Summary of Contents for KaVo MASTERtorque
- Page 1 Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 Always be on the safe side.
- Page 2 Distributed by: Manufacturer: KaVo Dental GmbH Kaltenbach & Voigt GmbH Bismarckring 39 Bismarckring 39 D-88400 Biberach D-88400 Biberach Phone +49 (0) 7351 56-0 www.kavo.com Fax +49 (0) 7351 56-1488...
-
Page 3: Table Of Contents
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 Table of contents Table of contents Safety ................................ 2 Safety instructions ........................... 2 Product description ............................ 3 Purpose – Proper use ........................3 Technical data ..........................4 Changing the replacement turbine ......................5 First use .............................. -
Page 4: Safety
▶ Stop work and seek service support. Note KaVo accepts no liability for damage arising from repairs that have been carried out inappropriately. It is permissible to have the replacement turbine exchanged by: ▪ Technicians at KaVo branches throughout the world ▪... -
Page 5: Product Description
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 2 Product description | 2.1 Purpose – Proper use 2 Product description ▪ Replacement turbine with wrenchMat. no. 2.000.2288 Note Wrench ⑥ for cover. Stamp ⑤ for installation of brake ring ④. -
Page 6: Technical Data
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 2 Product description | 2.2 Technical data According to these regulations, it is the responsibility of the user to: ▪ only use equipment that is operating correctly, ▪ use the equipment for the proper purpose, ▪... -
Page 7: Changing The Replacement Turbine
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 3 Changing the replacement turbine 3 Changing the replacement turbine CAUTION Residues in the head or cover of the spare turbine. Malfunctions. ▶ Remove potential residues of a defective spare turbine such as spring wash‐... - Page 8 ▶ Insert the enclosed spring washers into the lid and head housing. Insert the O-rings ▶ Replace both O-rings. ▶ Spray O-rings with KaVo Spray and insert them in the head housing and cov‐ Insert the replacement turbine DANGER Not maintaining a torque of 100 Ncm when tightening the cover.
-
Page 9: First Use
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 4 First use 4 First use CAUTION Compressed air connection on devices. Dirty and moist compressed air causes premature bearing wear. ▶ Ensure that the cooling air is dry, clean and uncontaminated in accordance with EN ISO 7494-2. -
Page 10: Function Test
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 5 Function test 5 Function test ▶ Insert a tool (cutter or grinder) and turn it radially by hand in various directions, applying slight thumb pressure, to precisely align the O-rings. -
Page 11: Tools And Consumables
Instructions for use Spare cartridge for MASTERtorque - 2.000.2288, 2.000.2266 6 Tools and consumables 6 Tools and consumables Obtainable from the dentalmed. specialist supplier Material summary Mat. No. Wrench 0.411.3053 O-rings 0.200.6172 Spring washer 1.003.5900 Stamp for brake ring 3.000.0214 Material summary Mat.
