Setup - Temp

Setting
FLOOR MIN - WAKE
Select the floor temperature while in the wake schedule .
Applies when there is both a floor and an air sensor .
FLOOR MIN - LEAVE
Select the floor temperature while in the leave schedule .
Applies when there is both a floor and an air sensor .
FLOOR MIN - RETURN
Select the floor temperature while in the return schedule .
Applies when there is both a floor and an air sensor .
FLOOR MIN - SLEEP
Select the floor temperature while in the sleep schedule .
Applies when there is both a floor and an air sensor .
FLOOR MIN - AWAY
Select the floor temperature while in away .
Applies when there is both a floor and an air sensor .
FLOOR MAX
Select the maximum floor temperature . This protects the
floor covering from over heating . Applies when there is a
floor sensor .
HEAT TO AWAY
Select the heating temperature when away .
HEAT TO MIN LIMIT
Select the minimum heating temperature limit .
HEAT TO MAX LIMIT
Select the maximum heating temperature limit .
COOL TO AWAY
Select the cooling temperature when away .
COOL TO MIN LIMIT
Select the minimum cooling temperature limit .
COOL TO MAX LIMIT
Select the maximum cooling temperature limit .
WARM WEATHER SHUT DOWN
Select the outdoor temperature at which the heating is shut off .
COLD WEATHER SHUT DOWN
Select the outdoor temperature at which the cooling is shut off .
HEAT PUMP BALANCE POINT
Select the outdoor temperature at which the heat pump is
shut off and the backup heat source is operated exclusively .
Screen Page 1
Screen Page 2
Screen Page 3
Range
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 95°F
Off, 4 .5 to 35 .0°C
Off, 40 to 100°F
Off, 4 .5 to 38 .0°C
Off, 40 to 100°F
Off, 4 .5 to 38 .0°C
Off, 40 to 100°F
Off, 4 .5 to 38 .0°C
Off, 40 to 100°F
Off, 4 .5 to 38 .0°C
Off, 40 to 100°F
Off, 4 .5 to 38 .0°C
Off, 10 to 70°F
Off, -12 .0 to 21 .0°C
Default
Off
Off
Off
Off
Off
Off
62°F
16 .5°C
Off
Off
Off
Off
Off
Off
Off
Off
19
