Congratulations
on the purchase
of your tekmar
programmable
thermostat with
communication.
This thermostat
combines easy-to-use
programming with
advanced features to
increase both comfort
and energy efficiency.
Your tekmar
thermostat allows you
to:
• • View the outdoor
temperature on
all of your tekmar
thermostats.
• • Easily set up
custom "Scenes" to
match your home and
lifestyle.
• • Easily override your
tekmar thermostats if you
are planning an extended
absence.
-
User Brochure
4 Thermostat 541
Table of Contents
Display ........................................................ 2
Symbols Description ................................... 2
User Interface ............................................. 3
Viewing Current Temperatures ................... 4
Viewing the Room Set Temperature ........... 4
Adjusting the Room Set Temperature ......... 5
Temporary Room Set Adjustment............... 6
Choosing the Mode of Operation ................ 7
Selecting a Scene ....................................... 7
Selecting a Schedule .................................. 9
Units of Temperature ................................ 10
Backlight ................................................... 10
Cleaning the Thermostat ......................... 10
Error Messages ........................................ 11
Warranty ................................................... 12
1 of 12
U 541
© 2007
U 541 - 08/07
08/07
