Catalog / Model Number_______________ Serial Number __________________

Initial Inspection

1. Upon receiving, examine the unit for external
damage.
2. Check to be sure the intake filter and the cabinet
air filter are in place.
3. Plug the unit into an electrical outlet, turn the unit
'On,' and check the audible/visual alarms.
4. Set the flow meter at the maximum
recommended flow rate and allow the unit to run
for 20 minutes.
5. Using an oxygen analyzer, check the
concentration.

Preventive Maintenance Check

Perform the PM at the interval shown for each model
in the Service Interval Chart below. Use the Log on
the back to track PM:
1. Record Hours
2. Perform Purity Check – check with an oxygen
analyzer and record the oxygen percent
3. Check Audible Alert and Indicator Lights every 2
years
4. Inspect Filters and replace as necessary
DeVilbiss Oxygen Concentrator Preventive Maintenance
Purity
Model
Check
515ADS/515AKS
2 Years
515ADZ/515AKZ
6 Months
2 Years
525 Series
515DS/515KS
2 Years
515DZ/515KZ
6 Months
2 Years
303DS
303DZ
6 Months
USA/Puerto Rico (800) 338-1988
DeVilbiss Oxygen Concentrator
Service Intervals
Cabinet
Filter
Wash on each
inspection. Replace
as necessary.
For a service manual or technical assistance, call:
Canada (905) 660-2459 / (800) 263-3390
Service and Maintenance Log

Between-Patient Maintenance

1. Discard oxygen tubing, cannula, & humidifier
bottle.
2. Wash or replace the cabinet air filter.
3. Wash the concentrator cabinet
4. Check oxygen concentration. If the unit falls within
specification, the intake bacteria filter does not
need to be replaced between patients.

Patient/Caregiver Maintenance

1. Oxygen tubing, cannula, and humidifier bottle -
clean daily.
2. Cabinet air filter - clean weekly
This PM Schedule assumes typical usage conditions below:
5000 hour usage per year
Normal, clean operating environment.
The homecare provider is responsible for:
determining the condition of the concentrator operating
environment
determining a preventive maintenance interval
takes into consideration the specific operating
environment.
Standard intervals are noted below. Service interval
may be more or less frequent than stated below
provided that the Home Care Provider establishes
and documents appropriate protocols.
Intake
Filter
Inspect every 2
years. Replace as
necessary.
Compressor Filter
N/A
N/A
years. Replace as
Inspect every 5
years. Replace as
conjunction with
necessary or in
compressor service.
conjunction with
compressor
service.
International (814) 443-4881
which
Final Bacteria
Filter
Inspect every 3
necessary or in
