Section 2: General Information
Specifications
Description
Max. cont. grid-tied AC power @ 122°F (50ºC)
Max. cont. islanded AC power @ 104°F (40°C)
with single 6 module battery cabinet
Max. cont. islanded AC power @ 104°F (40°C)
with 2 battery cabinets (8 modules minimum)
Max. cont. Islanded AC power @ 122°F (50°C)
Peak motor starting current (2 sec)
Normal output frequency AC
Grid Voltage Line to Neutral (L-N)
Grid Voltage Line to Line (L-L)
Peak efficiency
CEC weighted efficiency
AC terminals wire size
DC terminals wire size
STOP terminals wire size
Weight
Thermal management
Weatherization rating
Enclosure Material
Description
REbus voltage
REbus current
REbus Input short circuit current
REbus Input source backfeed current to input source
Output power factor rating AC
Operating voltage range AC, XVT076A03 (L-N)
Operating voltage range AC, XVT076A03 (L-L)
Operating voltage range AC, XVT114G03 (L-N)
Operating output voltage range AC, XVT114G03 (L-L)
Continuous output current AC grid-tied
PCS controlled current grid-tied
Continuous output current AC islanded
Output fault current duration
Full Power operating ambient temperature range
Utility interconnection voltage and frequency trip limits and trip
times
Trip voltage and frequency limits
Trip voltage accuracy
Trip time accuracy
1
Peak performance
2
Inverter limits its REbus current to adhere to its AC power rating. Total REbus current capability from multiple REbus
sources may safely exceed this value as the inverter safely limits the amount utilized.
3
Rating for one DC input. Four total.
4
Includes ambient temperature rising from inverter operation.
* In Island mode XVT114G03 Protected loads only supply 2 phases 120 VAC L-N, 208 L-L which results in lower power than in
grid tied 3 phase mode. The low value of the range is for full L-L loading while high value of the range is full L-N loading.
Installation Manual for Generac PWRcell Inverter
Units
kW
kW
1
kW
kW
A rms
Hz
VAC
VAC
%
%
AWG
AWG
AWG
lb (kg)
-
-
-
3
4
XVT076A03
7.6
9.0
11.0
8.8
240
97.3
96.5
14 to 6
18 to 6
28 to 16
62.7 (28.4)
forced convection
NEMA Type 3R
powder-coated steel
Units Min
V dc 360
V dc
V dc
V dc
-
V rms 108
V rms 216
V rms 108
V rms 184
A rms
A rms
A rms
A / ms
°F (°C) -4 (-20)
Voltage and Frequency Trip Thresholds
See
information.
%
General Information
XVT114G03
11.4
9.0
Range 9.6 to 11.0*
Range 7.5 to 8.8*
50
60
120
208
97.7
97.5
Nominal Max
380 420
2
30
30
30
1
120 130
240 260
120 130
208 228
32
32
42
50 / 2,000
+122 (+50)
for more
2% +/- 2 cycles
5
