Enabling Beacon TOU
Once the TOU Schedule is set, the scheduler will auto-
matically enable itself and begin running. However, if the
scheduler becomes disabled for any reason, follow the
instructions below to re-enable the scheduler:
1. See Figure 6-19. Navigate to the Beacon device
page and press the center button to enter the
device menu.
REbus Beacon
TOU Scheduler
disabled
To enable scheduler,
press center button
and select "Enable".
Figure 6-19. Enabling Beacon (1 of 2)
2. Highlight Enable and press the center button.
3. See 6-20. Arrow sideways to Confirm and
Figure
press the center button.
Rebus Beacon
Enable
Enable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 6-20. Enabling Beacon (2 of 2)
Installation Manual for Generac PWRCell Inverter
010118
Menu
Confirm
011140
Disabling Beacon TOU
The scheduler can be disabled at any time. To disable
the scheduler:
1. See 6-21. Navigate to the Beacon device
Figure
page and press the center button to enter the
device menu.
REbus Beacon
TOU Scheduler
running
Next Change:
To:
Schedule:
Figure 6-21. Disabling Beacon (1 of 3)
2. Highlight Disable and press the center button.
3. See
Figure 6-22. Arrow sideways to Confirm and
press the center button.
Rebus Beacon
Enable
Disable
Mod. Settings
Calibrate CTs
Cancel
RCPn: 00010003XXXX
< EXIT SCROLL > NEXT • SELECT
Figure 6-22. Disabling Beacon (2 of 3)
4. See
Figure 6-23. The status line on the Beacon
device page will read Disabled.
NOTE: The system will remain in the current system
mode until the mode is changed manually or the sched-
uler is re-enabled.
REbus Beacon
TOU Scheduler
disabled
To enable scheduler,
press center button
and select "Enable".
Figure 6-23. Disabling Beacon (3 of 3)
Commissioning and Setup
1h:37m
Self Supply
SDGE
010113
Menu
Confirm
010117
010118
31
