Commissioning and Setup
Connecting PWRcell Inverter to AC
Power
Turn ON main AC backfeed to power-up the inverter.
See Figure 6-2. On power-up, the home screen will
appear on the control panel LCD with the operational
mode listed at the top of the home screen.
Figure 6-2. Inverter Power-Up
NOTE: If there is no grid power at the site and the sys-
tem includes a PWRcell battery, blackstart can be used
to start the system from the battery. See the Generac
PWRcell Battery Owner's manual for information on
blackstarting a system.

Selecting Inverter System Mode

NOTE: See the Generac PWRcell Inverter Owner's
Manual for more information on system mode options.
To select a system mode:
1. See 6-2. While viewing the home screen
Figure
press the center button.
2. See
Figure 6-3. A list of system modes will be
displayed with the current mode marked with an
asterisk.
NOTE: The list of modes may not include all those
shown in Figure 6-3.
System Mode
Safety Shutdown
Grid Tie *
Self Supply
Clean Backup
< EXIT SCROLL > NEXT • SELECT
Figure 6-3. Selecting System Modes (1 of 4)
26
3. See
highlight the desired mode and press the center
button to select.
System Mode
Safety Shutdown
Grid Tie *
Self Supply
Clean Backup
< EXIT
Figure 6-4. Selecting System Modes (2 of 4)
4. Arrow right and press the center button to select
010006
Confirm.
5. See
button to select Confirm.
System Mode
SA
GRd. Settings
SElibrate CTs
CLEPn: 00010003XXXX
< EXIT
Figure 6-5. Selecting System Modes (3 of 4)
6. See
the home screen is the desired mode.
Menu
Figure 6-6. Selecting System Modes (4 of 4)
009966
Figure 6-4. Use the up and down arrows to
SCROLL > NEXT • SELECT
6-5. Arrow right and press the center
Figure
Enable
Cancel Confirm
SCROLL > NEXT • SELECT
Figure 6-6. Verify the mode listed at the top of
