INSTALLATION MANUAL
1095CFK Circulating Fan Kit
CSA approved for use only with Valor models 1000J Series Heaters
Note: This kit must be installed or serviced by a qualified installer, service agency or
gas supplier. These instructions are to be used in conjunction with the main installation
instructions for the above listed models.
WARNING: If these instructions are not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
GROUNDING: This power supply must be installed and grounded in accordance with local
codes, or in the absence of local codes, with the current Canadian Electrical Code CSA C22.1.
or in the USA the National Electrical Code ANSI/NFPA70 latest edition.
Description of System
The models listed above have been designed to
accommodate the installation of an air circulation fan.
Operated via the remote control handset and having
variable speed control, the fan is designed to boost the
natural convection through the heater; this may be a
desirable feature dependent on the fi replace location
and room layout.
It is preferable to install the circulating fan before com-
pleting the heater installation, although it may also be
retrofi tted at a later date provided power has been pre-
wired within the fi replace casing.
Note: Live wiring must terminate within a junction box.
A junction box is supplied as part of this kit. If roughing-
in power ahead of the fan installation, ensure the wiring
is not live or terminate the wiring within a temporary
junction box.
Retrofi tting the fan after the fi replace installation is
completed will require disconnecting the gas and
removing the burner module and gas train from the
fi replace.
The fan is designed for automatic operation to come
on and off when the burner comes on and off . The
fan speed can be controlled from the remote control
handset. There are four speeds available.
4007549-01
© 2019, Miles Industries Ltd. All rights reserved.
H3 Series
The fan, if turned on, will start approximately 4 minutes
after lighting the appliance and will continue to run for
approximately 10 minutes after the burner is shut off ,
and the control valve has rotated all the way to "OFF".
The fan will operate at the speed last selected by the
user.
Operation
with Valor MAX Remote
Control
To operate the fan, press the "SET" button on
the remote handset until only the fan icon
(
) appears on the display and is fl ashing. Press the
up/down buttons to set the fan speed (
showing means the fan is OFF. Once the fl ashing stops,
the fan is set. The fan icon and number of bars will show
when the remote is in other modes to confi rm the fan
status.
Note: The fan, when plugged in, provides power for
the remote control receiver via the fan control module.
Therefore batteries are no longer required in the battery
holder other than for back-up purposes. Batteries
are still required in the remote control handset.
Electrical Requirements
The fan kit requires a power supply of 120 Volts,
1 phase, 60 Hz. Full load current is less than 1 amp.
MAX
). No bar
1
