Page 9: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and acces-...
Page 10 ● ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail- able on request at your Toyota dealer.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 14: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 844 Searching installation ■ position • Pictorial index....P. 14 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 840 Searching by title ■...
Page 15: Pictorial Index
Pictorial index Pictorial index ■ Exterior Side doors ........P. 162 Locking/unlocking .
Page 16 Pictorial index Windshield wipers ....... . . P. 344 Precautions against winter season ..... P. 472 To prevent freezing (windshield wiper de-icer) .
Page 17 Pictorial index ■ Instrument panel (Left-hand drive vehicles) Engine switch ....... . P. 291, 295 Starting the engine/changing the modes .
Page 18 Pictorial index Multi-information display ..... . . P. 115, 119 Display........P. 115, 119 When the warning messages are displayed .
Page 19 Pictorial index ■ Switches (Left-hand drive vehicles) Power window switches ......P. 252 Door lock switch .
Page 20 ..... . P. 575 Toyota parking assist-sensor switch ....P. 407 DPF system switch .
Page 21 Pictorial index 1, 2 Audio remote control switches ....P. 482 Meter control switches ......P. 120 Vehicle-to-vehicle distance switch .
Page 22 Pictorial index 1, 3 Multi-terrain Select mode selector dial 1, 3 Crawl Control speed selector dial 1, 3 Multi-terrain Select ON/OFF switch 1, 3 Crawl Control ON/OFF switch 1, 3 Center differential lock/unlock switch 1, 3 Rear differential lock/unlock switch Four-wheel drive control switch 1, 3 Height control button...
Page 23 Pictorial index ■ Interior (Left-hand drive vehicles) SRS airbags ........P. 44 Floor mats .
Page 24 Pictorial index Inside rear view mirror ......P. 245 Sun visors ........P. 601 Vanity mirrors .
Page 25 Pictorial index ■ Instrument panel (Right-hand drive vehicles) Engine switch ....... . P. 291, 295 Starting the engine/changing the modes .
Page 26 Pictorial index Multi-information display ..... . . P. 115, 119 Display........P. 115, 119 When the warning messages are displayed .
Page 27 Pictorial index ■ Switches (Right-hand drive vehicles) Outside rear view mirror switches....P. 247 Automatic High Beam switch ..... . P. 336 Headlight cleaner switch .
Page 28 Pictorial index Toyota parking assist-sensor switch ....P. 407 1, 2 Multi-terrain Monitor switch Windshield wiper de-icer switch ....P. 554, 562 Tire pressure warning reset switch .
Page 29 Pictorial index 1, 2 Audio remote control switches ....P. 482 Meter control switches ......P. 120 Vehicle-to-vehicle distance switch .
Page 30 Pictorial index 1, 3 Multi-terrain Select mode selector dial 1, 3 Crawl Control speed selector dial 1, 3 Multi-terrain Select ON/OFF switch 1, 3 Crawl Control ON/OFF switch 1, 3 Center differential lock/unlock switch 1, 3 Rear differential lock/unlock switch Four-wheel drive control switch 1, 3 Height control button...
Page 31 Pictorial index ■ Interior (Right-hand drive vehicles) SRS airbags ........P. 44 Floor mats .
Page 32 Pictorial index Inside rear view mirror ......P. 245 Sun visors ........P. 601 Vanity mirrors .
Page 33 Pictorial index LC150_OM_OM60R93E_(GE)
Page 34: For Safety And Security
For safety and security 1-1. For safe use Before driving.......34 For safe driving ....36 Seat belts......38 SRS airbags......44 Airbag manual on-off system .......57 Safety information for children......59 Child restraint systems ..60 Installing child restraints ..73 Exhaust gas precautions ..87 1-2. Theft deterrent system Engine immobilizer system .......88 Double locking system..92...
Page 35: 1-1. For Safe Use
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 36 When installing the driver’s floor mat Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 37: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust the angle of the seat- back so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 38 1-1. For safe use Adjusting the mirrors Make sure that you can see backward clearly by adjusting the inside and outside rear view mirrors properly. (P. 245, 247) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’s seat while driving.
Page 39: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ◆ 3-point type seat belt ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 40 1-1. For safe use Fastening and releasing the seat belt To fasten the seat belt, push the plate into the buckle until a click sound is heard. To release the seat belt, press the release button. Release button Adjusting the seat belt shoulder anchor height (front and outer second [5-door models] seats) Push the seat belt shoulder anchor down while pressing the...
Page 41 1-1. For safe use Seat belt pretensioners (outer front seats) The pretensioners help the seat belts to quickly restrain the occu- pants by retracting the seat belts when the vehicle is subjected to certain types of severe frontal or side collision. The pretensioners do not activate in the event of a minor frontal impact, a minor side impact, a rear...
Page 42 ● For Taiwan: Toyota recommends that children be seated in the rear seat and always use seat belt. However, if a child is not large enough to prop- erly wear the vehicle’ seat belt, ensure that they are seated in a rear seat and use an appropriate child restraint system.
Page 43 Seat belt pretensioners If the pretensioner has activated, the SRS warning light will come on. In that case, the seat belt cannot be used again and must be replaced at your Toyota dealer. Adjustable shoulder anchor ■ Always make sure the shoulder belt is positioned across the center of your shoulder.
Page 44 ● Ensure that the belt and plate are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. Replace the seat assembly, including the belts, if your vehicle has been ●...
Page 45: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. LC150_OM_OM60R93E_(GE)
Page 46 1-1. For safe use ◆ SRS front airbags SRS driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas- senger from impact with interior components SRS driver knee airbag (if equipped) Can help provide driver protection ◆...
Page 47 1-1. For safe use Airbag system components Front impact sensors Driver airbag Side impact sensors Safing sensor (rear) (front door) (if equipped) (if equipped) Airbag manual on-off switch Driver’s seat belt buckle (if equipped) switch Curtain shield airbags Driver’s knee airbag (if equipped) (if equipped) Front passenger airbag...
Page 48 1-1. For safe use The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help restrain the motion of the occu- pants.
Page 49 An infant or child who is too small to use a seat belt should be properly secured using a child restraint system. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained.
Page 50 1-1. For safe use WARNING SRS airbag precautions ■ ● Vehicles with SRS curtain shield air- bags: Do not lean against the door, the roof side rail or the front, side and rear pil- lars. Vehicles with SRS side airbags: ●...
Page 51 1-1. For safe use WARNING SRS airbag precautions ■ ● Vehicles with SRS curtain shield air- bags: Do not attach anything to areas such as a door, windshield glass, side door glass, front, side or rear pillars, roof side rail and assist grip. Vehicles without a smart entry &...
Page 52 Wash off any residue as soon as possible to prevent skin irritation. If the areas where the SRS airbags are stored, such as the steering wheel ● pad and front, side and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 53 ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. Installation, removal, disassembly and repair of the SRS airbags ●...
Page 54 1-1. For safe use ■ SRS airbag deployment conditions (SRS front airbags) The SRS front airbags will deploy in the event of an impact that exceeds the ● set threshold level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18 mph] frontal collision with a fixed wall that does not move or deform).
Page 55 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front air- bags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 56 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● ●...
Page 57 1-1. For safe use ● Vehicles with SRS side airbags: The surface of the seats with the SRS side airbag is scratched, cracked or oth- erwise damaged. Vehicles with SRS curtain shield air- ● bags: The portion of the front pillars, side pil- lars, rear pillars or roof side rail gar- nishes (padding) containing the SRS curtain...
Page 58: Airbag Manual On-Off System
1-1. For safe use  Airbag manual on-off system This system deactivates the front passenger airbag. Only deactivate the airbag when using a child restraint system on the front passenger seat. AIR BAG OFF indicator light This indicator light turns on when the engine switch is in IGNITION ON mode.
Page 59 AIR BAG OFF indicator light If any of the following problems occur, it is possible that there is a malfunction in the system. Have the vehicle inspected by your Toyota dealer. ● The indicator light does not come on when the airbag manual on-off switch is switched to “OFF”.
Page 60: Safety Information For Children
1-1. For safe use Safety information for children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt.
Page 61: Child Restraint Systems
General installation instructions are provided in this manual. (P. 73) ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint sys- tem installation. ● Toyota recommends that you use a child restraint system which conforms to the regulation ECE No.44.
Page 62 1-1. For safe use Types of child restraints Child restraint systems are classified into the following 5 groups according to the regulation ECE No.44. Group 0: Up to 10 kg (22 lb.) (0 - 9 months) Group 0+: Up to 13 kg (28 lb.) (0 - 2 years) Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years) Group II:...
Page 63 1-1. For safe use Child restraint system suitability for various seating positions Information provided in the table shows your child restraint system suitability for various seating positions.  For Taiwan (vehicles without slideable second seat): Seating Front passenger position seat Second seat Airbag manual on-off switch...
Page 64 1-1. For safe use  For Taiwan (vehicles with slideable second seat): Seating Front passenger position seat Second seat Third Airbag manual seat (if on-off switch Stan- equipped) dard Out- Center board Mass groups Up to 10 kg (22 lb.) (0 - 9 months) Up to 13 kg (28 lb.)
Page 65 1-1. For safe use  Except for Taiwan: Seating Front passenger position seat Second seat Third Airbag manual seat (if on-off switch Stan- equipped) dard Out- Center board Mass groups Up to 10 kg Never Never (22 lb.) (0 - 9 months) Up to 13 kg Never Never...
Page 66 L1: Suitable for “TOYOTA G0+, BABYSAFE PLUS” (0 to 13 kg [0 to 28 lb.]) and “TOYOTA MINI” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.
Page 67 1-1. For safe use NOTE: : Adjust the seatback to the most upright position. Move the front seat to the rear most position. If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint. If the passenger seat is equipped with a vertical height adjuster, it must be placed in the upper most position.
Page 68 1-1. For safe use Child restraint system suitability for various seating positions (with ISOFIX rigid anchors) Information provided in the table shows your child restraint system suitability for various seating positions. Vehicle ISOFIX positions Mass groups Size class Fixture Outboard second seat ISO/L1 Carrycot ISO/L2...
Page 69 IUF: Suitable for ISOFIX forward-facing child restraint systems of uni- versal category approved for use in this mass group. IL1: Suitable for “TOYOTA MINI with BASE” (0 to 13 kg [0 to 28 lb.]) and “TOYOTA MIDI” (0 to 13 kg [0 to 28 lb.]) approved for the use in this mass group.
Page 70 1-1. For safe use The child restraint systems mentioned in the table may not be avail- able outside of the EU area. Other child restraint systems different from the systems mentioned in the table can be used, but the suitability of the systems must be care- fully checked with the child restraint system manufacturer and retailer.
Page 71 1-1. For safe use WARNING Child restraint precautions (For Taiwan) ■ ● For effective protection in automobile accidents and sudden stops, a child must be properly restrained, using a seat belt or child restraint system depending on the age and size of the child. Holding a child in your arms is not a substitute for a child restraint system.
Page 72 In an accident, the child can be crushed against the windshield, or between you and the vehicle’s interior. Toyota strongly urges the use of a proper child restraint system that con- ●...
Page 73 1-1. For safe use WARNING When children are in the vehicle ■ Do not allow children to play with the seat belt. If the seat belt becomes twisted around a child’s neck, it may lead to choking or other serious injuries that could result in death.
Page 74: Installing Child Restraints
1-1. For safe use Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the seats using a seat belt or ISOFIX rigid anchors. Attach the top strap when installing a child restraint. Seat belts (An ELR belt requires a locking clip) ISOFIX rigid anchors (ISOFIX child restraint system)
Page 75 1-1. For safe use Installing child restraints using a seat belt Rear-facing  Baby seat (infant seat)/child seat (convertible ■ seat) Adjust the seats as follows:  3-door models Fold the seatback forward and then back to the 1st lock posi- tion (most upright position) until it locks into place.
Page 76 1-1. For safe use Place the child restraint sys- tem on the second seat fac- ing the rear of the vehicle. Run the seat belt through the child restraint system and insert the plate into the buckle. Make sure that the belt is not twisted.
Page 77 1-1. For safe use Forward-facing Child seat (convertible seat) ■ Adjust the seats as follows:  3-door models Fold the seatback forward and then back to the 1st lock posi- tion (most upright position) until it locks into place. Adjust the seatback to the 5th lock posi- tion.
Page 78 1-1. For safe use Install a locking clip near the tab of the lap and shoulder belt by inserting the lap and shoulder webbing through the recesses of the locking clip. Buckle the belt again. If belt has slack, release the buckle and rein- stall the locking clip.
Page 79 1-1. For safe use Junior seat (booster seat) ■ Adjust the seats as follows:  3-door models Fold the seatback forward and then back to the 1st lock posi- tion (most upright position) until it locks into place. Adjust the seatback to the 5th lock posi- tion.
Page 80 1-1. For safe use Sit the child in the child restraint system. Fit the seat belt to the child restraint sys- tem according to the manu- facturer’s instructions insert the plate into the buckle. Make sure that the belt is not twisted. Check that the shoulder belt is correctly positioned over the child’s shoulder, and that the lap...
Page 81 1-1. For safe use Installation with ISOFIX rigid anchors (ISOFIX child restraint system) Adjust the seats as follows:  3-door models Fold the seatback forward and then back to the 1st lock position (most upright position) until it locks into place. Adjust the seat- back to the 5th lock position.
Page 82 You need a locking clip to install the child restraint system. Follow the instruc- tions provided by the manufacturer of the system. If your child restraint sys- tem does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010)
Page 83 1-1. For safe use WARNING When installing a child restraint system (For Taiwan) ■ Follow the directions given in the child restraint system installation manual and fix the child restraint system securely in place. If the child restraint system is not correctly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving or an accident.
Page 84 “9L” in the illustration is not related to the contents of the warning label. If child restraint system regulations exist in the country where you reside, ● please contact your Toyota dealer for the child restraint system installation. ● When installing a child restraint system on the second center seat, adjust both seat cushions to the same position (vehicles with third manual/power seats) and align both seatbacks at the same angle.
Page 85 1-1. For safe use WARNING When installing a child restraint system (For Taiwan) ■ ● Shake the child restraint system left and right, and forward and backward to ensure that it has been securely installed. After securing a child restraint system, never adjust the seat. ●...
Page 86 1-1. For safe use WARNING When installing a child restraint system (except for Taiwan) ■ ● Vehicles without an airbag manual on- off switch: Never install a rear-facing child restraint system on the front pas- senger seat. The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 87 ■ ● If child restraint system regulations exist in the country where you reside, please contact your Toyota dealer for the child restraint system installation. When installing a child restraint system on the second center seat, adjust ● both seat cushions to the same position (vehicles with third manual/power seats) and align both seatbacks at the same angle.
Page 88: Exhaust Gas Precautions
Keep the back door closed. If you smell exhaust gases in the vehicle even when the back door is ● closed, open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking If the vehicle is in a poorly ventilated area or a closed area, such as a ●...
Page 89: 1-2. Theft Deterrent System
1-2. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 90 1-2. Theft deterrent system ■ Certification for the engine immobilizer system (vehicles without a smart entry & start system)  For vehicles sold in the Dominican Republic LC150_OM_OM60R93E_(GE)
Page 91 1-2. Theft deterrent system  For vehicles sold in Vietnam Certification for the engine immobilizer system (vehicles with a smart ■ entry & start system)  For vehicles sold in the Dominican Republic LC150_OM_OM60R93E_(GE)
Page 92 1-2. Theft deterrent system  For vehicles sold in Taiwan  For vehicles sold in Jamaica NOTICE To ensure the system operates correctly ■ Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. LC150_OM_OM60R93E_(GE)
Page 93: Double Locking System
1-2. Theft deterrent system  Double locking system Unauthorized access to the vehicle is prevented by disabling the door unlocking function from both the interior and exterior of the vehicle. Vehicles employing this system have labels on the window glass of both front doors.
Page 94: Alarm
1-2. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or glass hatch (if equipped) is unlocked or opened in any way other than using the entry function (vehicles with a smart entry &...
Page 95 1-2. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm. ● Unlock the doors using the entry function or the wireless remote control. ● Start the engine. (The alarm will be deactivated or stopped after a few seconds.) ■...
Page 96 1-2. Theft deterrent system ● The battery is recharged or replaced when the vehicle is locked. (P. 777) ■ Alarm-operated door lock In the following cases, depending on the situation, the door may automatically lock to prevent improper entry into the vehicle: ●...
Page 97 1-2. Theft deterrent system Intrusion sensor and tilt sensor (if equipped) ● The intrusion sensor detects intruders or movement in the vehicle. ● The tilt sensor detects changes in vehicle inclination, such as when the vehicle is towed away. This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.
Page 98 1-2. Theft deterrent system ■ Canceling and automatic re-enabling of the intrusion sensor and tilt sen- sor (if equipped) The alarm will still be set even when the intrusion sensor and tilt sensor are ● canceled. ● After the intrusion sensor and tilt sensor are canceled, pressing the engine switch or unlocking the doors using the entry function or wireless remote control will re-enable the intrusion sensor and tilt sensor.
Page 99 1-2. Theft deterrent system ● The vehicle is parked in a place where extreme vibrations or noises occur, such as in a parking garage. Ice or snow is removed from the vehicle, ● causing the vehicle to receive repeated impacts or vibrations. The vehicle is inside an automatic or high-pressure car wash.
Page 100 Do not spray air fresheners or other ● products directly into the sensor holes. Installing accessories other than genuine Toyota parts or leaving objects ● between the driver’s seat and front passenger’s seat may reduce the detection performance.
Page 101 1-2. Theft deterrent system LC150_OM_OM60R93E_(GE)
Page 102: Instrument Cluster
Instrument cluster Instrument cluster Warning lights and indicators ......102 Gauges and meters ...111 Multi-information display (Type A)......115 Multi-information display (Type B)......119 Fuel consumption information.......130 LC150_OM_OM60R93E_(GE)
Page 103: Instrument Cluster Warning Lights And
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustrations dis- play all warning lights and indicators illuminated.
Page 104 2. Instrument cluster  Vehicles with the multi-information display type B The units used on the speedometer and some indicators may differ depending on the target region. LC150_OM_OM60R93E_(GE)
Page 105 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. Master warning light Open door warning light (P. 733) (P. 732) (if equipped) Driver’s and front Brake system warning passenger’s seat light (P. 729) belt reminder light (P.
Page 106 Smart entry & start PCS warning light system indicator (P. 730) (green) (P. 737) (if equipped) (if equipped) 1, 3 Toyota parking Smart entry & start assist-sensor indicator system indicator (yellow) (P. 734) (P. 737) (if equipped) (if equipped) LED headlight warning DPF system warning light (P.
Page 107 They will turn off after the engine is started, or after a few seconds. There may be a malfunction in a system if the lights do not come on, or turn off. Have the vehicle inspected by your Toyota dealer.
Page 108 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. 1, 2 Turn signal indicator Downhill assist control (P. 316) system indicator (if equipped) Headlight high beam Cruise control “SET” indicator (P. 326) indicator (P.
Page 109 (if equipped) 2, 7 Rear differential lock MTS AUTO indicator indicator (if equipped) (if equipped) 1, 6 Toyota parking Eco drive mode assist-sensor indicator indicator (P. 404) (P. 408) (if equipped) (if equipped) 1, 3 PCS warning light SPORT S mode indicator (P.
Page 110 There may be a malfunction in a system if a light does not turn on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : Refer to the “Off-road Driving Owner’s Manual”...
Page 111 Have the vehicle inspected by your Toyota dealer immediately if this occurs. LC150_OM_OM60R93E_(GE)
Page 112: Gauges And Meters
2. Instrument cluster Gauges and meters  Vehicles with the multi-information display type A (except for 5L-E engine) Vehicles with the multi-information display type A (5L-E engine)  LC150_OM_OM60R93E_(GE)
Page 113 2. Instrument cluster  Vehicles with the multi-information display type B The units used on the speedometer may differ depending on the tar- get region. Engine coolant temperature gauge Displays the engine coolant temperature Multi-information display Presents the driver with a variety of driving-related data (P.
Page 114 2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute Odometer/trip meter display change button P. 113, 116 : Vehicles with an automatic transmission only. Changing the display Vehicles with the multi-information display type A  P. 115 ...
Page 115 2. Instrument cluster ■ The meters and display illuminate when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode. ■...
Page 116: Multi-Information Display (Type A)
2. Instrument cluster  Multi-information display (Type A) Display contents The multi-information display presents the driver with a variety of driv- ing-related data including the current outside air temperature. Automatic Manual transmission transmission ● Outside temperature display (P. 117) ● Trip information contents (P.
Page 117 2. Instrument cluster Switching the display Items displayed can be switched by pressing the “ODO/TRIP” but- ton. Trip information contents Odometer ■ Display the total distance the vehicle has been driven. Trip meters A and B ■ Display the distance the vehicle has been driven since the meters were last reset.
Page 118 2. Instrument cluster Average fuel consumption ■ Displays the average fuel consumption since the function was reset • The function can be reset by pressing the “ODO/TRIP” button for longer than 1 second when the average fuel consumption is displayed. •...
Page 119 When the outside temperature has changed suddenly (at the entrance/exit of a garage, tunnel, etc.) When “--” or “E” is displayed, the system may be malfunctioning. Take your ● vehicle to Toyota dealer. WARNING ■ The multi-information display at low temperatures (vehicles with an...
Page 120: Multi-Information Display (Type B)
2. Instrument cluster  Multi-information display (Type B) Summary of functions The multi-information display presents the driver with a variety of driv- ing related data, such as the current outside temperature. The multi- information display can also be used to change the display settings and other settings.
Page 121 2. Instrument cluster Operating the meter control switches The multi-information display is operated using the meter control switches. Switching displayed items Operate up and down: Switches screens and moves the cursor Press: Enters, moves to next screen and turns functions on/off : For some functions Press: Displays the screen registered as the top screen When no screen has been registered, the drive information screen will be...
Page 122 2. Instrument cluster Menu icons Drive information Select to display various drive data. (P. 122) Vehicle information display Select to display the vehicle information. (P. 124) Navigation system-linked display (if equipped) Select to display the following navigation system-linked information. • Route guidance •...
Page 123 2. Instrument cluster Drive information Items displayed can be switched by operating up and down. After Start ■ Average fuel economy Displays the average fuel con- sumption since the engine was started. Average vehicle speed Displays average vehicle speed since engine started.
Page 124 2. Instrument cluster After Refuel ■ Range Displays the driving range with remaining fuel. Average fuel economy Displays the average fuel con- sumption since the vehicle was refueled. : This distance is computed based on your average fuel consumption. As a result, the actual distance that can be driven may differ from that dis- played.
Page 125 2. Instrument cluster Vehicle information Items displayed can be switched by operating up and down. Steering angle ■ Displays the direction of the front tires. The tire direction is displayed in 3 stages for both left and right, in accor- dance with the angle of the tire.
Page 126 2. Instrument cluster Settings display The settings of some features can be changed by using the meter control switches. Setting procedure ■ On the setting screen, choose the desired item using , and then press • For functions that can be enabled or disabled, the function switches between on and off each time is pressed.
Page 127 2. Instrument cluster ● Meter settings (P. 835) Select to set the following items. • Language Select to change the language on the display. • Units Select to change the unit for measure. • Eco Driving Indicator Light (if equipped) Select to activate/deactivate the Eco Driving Indicator Light.
Page 128 2. Instrument cluster Other contents AVS mode (if equipped) ■ Refer to the “Off-road Driving Owner’s Manual” Driving mode (if equipped) (P. 404) ■ Rear height control air suspension display (if equipped) ■ Refer to the “Off-road Driving Owner’s Manual” Multi-terrain Select display (if equipped) ■...
Page 129 When “--” or “E” is displayed, the system may be malfunctioning. Take your ● vehicle to Toyota dealer. ■ Suspension of the settings display In the following situations, the settings display using the meter control switches will be suspended.
Page 130 2. Instrument cluster WARNING Caution for use while driving ■ For safety, avoid operating the meter control switches while driving as much as possible, and do not look continuously at the multi-information display while driving. Stop the vehicle and operate the meter control switches. Fail- ure to do so may cause a steering wheel operation error, resulting in an unexpected accident.
Page 131: Fuel Consumption Information
2. Instrument cluster  Fuel consumption information Navigation system or multimedia system screen (if equipped) can be used to display the fuel consumption. Display the screen Press the “MENU”/“APPS” button. Select “Information” (on some models), and then select “Eco” on the screen.
Page 132: Operation Of Each Component
Operation of each component 3-1. Key information Keys........132 3-2. Opening, closing and locking the doors Side doors......162 Back door......172 Glass hatch......179 Smart entry & start system ......185 3-3. Adjusting the seats Front seats......217 Rear seats ......220 Driving position memory ..235 Head restraints ....239 3-4.
Page 133: Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle.  Vehicles without a smart entry & start system Master keys Operating the wireless remote con- trol function Valet key Key number plate  Vehicles with a smart entry & start system Electronic keys •...
Page 134 (P. 162) Opens the glass hatch (vehi- cles with the glass hatch) (P. 179) : These settings must be customized at your Toyota dealer. Vehicles with a smart entry & start system  Locks the doors (P. 162) Closes the windows and moon roof (if equipped) (P.
Page 135 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using a master key (vehicles without a smart entry & start system) or the other key (vehicles with a smart entry & start system) and the key number stamped on your key num- ber plate.
Page 136 You can replace the battery by yourself (P. 691). However, as there is a danger that the electronic key may be damaged, it is recommended that replacement is carried out by your Toyota dealer. ● To reduce key battery depletion when the electronic key is to not be used for long periods of time, set the electronic key to the battery-saving mode.
Page 137 3-1. Key information ■ If a wrong key is used On some models: The key cylinder rotates freely to isolate inside mechanism. Certification for wireless remote control ■  For vehicles sold in Vietnam  For vehicles sold in Tahiti LC150_OM_OM60R93E_(GE)
Page 138 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 139 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 140 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 141 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 142 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 143 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 144 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 145 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 146 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 147 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 148 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 149 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 150 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 151 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 152 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 153 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 154 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 155 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 156 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 157 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 158 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 159 3-1. Key information  For vehicles sold in the Commonwealth of Dominica LC150_OM_OM60R93E_(GE)
Page 160 3-1. Key information LC150_OM_OM60R93E_(GE)
Page 161 3-1. Key information  For vehicles sold in Republic of Paraguay  For vehicles sold in Republic of Zambia  For vehicles sold in Nigeria LC150_OM_OM60R93E_(GE)
Page 162 When an electronic key is lost (vehicles with a smart entry & start sys- ■ tem) If the electronic key remains lost, the risk of vehicle theft increases signifi- cantly. Visit your Toyota dealer immediately with all remaining electronic keys that were provided with your vehicle. LC150_OM_OM60R93E_(GE)
Page 163: Side Doors
3-2. Opening, closing and locking the doors Side doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Locking and unlocking the doors from the outside ◆ Smart entry & start system (if equipped) Carry the electronic key to enable this function.
Page 164 Press and hold to close the windows and moon roof (if equipped). Check that the door is securely locked. Unlocks all the doors Press and hold to open the windows and moon roof (if equipped). : These settings must be customized at your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 165 : These settings must be custom- ized at your Toyota dealer. Vehicles with a smart entry & start system  The doors can also be locked and unlocked with the mechanical key. (P. 769) Operation signals ■...
Page 166 3-2. Opening, closing and locking the doors ■ Door lock buzzer If an attempt to lock the doors is made when a door and/or the glass hatch is not fully closed, a buzzer sounds continuously for 5 seconds. Fully close the door and/or the glass hatch to stop the buzzer, and lock the vehicle once more.
Page 167 3-2. Opening, closing and locking the doors Locking and unlocking the doors from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock button Locks the door Unlocks the door The driver’s door and front pas- senger’s door (for some models only) can be opened by pulling the inside handle even if the...
Page 168 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without a smart entry & start system ...
Page 169 3-2. Opening, closing and locking the doors Setting and canceling the functions ■ To switch between setting and canceling, follow the procedure below. Close all the doors and turn the engine switch to IGNITION ON mode. (Perform step 2 within 20 seconds.) Shift the shift lever to P or N, and press and hold the driver’s...
Page 170 3-2. Opening, closing and locking the doors ■ Changing the door unlock function setting (vehicles with a smart entry & start system) It is possible to set which doors the entry function unlocks using the wireless remote control. Turn the engine switch off. Cancel the intrusion sensor and tilt sensor of the alarm system to prevent unintended triggering of the alarm during the setting change.
Page 171 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system (if equipped) In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 172 3-2. Opening, closing and locking the doors WARNING To prevent an accident ■ Observe the following precautions while driving the vehicle. Failing to do so may result in a door opening and an occupant falling out, resulting in death or serious injury. Ensure that all doors are properly closed and locked.
Page 173: Back Door
3-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked and opened by the fol- lowing procedures. Locking and unlocking the back door from the outside ◆ Smart entry & start system (if equipped) Carry the electronic key to enable this function. ...
Page 174 3-2. Opening, closing and locking the doors Locking and unlocking the back door from the inside ◆ Door lock switch Locks all the doors Unlocks all the doors ◆ Inside lock button (vehicles with longitudinal type third seats) Locks the door Unlocks the door LC150_OM_OM60R93E_(GE)
Page 175 3-2. Opening, closing and locking the doors Opening the back door from the outside  Vehicles with back door mounted spare tire Pull the handle Open the back door The back door can be kept open at a desired position. ...
Page 176 3-2. Opening, closing and locking the doors Back door child-protector lock (vehicles with longitudinal type third seats) The door cannot be opened from inside the vehicle when the lock is set. Unlock Lock This lock can be set to prevent chil- dren from opening the back door.
Page 177 3-2. Opening, closing and locking the doors WARNING While driving ■ ● Keep the back door closed while driving. If the back door is left open, it may hit near-by objects while driving or lug- gage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 178 If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. LC150_OM_OM60R93E_(GE)
Page 179 Failure to do so may cause damage to the back door damper stay, resulting in malfunction. ● Do not attach any accessories other than genuine Toyota parts to the back door. Do not lean against, climb on or place ●...
Page 180: Glass Hatch
3-2. Opening, closing and locking the doors  Glass hatch The glass hatch can be opened using the glass hatch opener or wireless remote control. Opening the glass hatch ◆ Glass hatch opener Press the button to pop up the glass hatch. Raise The glass hatch cannot be opened when the back door is...
Page 181 3-2. Opening, closing and locking the doors ◆ Wireless remote control Press and hold the button to open the glass hatch. The glass hatch will pop up. Vehicles without a smart entry Vehicles with a smart entry &   &...
Page 182 3-2. Opening, closing and locking the doors ■ When opening the glass hatch ● Open the glass hatch slowly and carefully. ● Use the glass hatch opener or wireless remote control when the back door is closed. ■ Operation signals (when opening with the wireless remote control) A buzzer (if equipped) sounds once to indicate that the glass hatch have been opened.
Page 183 3-2. Opening, closing and locking the doors WARNING While driving ■ ● Keep the glass hatch closed while driving. If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 184 Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the glass hatch. Such additional weight on the glass hatch may cause the glass hatch to suddenly shut again after it is opened.
Page 185 Do not touch the damper stay rod with ● gloves or other fabric items. ● Do not attach any accessories other than genuine Toyota parts to the glass Damper stays hatch. ● Do not place your hand or foot on the damper stay or apply lateral forces to it.
Page 186: Smart Entry & Start System
3-2. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 187 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected) When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) of either of the outside front door handle.
Page 188 3-2. Opening, closing and locking the doors The following table describes circumstances and correction procedures when only alarms are sounded. Alarm Situation Correction procedure Interior alarm An attempt was made to lock Retrieve the electronic pings once and the doors using the smart key from the vehicle exterior alarm...
Page 189 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the vehicle battery from being discharged while the vehicle is not in operation for a long time. ●...
Page 190 3-2. Opening, closing and locking the doors ■ Conditions affecting operation The smart entry & start system uses weak radio waves. In the following situa- tions, the communication between the electronic key and the vehicle may be affected, preventing the smart entry & start system, wireless remote control and engine immobilizer system from operating properly.
Page 191 3-2. Opening, closing and locking the doors ■ Note for the entry function Even when the electronic key is within the effective range (detection areas), ● the system may not operate properly in the following cases: • The electronic key is too close to the window or outside door handle, near the ground, or in a high place when the doors are locked or unlocked.
Page 192 ● Unlocking the vehicle may take more time if another electronic key is within the effective range. : This setting can be customized at your Toyota dealer. ■ When the vehicle is not driven for extended periods To prevent theft of the vehicle, do not leave the electronic key within 2 m ●...
Page 193 3-2. Opening, closing and locking the doors ■ Certification  For vehicles sold in Pakistan  For vehicles sold in Taiwan LC150_OM_OM60R93E_(GE)
Page 194 3-2. Opening, closing and locking the doors  For vehicles sold in the Dominican Republic  For vehicles sold in Jamaica  For vehicles sold in South Africa LC150_OM_OM60R93E_(GE)
Page 195 3-2. Opening, closing and locking the doors  For vehicles sold in Nigeria  For vehicles sold in Tahiti LC150_OM_OM60R93E_(GE)
Page 196 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 197 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 198 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 199 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 200 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 201 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 202 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 203 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 204 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 205 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 206 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 207 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 208 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 209 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 210 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 211 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 212 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 213 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 214 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 215 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 216 3-2. Opening, closing and locking the doors LC150_OM_OM60R93E_(GE)
Page 217 (P. 185) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 218: Adjusting The Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Vertical height adjustment lever (driver’s side only) Seatback angle adjustment lever Lumbar support adjustment switch (driver’s side only) Power seat  Seat position adjustment switch Vertical height adjustment...
Page 219 3-3. Adjusting the seats Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for- ward and upward to help reduce the risk of whiplash on the seat occupant. Moving a front passenger’s seat for second seat access (3-door models) Getting in the vehicle...
Page 220 3-3. Adjusting the seats ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may appear the head restraint inner structure. These do not indicate problems. During rear-end collision...
Page 221: Rear Seats
3-3. Adjusting the seats  Rear seats Adjustment procedure Second seat ■  3-door models (if equipped) Seatback angle adjustment lever  5-door models, type A (if equipped) Seatback angle adjustment lever 5-door models, type B (if equipped)  Seatback angle adjustment lever Seat position...
Page 222 3-3. Adjusting the seats Third seat ■ Power seat (if equipped)  Seatback angle adjustment switch Moving a second seat for third seat or luggage compartment access (5-door models, type B) Getting in the vehicle (right side only [left-hand drive vehicles] ■...
Page 223 3-3. Adjusting the seats Tumbling the second seats (3-door models) Before tumbling the second seats ■ Lower the head restraints to the lowest position. Use the seat belt hangers to prevent the belts from being tangled. Make sure that the seat belts are removed from the hangers before using them.
Page 224 3-3. Adjusting the seats Tumbling the second seats ■ Pull the seatback angle lever and fold them down. Pull the seat lock release lever on the back and swing the whole seat up and for- ward. Returning the second seats ■...
Page 225 3-3. Adjusting the seats Folding down the second seatbacks (5-door models, type A) Before folding down the second seatbacks ■ Stow the center seat belt buckle with the hook-and-loop fastener and lower the head restraints to the lowest position. Folding down second seatbacks ■...
Page 226 3-3. Adjusting the seats Folding down the second seatbacks (5-door models, type B) Before folding down the second seatbacks ■ Lower the head restraints to the lowest position. Folding down second seatbacks ■ Pull the seatback lock release lever and fold them down. To return the second seatbacks to their original positions, lift them up until they lock.
Page 227 3-3. Adjusting the seats ■ Folding down second center seatback only (5-door models) Pull the center seatback lock release lever behind the seatback and fold it down. To return the center seatback to its origi- nal position, lift it up until it locks. If you cannot raise the seatback ■...
Page 228 3-3. Adjusting the seats Folding the third seats (longitudinal type seat) Folding the third seats ■ Swing the seat cushion fully Take the holding strap of its pocket on the back of the seatback and secure the seat hooking the strap onto the hook in the back of the seat cushion.
Page 229 3-3. Adjusting the seats Folding down the third seats (manual seat) Before folding down the third seats ■ Lower the head restraints to the lowest position. Pass the seat belts through the seat belt hangers and secure the seat belt plates. This prevents the shoulder belt from being damage.
Page 230 3-3. Adjusting the seats  From rear door side Pull the seat cushion lock release lever. The seat cushion is stowed automatically. Pull seatback lock release lever and fold them down. Returning the third seats ■ From rear door side, unlock the seatbacks by pulling the lock release lever, and lift them up until they lock.
Page 231 3-3. Adjusting the seats Folding down the third seats (power seat)  Left-hand drive vehicles  Right-hand drive vehicles Right seat return switch Right seat fold switch Left seat return switch Left seat fold switch The switches can be operated from both the rear door side and the back door side.
Page 232 3-3. Adjusting the seats Folding down the third seats ■ Press and hold . Two beeps sound and the seat- back will rise. When operating is completed, two beeps sound again. Press and hold again. Two beeps sound, the head restraints will fold forward, and the seat will be stowed.
Page 233 3-3. Adjusting the seats ■ The third power seats can be operated when ● The engine switch is off. ● The shift lever is in P position (vehicles with an automatic transmission) or the parking brake is applied (vehicles with a manual transmission) with the engine switch in IGNITION ON mode.
Page 234 3-3. Adjusting the seats WARNING When folding the seatbacks down ■ Observe the following precautions. Failure to do so may result in death or serious injury. Do not fold the seatbacks down while driving. ● Stop the vehicle on level ground, set the parking brake and shift the shift ●...
Page 235 3-3. Adjusting the seats WARNING When stowing the third seats ■ Observe the following precautions. Failure to do so may result in death or serious injury. Check that there is no luggage and that there are no other people around ●...
Page 236: Driving Position Memory
3-3. Adjusting the seats  Driving position memory This feature automatically adjusts the driver’s seat, steering wheel and outside rear view mirrors to suit your preferences. Driving position memory Your preferred driving position (the position of the driver’s seat, steer- ing wheel and outside rear view mirrors) can be memorized and recalled with the touch of a button.
Page 237 3-3. Adjusting the seats Recall procedure ■ Vehicles with an automatic transmission: Check that the shift lever is in P. Vehicles with a manual transmission: Check that the parking brake is set. Vehicles without a smart entry & start system: Turn the engine switch to the “ON”...
Page 238 3-3. Adjusting the seats Memory recall function (vehicles with a smart entry & start sys- tem) Each electronic key can be registered to recall your preferred driving position. Registering procedure ■ Record your driving position to button “1” or “2” before performing the following: Carry only the key to which you want to register, and then close the driver’s door.
Page 239 3-3. Adjusting the seats Cancelation procedure ■ Carry only the key you want to cancel and then close the driver’s door. If 2 or more keys are in the vehicle, the driving position cannot be canceled properly. Turn the engine switch to IGNITION ON mode. While pressing “SET”...
Page 240: Head Restraints
3-3. Adjusting the seats Head restraints Front, second and third manual seats (if equipped) Lock release button Pull the head restraints up. Down Push the head restraint down while pushing the lock release button. Third power seats (if equipped) To fold the head restraints, pull the lock release strap.
Page 241 3-3. Adjusting the seats ■ Installing the head restraints (front, second and third manual seats) Align the head restraint with the installa- tion holes and push it down to the lock position. Press and hold the lock release button when lowering the head restraint. : If equipped Adjusting the height of the head restraints ■...
Page 242 3-3. Adjusting the seats WARNING Head restraint precautions ■ Observe the following precautions regarding the head restraints. Failure to do so may result in death or serious injury. Use the head restraints designed for each respective seat. ● Adjust the head restraints to the correct position at all times. ●...
Page 243: Steering Wheel
3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Manual adjustment type  Hold the steering wheel and pull the lever down. Adjust to the ideal position by moving the steering wheel hori- zontally and vertically. After adjustment, pull the lever up to secure the steering wheel.
Page 244 3-4. Adjusting the steering wheel and mirrors Auto tilt away (power adjustment type) When the engine switch is turned off, the steering wheel returns to its stowed position by moving up and away to enable easier driver entry and exit. Turning the engine switch...
Page 245 3-4. Adjusting the steering wheel and mirrors WARNING Caution while driving ■ Do not adjust the steering wheel while driving. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury. After adjusting the steering wheel (manual adjustment type) ■...
Page 246: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror The height of the rear view mirror can be adjusted to suit your driving posture.
Page 247 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode On/off When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 248: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure Left-hand drive vehicles (type A)  To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left LC150_OM_OM60R93E_(GE)
Page 249 3-4. Adjusting the steering wheel and mirrors  Left-hand drive vehicles (type B) To select a mirror to adjust, press the switch. Left Right To adjust the mirror, press the switch. Right Down Left  Right-hand drive vehicles To select a mirror to adjust, turn the switch.
Page 250 3-4. Adjusting the steering wheel and mirrors Folding and extending the mirrors  Left-hand drive vehicles (type A) Press the switch to fold the mir- rors. Press it again to extend them to the original position.  Left-hand drive vehicles (type B) Automatic mode allows the folding or extending of the mirrors to be linked to locking/unlocking of the doors.
Page 251 3-4. Adjusting the steering wheel and mirrors Linked mirror function when reversing (if equipped) When the mirror select switch is in the L or R position, the outside rear view mirrors will automatically angle downwards when the vehicle is reversing in order to give a better view of the ground. To disable this function, move the mirror select switch to the neutral position (between L and R).
Page 252 3-4. Adjusting the steering wheel and mirrors ■ Automatic adjustment of the mirror angle (vehicles with driving position memory) A desired mirror face angle can be entered to memory and recalled automati- cally by the driving position memory. (P. 235) ■...
Page 253: Power Windows
3-5. Opening and closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Closing One-touch closing Opening One-touch opening : To stop the window partway, oper- ate the switch in the opposite direc- tion.
Page 254 3-5. Opening and closing the windows and moon roof ■ The power windows can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 255 Door lock linked window operation ■ The power windows can be opened and closed using the wireless remote control or key if customized at your Toyota dealer. (P. 163, 164) ■ Customization Settings (e.g. linked door lock operation) can be changed.
Page 256 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may result in death or serious injury. ■ Closing the windows The driver is responsible for all the power window operations, including the ●...
Page 257: Moon Roof
3-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 258 ■ Door lock linked moon roof operation The moon roof can be opened and closed using the wireless remote control or key if customized at your Toyota dealer. (P. 163, 164) Moon roof open reminder function ■ An alarm will sound when the driver’s door is opened with the moon roof not fully closed and the engine switch off.
Page 259 If the moon roof does not fully close even after performing the above proce- dure correctly, have the vehicle inspected by your Toyota dealer. Customization ■...
Page 260 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 261 3-5. Opening and closing the windows and moon roof LC150_OM_OM60R93E_(GE)
Page 262: Driving
......354 Cargo and luggage ....274 4-5. Using the driving support Trailer towing systems (with towing hitch)....277 Toyota Safety Sense ..358 4-2. Driving procedures PCS (Pre-Crash Safety Engine (ignition) switch system) ......365 (vehicles without a smart entry & start system)..291 LDA (Lane Departure Alert) ........378...
Page 263: 4-1. Before Driving
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 291, 295 Driving  Automatic transmission With the brake pedal depressed, shift the shift lever to D. (P. 305) Release the parking brake. (P. 317) Gradually release the brake pedal and gently depress the accelera- tor pedal to accelerate the vehicle.
Page 264 4-1. Before driving Parking the vehicle  Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake (P. 317), and shift the shift lever to P (P. 305). Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 265 4-1. Before driving Starting off on a steep uphill  Automatic transmission Make sure that the parking brake is set and shift the shift lever to D. Gently depress the accelerator pedal. Release the parking brake.  Manual transmission With the parking brake firmly set and the clutch pedal fully depressed, shift the shift lever to 1.
Page 266 • Put the four-wheel drive control switch in H4L or L4L. : Refer to the “Off-road Driving Owner’s Manual” ■ Breaking in your new Toyota To extend the life of the vehicle, observing the following precautions is recom- mended: ●...
Page 267 This type of brake system needs bedding-down of the brake shoes periodi- cally or whenever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding-down operation. ■ Idling time before stopping the engine (1KD-FTV and 1GD-FTV engines) To prevent damage to the turbocharger, allow the engine to idle immediately after high-speed driving or driving up a hill.
Page 268 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving the vehicle Do not drive if you are unfamiliar with the location of the brake and accel- ● erator pedals to avoid depressing the wrong pedal.
Page 269 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and ● reduce your ability to control the vehicle. Sudden acceleration, engine braking due to shifting, or changes in engine ●...
Page 270 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 271 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in ● the vehicle when it is in the sun. Doing so may result in the following: •...
Page 272 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 273 4-1. Before driving NOTICE When driving the vehicle ■  Automatic transmission ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain the engine output. Do not use the accelerator pedal or depress the accelerator and brake ●...
Page 274 ● Engine damage caused by water immersion In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: ● Brake function Changes in quantity and quality of oil and fluid used for the engine, trans- ●...
Page 275: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: Roof luggage carrier (if equipped) Roof luggage carrier components ■ Roof rail Cross rail WARNING ■ Things that must not be carried in the luggage compartment The following things may cause a fire if loaded in the luggage compartment: ●...
Page 276 4-1. Before driving WARNING Storage precautions ■ Observe the following precautions. Failure to do so may prevent the pedals from being depressed properly, may block the driver’s vision, or may result in items hitting the driver or pas- sengers, possibly causing an accident. Stow cargo and luggage in the luggage compartment whenever possible.
Page 277 ■ To use the roof rails as a roof luggage carrier, you must fit the roof rails with two or more genuine Toyota cross rails or their equivalent. Follow the manufacturer’s instructions and precautions when installing the cross rails or their equivalent.
Page 278: Trailer Towing (With Towing Hitch)
MPAC (Maximum Permissible Axle Capacity), and permissible drawbar load before towing. (P. 787) ◆ Towing hitch/bracket Toyota recommends the use of the Toyota hitch/bracket for your vehicle. Other products of a suitable nature and comparable quality may also be used. ◆...
Page 279 4-1. Before driving Selecting a trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer cou- pler. Most couplers are stamped with the required trailer ball size.
Page 280 4-1. Before driving Important points regarding trailer loads Total trailer weight and permissible drawbar load ■ Total trailer weight Weight of the trailer itself plus the trailer load should be within the maximum towing capacity. Exceeding this weight is danger- ous.
Page 281 The values for towing capacity were derived from testing conducted at sea level. Take note that engine output and towing capacity will be reduced at high altitudes. : To distinguish the vehicle category, ask your Toyota dealer.  Type A ...
Page 282 Do not exceed the established speed limit for towing a trailer in built-up areas or 100 km/h (62 mph), whichever is lower. Failing to observe this precaution may lead to an accident causing death or serious injury. : To distinguish the vehicle category, ask your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 283 4-1. Before driving Installation positions for the towing hitch/bracket and hitch ball  5-door models 78 mm (3.0 in.) 78 mm (3.0 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 1219 mm (48.0 in.) 137 mm (5.4 in.) 141 mm (5.6 in.) 79 mm (3.1 in.)
Page 284 4-1. Before driving  3-door models 78 mm (3.0 in.) 78 mm (3.0 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 53 mm (2.1 in.) 1110 mm (43.7 in.) 142 mm (5.6 in.) 84 mm (3.3 in.) 59 mm (2.3 in.) 327 mm (12.9 in.) 199 mm (7.8 in.)
Page 285 4-1. Before driving ■ When connecting and disconnecting a trailer (vehicles with rear height control air suspension) Connecting ● Set the rear height control air suspension to LO mode. Turn off the engine switch or the rear height control air suspension. Connect the trailer.
Page 286 ■ Break-in schedule Toyota recommends that vehicles fitted with new power train components should not be used for towing trailers for the first 800 km (500 miles). Safety checks before towing ■...
Page 287 4-1. Before driving ■ Maintenance Maintenance must be performed more frequently when using the vehicle for ● towing due to the greater weight burden placed on the vehicle compared to normal driving. ● Retighten all bolts securing the hitching ball and bracket after towing for approximately 1000 km (600 miles).
Page 288 4-1. Before driving WARNING For GRJ150L-GKTEKQ models ● The gross combined weight (sum of your vehicle weight plus its load and the total trailer weight) must not exceed the following (except for when using a weight carrying hitch): TX-L grade: 5440 kg (11993 lb.) 5360 kg (11817 lb.) VX grade: 5330 kg (11751 lb.)
Page 289 4-1. Before driving Guidance Your vehicle will handle differently when towing a trailer. In order to avoid accident, death or serious injury, keep the following in mind when towing: Checking connections between trailer and lights ■ Stop the vehicle and check the operation of the connection between the trailer and lights after driving for a brief period as well as before starting off.
Page 290 4-1. Before driving Sudden acceleration/steering input/cornering ■ Executing sharp turns when towing may result in the trailer colliding with your vehicle. Decelerate well in advance when approaching turns and take them slowly and carefully to avoid sudden braking. Important points regarding turning ■...
Page 291 4-1. Before driving If the engine overheats ■ Towing a loaded trailer up a long, steep incline in temperatures exceeding 30C (85F) may result in the engine overheating. If the engine coolant temperature gauge indicates that the engine is over- heating, turn the air conditioning off immediately, leave the road and stop the vehicle in a safe place.
Page 292: Engine (Ignition) Switch (Vehicles Without A
4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine  Automatic transmission (gasoline engine) Check that the parking brake is set. Check that the shift lever is set in P. Firmly depress the brake pedal. Turn the engine switch to the “START”...
Page 293 4-2. Driving procedures  Manual transmission (gasoline engine) Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal. Turn the engine switch to the “START” position to start the engine. ...
Page 294 “LOCK” position. ■ If the engine does not start The engine immobilizer system may not have been deactivated. (P. 88) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 295 Do not crank the engine for more than 30 seconds at a time. This may ● overheat the starter and wiring system. ● Do not race a cold engine. If the engine becomes difficult to start or stalls frequently, have your vehi- ● cle checked by your Toyota dealer immediately. LC150_OM_OM60R93E_(GE)
Page 296: Engine (Ignition) Switch (Vehicles With A Smart Entry & Start System)
4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch modes. Starting the engine  Automatic transmission Check that the parking brake is set.
Page 297 4-2. Driving procedures  Manual transmission Check that the parking brake is set. Check that the shift lever is set in N. Firmly depress the clutch pedal. Vehicles with the multi-information display type A: The smart entry & start system indicator (green) will turn on. If the indicator does not turn green, the engine cannot be started.
Page 298 4-2. Driving procedures Stopping the engine  Automatic transmission Stop the vehicle. Set the parking brake (P. 317), and shift the shift lever to P. Press the engine switch. Release the brake pedal and check that the indicator on the instru- ment cluster is off.
Page 299 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal (vehicles with an automatic transmission) or clutch pedal (vehi- cles with a manual transmission) released. (The mode changes each time the switch is pressed.) ...
Page 300 4-2. Driving procedures  Vehicles with the multi-information display type B The emergency flashers can be used. ACCESSORY mode Some electrical components such as the audio system can be used. “ACCESSORY” will be displayed on the multi-information display. IGNITION ON mode All electrical components can be used.
Page 301 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (Vehicles with an automatic transmission) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 302 ■ ● The engine immobilizer system may not have been deactivated. (P. 88) Contact your Toyota dealer. Vehicles with an automatic transmission only: ● Check that the shift lever is securely set in P. The engine may not start if the shift lever is displaced out of P.
Page 303 When the smart entry & start system indicator light flashes in yellow (vehicles with the multi-information display type A) The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ When “Check entry & start system Have your vehicle checked by a dealer”...
Page 304 4-2. Driving procedures WARNING When starting the engine ■ Always start the engine while sitting in the driver’s seat. Do not depress the accelerator pedal while starting the engine under any circumstances. Doing so may cause an accident resulting in death or serious injury. Caution while driving ■...
Page 305 Do not race a cold engine. ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. ■ Symptoms indicating a malfunction with the engine switch If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 306: Automatic Transmission
4-2. Driving procedures  Automatic transmission Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 307 4-2. Driving procedures Shift position purpose Shift position Purpose and condition Parking the vehicle/starting the engine Reversing Neutral (Condition in which the power is not transmitted) Normal driving S mode driving (P. 307) : Shifting to the D position allows the system to select a gear suitable for the driving conditions.
Page 308 4-2. Driving procedures Changing shift ranges in S mode When the shift lever is in the S position, the shift lever can be oper- ated as follows: Upshifting Type A Type B Downshifting 5-speed models: The selected shift range, from 1 to 5, will be displayed in the meter.
Page 309 4-2. Driving procedures ■ Driving on a downhill On declines, there may be case where the vehicle shifts down automatically to obtain engine braking. As a result of the downshifting, the engine speed may increase. ■ Second start mode automatic deactivation Second start mode is automatically deactivated if the engine is turned off after driving in second start mode.
Page 310 If the “S” indicator does not come on even after shifting the shift lever to ■ This may indicate a malfunction in the automatic transmission system. Have the vehicle inspected by your Toyota dealer immediately. ■ Downshift restriction warning buzzer (S mode) To help ensure safety and driving performance, downshifting operation may sometimes be restricted.
Page 311 4-2. Driving procedures ■ Transmission protection function (6-speed models) If the tires spin continually when the vehicle becomes stuck in mud, dirt or snow, or if the accelerator pedal is depressed and released repeatedly while driving, the automatic transmission temperature may become too high and the automatic transmission may be damaged.
Page 312: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever 5-speed transmission  Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 313 4-2. Driving procedures  6-speed transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Gear Shift Indicator (if equipped) The Gear Shift Indicator display is a guide to help the driver achieve improved fuel economy and reduced exhaust emissions within limits of engine performance.
Page 314 4-2. Driving procedures ■ Gear Shift Indicator display (if equipped) ● The Gear Shift Indicator will not be displayed when the four-wheel drive con- trol switch is in L4. ● The Gear Shift Indicator may not be displayed when your foot is placed on the clutch pedal.
Page 315 4-2. Driving procedures  6-speed transmission Maximum speed (km/h [mph]) Shift Model code Transfer position Transfer position position 50 (31) 20 (12) 96 (60) 37 (23) GRJ150L-GKFEK 141 (88) 55 (34) GRJ150L-GKFEKV 176 (109) 69 (43) 180 (112) 82 (51) 38 (24) 15 (9) 77 (48)
Page 316 4-2. Driving procedures NOTICE To prevent damage to the transmission ■ ● Do not shift the shift lever to R without depressing the clutch pedal. ● Shift the lever to R only when the vehicle is stationary. LC150_OM_OM60R93E_(GE)
Page 317: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operating instructions The turn signal lever can be used to show the following intentions of the driver: Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 318: Parking Brake
4-2. Driving procedures Parking brake To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button. ■ Parking the vehicle P.
Page 319: Diesel Particulate Filter System (1Gd-Ftv Engine Only)
4-2. Driving procedures Diesel Particulate Filter system (1GD-FTV engine only) When the deposit collected by the filter reaches a predetermined amount, it is automatically regenerated. ◆ Regeneration Regeneration is performed as necessary in accordance with driving conditions. ◆ System characteristics The DPF system has the following characteristics: ●...
Page 320 4-2. Driving procedures DPF system failure warning ● If the DPF system warning light comes on (vehicles with the multi- information display type A) or the DPF system warning message “DPF full Manual regeneration required See owner’s manual” appears on the display (vehicles with the multi-information display type B), follow the procedure below to regenerate.
Page 321 ● If the DPF system warning light flashes (vehicles with the multi- information display type A) or the DPF system warning message “DPF full Visit your dealer” appears on the display (vehicles with the multi-information display type B), have the vehicle inspected by your Toyota dealer immediately. LC150_OM_OM60R93E_(GE)
Page 322 4-2. Driving procedures ■ Regeneration with the DPF system switch ● After pressing the DPF system switch, do not depress the accelerator pedal or the clutch pedal (manual transmission). Depressing the pedal(s) will stop regeneration. If regeneration has been stopped, restart regeneration as soon as possible.
Page 323 A), or the DPF warning message “DPF full Visit your dealer” appears on the display (vehicles with the multi-information display type B). In this event, damage may be caused to the vehicle or an accident may occur. Have the vehicle inspected by your Toyota dealer immediately. LC150_OM_OM60R93E_(GE)
Page 324 4-2. Driving procedures NOTICE To prevent the DPF system from failing ■ ● Vehicles with the multi-information display type A: Do not drive for long periods of time while the DPF system warning light is flashing. Vehicles with the multi-information display type B: Do not drive for long ●...
Page 325: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually or automatically. Operating instructions Operating the switch turns on the lights as follows:  Type A Vehicles without day- time running light sys- tem: Off. Vehicles with daytime running light system:...
Page 326 4-3. Operating the lights and wipers  Type B Vehicles without a smart entry & start system: headlights, front position lights, daytime running lights (P. 333) and so on turn on and off automatically (when the engine switch is in the “ON”...
Page 327 4-3. Operating the lights and wipers Turning on the high beam headlights With the headlights on, push the lever away from you to turn on the high beams. Pull the lever toward you to the center position to turn the high beams off.
Page 328 4-3. Operating the lights and wipers Guide to dial settings ■ 10-seat models  Occupancy and luggage load conditions Without load Driver and full luggage loading in the luggage room Model code Type With sub fuel tank LJ150L-GKMEE LJ150R-GKMEE Without sub fuel tank : The model code is indicated on the manufacturer’s label or Certification Regulation label.
Page 329 4-3. Operating the lights and wipers  9-seat models Occupancy and luggage load conditions Driver only, or Driver and one passenger in the front seat Driver, one passenger in the front seat, and all passengers in the rear seats farthest to the rear All passengers All passengers and full luggage loading in the luggage room Driver and full luggage loading in the luggage room...
Page 330 4-3. Operating the lights and wipers  7-seat models Occupancy and luggage load conditions Driver only, or Driver and one passenger in the front seat Driver, one passenger in the front seat, and all passengers in the rear seats farthest to the rear All passengers All passengers and full luggage loading in the luggage room Driver and full luggage loading in the luggage room...
Page 331 4-3. Operating the lights and wipers Model code Type With fuel tank TX grade Without sub 2.5 3.5 4.5 fuel tank KDJ150L-GKAEYV With fuel tank TX-L grade Without sub fuel tank KDJ150L-GKAEYW KDJ150L-GKFEYW With sub fuel tank 3.5 3.5 LJ150L-GKMEE LJ150R-GKMEE Without sub fuel tank With sub fuel tank...
Page 332 4-3. Operating the lights and wipers  5-seat models Occupancy and luggage load conditions Driver only, or Driver and one passenger in the front seat Driver, one passenger in the front seat, and all passengers in the rear seats farthest to the rear All passengers All passengers and full luggage loading in the luggage room Driver and full luggage loading in the luggage room...
Page 333 4-3. Operating the lights and wipers Model code Type TRJ150L-GKMEK With sub fuel tank 3.5 3.5 TRJ150L-GKTEK TRJ150L-GKMEKV Without sub fuel tank TRJ150L-GKTEKV TRJ155L-GJTEKV : The model code is indicated on the manufacturer’s label or Certification Regulation label. (P. 789) LC150_OM_OM60R93E_(GE)
Page 334 4-3. Operating the lights and wipers ■ Daytime running light system (if equipped) To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the engine is started and the parking brake is released with the headlight switch off or in the “AUTO”...
Page 335 4-3. Operating the lights and wipers  Type B ● Vehicles without a smart entry & start system • When only the tail lights are on: All lights turn off automatically if the engine switch is turned to the “ACC” or “LOCK”...
Page 336 If the automatic headlight leveling system warning light flashes (if ■ equipped) It may indicate a malfunction in the system. Contact your Toyota dealer. Light reminder buzzer (if equipped) ■ A buzzer sounds when the engine switch is turned off or turned to ACCES- SORY mode and the driver’s door is opened while the tail lights remain on.
Page 337: Automatic High Beam
4-3. Operating the lights and wipers  Automatic High Beam The Automatic High Beam uses an in-vehicle camera sensor to assess the brightness of streetlights, the lights of vehicles ahead etc., and automatically turns the high beam on or off as necessary.
Page 338 4-3. Operating the lights and wipers Activating the Automatic High Beam system Push the lever away from you with the headlight switch in the position. Press the Automatic High Beam switch. The Automatic High Beam indica- tor will come on when the head- lights are turned on automatically to indicate that the system is active.
Page 339 4-3. Operating the lights and wipers Turning the high beam on/off manually Switching to low beam ■ Pull the lever to the original posi- tion. The Automatic High Beam indica- tor will turn off. Push the lever away from you to activate the Automatic High Beam system again.
Page 340 4-3. Operating the lights and wipers ■ High beam automatic turning on or off conditions ● When all of the following conditions are fulfilled, the high beam will be auto- matically turned on (after approximately 1 second): • Vehicle speed is above approximately 40 km/h (25 mph). •...
Page 341 4-3. Operating the lights and wipers ● In the situations shown below, the system may not be able to accurately detect surrounding brightness levels. This may cause the low beams to remain on or the high beams to cause problems for pedestrians, vehicles ahead or other parties.
Page 342: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Front fog light switch  Turns the front fog lights Turns the front fog lights ...
Page 343 4-3. Operating the lights and wipers  Front and rear fog light switch Turns the front and rear fog lights off Turns the front fog lights Turns both front and rear fog lights on Releasing the switch ring returns it Operating the switch ring again turns only the rear fog lights off.
Page 344 4-3. Operating the lights and wipers ■ Fog lights can be used when  Vehicles with a front and rear fog light Front fog lights: The headlights or front position lights are turned on. Rear fog lights: The front fog lights or headlights are turned on. ...
Page 345: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows.  Intermittent windshield wipers with interval adjuster Intermittent operation Low speed operation High speed operation Temporary operation LC150_OM_OM60R93E_(GE)
Page 346 4-3. Operating the lights and wipers Wiper intervals can be adjusted when intermittent operation is selected. Increases the intermittent wind- shield wiper frequency Decreases intermittent windshield wiper frequency Washer/wiper dual oper- ation Pulling the lever operates the wip- ers and washer. The wipers will automatically oper- ate a couple of times after the washer squirts.
Page 347 4-3. Operating the lights and wipers  Rain-sensing windshield wipers Rain-sensing operation (“AUTO”) Low speed operation High speed operation Temporary operation When “AUTO” is selected, the wip- ers will operate automatically when the sensor detects falling rain. The system automatically adjusts wiper timing in accordance with rain vol- ume and vehicle speed.
Page 348 4-3. Operating the lights and wipers The sensor sensitivity can be adjusted when “AUTO” is selected. Increases the sensitivity Decreases the sensitivity Washer/wiper dual oper- ation Pulling the lever operates the wip- ers and washer. The wipers operate automatically. (After operating several times, the wipers operate one more time after a short delay to prevent dripping.) Vehicles with headlight cleaners: If...
Page 349 4-3. Operating the lights and wipers ■ The windshield wiper and washer can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 350 4-3. Operating the lights and wipers WARNING Caution regarding the use of windshield wipers in “AUTO” mode (vehi- ■ cles with rain-sensing windshield wipers) The windshield wipers may operate unexpectedly if the sensor is touched or the windshield is subject to vibration in “AUTO” mode. Take care that your fingers or anything else does not become caught in the windshield wipers.
Page 351: Rear Window Wiper And Washer
4-3. Operating the lights and wipers Rear window wiper and washer Operating the wiper lever Operating the switch operates the rear wiper as follows: Intermittent operation Normal operation Washer/wiper dual oper- ation Pushing the lever operates the wiper and washer. The wipers will automatically oper- ate a couple of times after the washer squirts.
Page 352 4-3. Operating the lights and wipers ■ The rear window wiper and washer can be operated when ● Vehicles without a smart entry & start system: The engine switch is in the “ON” position. Vehicles with a smart entry & start system: The engine switch is in IGNI- TION ON mode.
Page 353: Headlight Cleaner Switch
4-3. Operating the lights and wipers  Headlight cleaner switch Washer fluid can be sprayed on the headlights. Press the switch to clean the headlights.  Left-hand drive vehicles  Right-hand drive vehicles ■ The headlight cleaners can be operated when ...
Page 354 4-3. Operating the lights and wipers ■ Windshield washer linked operation  Vehicles without a smart entry & start system When the windshield washer is operated with the engine switch is in the “ON” position and the headlight on, the headlight cleaners will operate once. (P.
Page 355: Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. Before refueling the vehicle ● Turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with smart entry & start system) and ensure that all the doors and windows are closed.
Page 356 4-4. Refueling WARNING When refueling the vehicle ■ Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. After exiting the vehicle and before opening the fuel door, touch an ● unpainted metal surface to discharge any static electricity.
Page 357: Refueling
4-4. Refueling NOTICE Refueling ■ Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control systems to operate abnormally or damaging fuel system components or the vehicle’s painted surface. Opening the fuel tank cap Pull up the opener to open the fuel filler door.
Page 358 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 359: Using The Driving Support
■ Toyota Safety Sense The Toyota Safety Sense is designed to operate under the assumption that the driver will drive safely, and is designed to help reduce the impact to the occupants and the vehicle in the case of a collision or assist the driver in normal driving conditions.
Page 360 Toyota will not disclose the recorded data to a third party except: • With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased •...
Page 361 4-5. Using the driving support systems Sensors Two types of sensors, located behind the front grille and windshield, detect information necessary to operate the drive assist systems. Radar sensor Camera sensor LC150_OM_OM60R93E_(GE)
Page 362 Do not subject the radar sensor or surrounding area to a strong impact. If the radar sensor, front grille, or front bumper has been subjected to a strong impact, have the vehicle inspected by your Toyota dealer. Do not disassemble the radar sensor.
Page 363 Do not attach window tinting to the windshield. Replace the windshield if it is damaged or cracked. ● If the windshield needs to be replaced, contact your Toyota dealer. ● Do not get the camera sensor wet. Do not allow bright lights to shine into the camera sensor.
Page 364 Do not attach any accessories that may obstruct the camera sensor to the hood, front grille or front bumper. Contact your Toyota dealer for details. If a surfboard or other long object is to be mounted on the roof, make sure ●...
Page 365 4-5. Using the driving support systems ■ Certification for the radar sensor  Vehicles sold in Taiwan LC150_OM_OM60R93E_(GE)
Page 366: Pcs (Pre-Crash Safety System)
The countries and areas for each region listed in the table are cur- rent as of August 2019. However, depending on when the vehicle was sold, the countries and areas of each region may be different. Contact your Toyota dealer.  : If equipped...
Page 367 4-5. Using the driving support systems ◆ Pre-crash warning When the system determines that the possibility of a frontal collision is high, a buzzer will sound and a warning message will be displayed on the multi- information display to urge the driver to take evasive action.
Page 368 4-5. Using the driving support systems WARNING Limitations of the pre-crash safety system ■ ● The driver is solely responsible for safe driving. Always drive safely, taking care to observe your surroundings. Do not use the pre-crash safety system instead of normal braking opera- tions under any circumstances.
Page 369 4-5. Using the driving support systems WARNING When to disable the pre-crash safety system ■ In the following situations, disable the system, as it may not operate prop- erly, possibly leading to an accident resulting in death or serious injury: When the vehicle is being towed ●...
Page 370 4-5. Using the driving support systems Changing settings of the pre-crash safety system Enabling/disabling the pre-crash safety system ■ The pre-crash safety system can be enabled/disabled on (P. 125) of the multi-information display. The system is automatically enabled each time the engine switch is turned to IGNITION ON mode.
Page 371 4-5. Using the driving support systems ■ Operational conditions Availability of the pedestrian detection function depends on the region in which the vehicle was sold. (For specific countries/areas: P. 365) Read the following for details:  Region A (The pedestrian detection function is available) The pre-crash safety system is enabled and the system determines that the possibility of a frontal collision with a vehicle or pedestrian is high.
Page 372 4-5. Using the driving support systems  Region B (The pedestrian detection function is not available) The pre-crash safety system is enabled and the system determines that the possibility of a frontal collision with a vehicle is high. Each function is operational at the following speeds: Pre-crash warning: ●...
Page 373 4-5. Using the driving support systems ■ Cancelation of the pre-crash braking If either of the following occur while the pre-crash braking function is operat- ing, it will be canceled: The accelerator pedal is depressed strongly. ● ● The steering wheel is turned sharply or abruptly. Conditions under which the system may operate even if there is no pos- ■...
Page 374 4-5. Using the driving support systems • When there is a vehicle, pedes- trian , or object by the roadside at the entrance of a curve • When driving on a narrow path surrounded by a structure, such as in a tunnel or on an iron bridge •...
Page 375 4-5. Using the driving support systems • When driving through under objects that may contact the vehicle, such as thick grass, tree branches, or a banner • When the vehicle is hit by water, snow, dust, etc. from a vehicle ahead •...
Page 376 4-5. Using the driving support systems • If a vehicle ahead is irregularly shaped, such as a tractor or side car • If the sun or other light is shining directly on a vehicle ahead • If a vehicle cuts in front of your vehicle or emerges from beside a vehicle •...
Page 377 4-5. Using the driving support systems ● In some situations such as the following, sufficient braking force may not be obtained, preventing the system from performing properly: • If the braking functions cannot operate to their full extent, such as when the brake parts are extremely cold, extremely hot, or wet •...
Page 378 ● warning message does not disappear even though the vehicle has returned to normal, the system may be malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ If VSC is disabled If VSC is disabled (P. 457), the pre-crash brake assist and pre-crash brak- ●...
Page 379: Lda (Lane Departure Alert)
4-5. Using the driving support systems  LDA (Lane Departure Alert) Summary of functions When driving on roads with white (yellow) lines, this function alerts the driver when the vehicle might depart from its lane. The LDA system recognizes visi- ble white (yellow) lines with the camera sensor on the upper por- tion of the front windshield.
Page 380 4-5. Using the driving support systems ◆ Vehicle sway warning function When the vehicle is swaying or appears as if it may depart from its lane multiple times, the warning buzzer sounds and a message is displayed on the multi-information display to alert the driver.
Page 381 Toyota dealer. Do not install or place anything on the hood or grille. Also, do not install a ● grille guard (bull bars, kangaroo bar, etc.). ● If your windshield needs repairs, contact your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 382 4-5. Using the driving support systems Turning LDA system on Press the LDA switch to turn the LDA system on. The LDA indicator illuminates and a message is displayed on the multi-information display. Press the LDA switch again to turn the LDA system off.
Page 383 4-5. Using the driving support systems Indications on multi-information display LDA indicator Illuminates when the LDA system is on. Lane departure alert function display Displayed when the multi-informa- tion display is switched to the driv- assist system information screen.  Inside of displayed white lines ...
Page 384 4-5. Using the driving support systems ■ Operation conditions of each function ● Lane departure alert function This function operates when all of the following conditions are met. • LDA is turned on. • Vehicle speed is approximately 50 km/h (32 mph) or more. •...
Page 385 4-5. Using the driving support systems ■ Conditions in which functions may not operate properly In the following situations, the camera sensor may not detect white (yellow) lines and various functions may not operate normally. There are shadows on the road that run parallel with, or cover, the white ●...
Page 386 The system may not be operating Alert properly.  Have the vehicle inspected at your Malfunction Visit Your Dealer” Toyota dealer. Dirt, rain, condensation, ice, snow, etc. are present on the windshield in “Forward Camera front of the camera sensor. System ...
Page 387 4-5. Using the driving support systems ■ Customization The following settings can be changed. Function Setting details Lane departure alert function Adjust alert sensitivity Turn function on and off Vehicle sway warning function Adjust alert sensitivity For how to change settings, refer to P. 826. LC150_OM_OM60R93E_(GE)
Page 388: Dynamic Radar Cruise Control
4-5. Using the driving support systems  Dynamic radar cruise control Summary of functions In vehicle-to-vehicle distance control mode, the vehicle automatically accelerates and decelerates to match the speed changes of the pre- ceding vehicle even if the accelerator pedal is not depressed. In con- stant speed control mode, the vehicle runs at a fixed speed.
Page 389 4-5. Using the driving support systems WARNING Before using dynamic radar cruise control ■ ● Driving safely is the sole responsibility of the driver. Do not rely solely on the system, and drive safely by always paying careful attention to your sur- roundings.
Page 390 4-5. Using the driving support systems WARNING Cautions regarding the driving assist systems ■ Observe the following precautions, as there are limitations to the assistance provided by the system. Failure to do so may cause an accident resulting in death or serious injury. Assisting the driver to measure following distance ●...
Page 391 4-5. Using the driving support systems WARNING Situations unsuitable for dynamic radar cruise control ■ Do not use dynamic radar cruise control in any of the following situations. Doing so may result in inappropriate speed control and could cause an acci- dent resulting in death or serious injury.
Page 392 4-5. Using the driving support systems Driving in vehicle-to-vehicle distance control mode This mode employs a radar sensor to detect the presence of vehicles up to approximately 100 m (328 ft.) ahead, determines the current vehicle-to-vehicle following distance, and operates to maintain a suit- able following distance from the vehicle ahead.
Page 393 4-5. Using the driving support systems Setting the vehicle speed (vehicle-to-vehicle distance control mode) Press the “ON-OFF” button to activate the cruise control. Radar cruise control indicator will come on and a message will be displayed on the multi-information display. Press the button again to deacti- vate the cruise control.
Page 394 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is displayed. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 395 4-5. Using the driving support systems Changing the vehicle-to-vehicle distance (vehicle-to-vehicle dis- tance control mode) Pressing the switch changes the Preceding vehicle-to-vehicle distance as fol- vehicle mark lows: Long Medium Short The vehicle-to-vehicle distance is set automatically to long mode when the engine switch is turned to IGNITION ON mode.
Page 396 4-5. Using the driving support systems Canceling and resuming the speed control Pulling the lever toward you cancels the speed control. The speed control is also canceled when brake pedal depressed. Pushing the lever up resumes the cruise control and returns vehicle speed to the set speed.
Page 397 4-5. Using the driving support systems Selecting constant speed control mode When constant speed control mode is selected, your vehicle will main- tain a set speed without controlling the vehicle-to-vehicle distance. Select this mode only when vehicle-to-vehicle distance control mode does not function correctly due to a dirty radar sensor, etc.
Page 398 Switching operation to center differential lock mode continues for 5 seconds or more after operating the center differential lock/unlock switch. If vehicle-to-vehicle distance control mode is automatically canceled for any other reason, there may be a malfunction in the system. Contact your Toyota dealer. ■...
Page 399 4-5. Using the driving support systems ■ Brake system operation sound If the brakes are applied automatically while the vehicle is in vehicle-to-vehi- cle distance control mode, a brake system operation sound may be heard. This does not indicate a malfunction. ■...
Page 400 4-5. Using the driving support systems ● Preceding vehicle has an extremely high ground clearance ■ Conditions under which the vehicle-to-vehicle distance control mode may not function correctly In the case of the following conditions, operate the brake pedal (or accelera- tor pedal, depending on the situation) as necessary.
Page 401: Cruise Control
4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 402 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 403 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 404 4-5. Using the driving support systems WARNING To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 405: Driving Mode Select Switches
4-5. Using the driving support systems  Driving mode select switches The driving modes can be selected to suit driving condition.  Type A Normal mode For normal driving. Press the “NORMAL” switch to change the driving mode to normal mode when selected to Eco drive mode or sport mode.
Page 406 4-5. Using the driving support systems  Type B Normal mode For normal driving. Press the “NORMAL” switch to change the driving mode to normal mode when not in normal mode. Comfort mode By controlling the suspension, riding comfort is further enhanced. Suitable for city driving.
Page 407 4-5. Using the driving support systems Eco drive mode Use Eco drive mode to help achieve low fuel consumption during trips that involve frequent accelerating. When in comfort mode and the “COMF ECO” switch is pressed, the “ECO” indicator comes on in the multi-information display. Sport mode •...
Page 408: Toyota Parking Assist-Sensor
Rear corner sensors Rear center sensors Toyota parking assist-sensor switch Left-hand drive Right-hand drive   Turns Toyota parking assist-sensor on/off When on, the indicator light come on to inform the driver that the system is operational.  : If equipped LC150_OM_OM60R93E_(GE)
Page 409 Display When the sensors detect an obstacle, the following indicator or dis- plays inform the driver of the position and distance to the obstacle.  Toyota parking assist-sensor indicator (if equipped) Vehicle indicator Rear corner indicator Rear center indicator ...
Page 410 4-5. Using the driving support systems  Navigation system or multimedia system screen (if equipped) Toyota parking assist-sensor display When the Toyota parking assist monitor or Multi-terrain Monitor is not displayed. A graphic is automatically dis- played when obstacle detected. The screen can be set so that the graphic is not displayed.
Page 411 4-5. Using the driving support systems Sensor detection display, obstacle distance Distance display ■ Sensors that detect an obstacle will illuminate continuously or blink. Approximate distance to obstacle Insert Front corner Rear corner Indicator Display display sensor/front sensor/rear center sensor center sensor Front center Rear center...
Page 412 4-5. Using the driving support systems : Except for 4 sensor type : Multi-information display : Navigation system or multimedia system screen Buzzer operation and distance to an obstacle ■ A buzzer sounds when the sensors are operating. ● The buzzer sounds faster as the vehicle approaches an obstacle. When the vehicle comes within the following distance of the obstacle, the buzzer sounds continuously.
Page 413 Select the desired item. ● The buzzer sound volume can be adjusted. ● On or off can be selected for Toyota parking assist-sensor display. ● Front or rear center sensors display and tone indication can be set. ■ The Toyota parking assist-sensor can be operated when Front corner sensors: ●...
Page 414 ■ Toyota parking assist-sensor display When an obstacle is detected while the Toyota parking assist monitor or Multi-terrain Monitor is in use, the warning indicator will appear in the upper corner of the screen even if the display setting has been set to off.
Page 415 • When an object is directly under the bumper. • When objects become too close to the sensors. • When a non-genuine Toyota suspension (lowered suspension etc.) is installed. In addition to the examples above, there are instances in which, because of their shape, signs and other objects may be judged by a sensor to be closer than they are.
Page 416 • People, animals and other moving objects • People wearing certain types of clothing ● The following situations may occur when using the Toyota parking assist- sensor. • Depending on the shape of the object and other factors, the detection distance may shortened, or detection may not be possible.
Page 417 In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. A beep does not sound when you turn the Toyota parking assist-sensor ● If the area around a sensor collides with something, or is subjected to ●...
Page 418: Rear View Monitor System
4-5. Using the driving support systems  Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 419 4-5. Using the driving support systems Using the rear view monitor system Screen description ■  Vehicles without a smart entry & start system The rear view monitor system screen will be displayed if the shift lever is shifted to R while the engine switch is in the “ON” position. Vehicles with a smart entry &...
Page 420 4-5. Using the driving support systems Rear view monitor system precautions Area displayed on screen ■ The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga- tion System Owner’s Manual”,...
Page 421 4-5. Using the driving support systems Rear view monitor system camera ■ Vehicles with back door Vehicles with under floor   mounted spare tire mounted spare tire ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 422 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 423 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the fixation guide lines on the screen and the actual dis- A margin of error...
Page 424 4-5. Using the driving support systems ● Distance guide lines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 425 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 426  The fixed guide lines are very far out of alignment The camera position is out of align- Have the vehicle inspected by your ment. Toyota dealer. • The vehicle is tilted (there is a If this happens due to these causes, heavy load on the vehicle, tire it does not indicate a malfunction.
Page 427 4-5. Using the driving support systems WARNING When using the rear view monitor system ■ The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 428 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC150_OM_OM60R93E_(GE)
Page 429: Toyota Parking Assist Monitor
4-5. Using the driving support systems  Toyota parking assist monitor The parking assist monitor assists the driver by displaying an image of the view behind the vehicle while backing up, for exam- ple while parking. The parking assist monitor assists with the following 2 backing-up operations: •...
Page 430 Display mode switch screen button Switches the display mode. (P. 430) Toyota parking assist-sensor display If an obstacle is detected while the Toyota parking assist-sensor is on, a display is shown in the top right corner of the screen. Parking mode switch screen button...
Page 431 4-5. Using the driving support systems Using the system when perpendicular parking ■ Use any of the following modes when perpendicular parking (for example, when parking in a garage). Each time you select the dis- play mode switch screen but- ton, the display mode switches in the following order: Estimated course...
Page 432 4-5. Using the driving support systems ● Estimated course line display mode (P. 433) Estimated course lines are displayed which move in accordance with the opera- tion of the steering wheel. ● Parking assist guide line display mode (P. 435) The steering wheel return points (parking assist guide lines) are displayed.
Page 433 4-5. Using the driving support systems Using the system when parallel parking ■ Screen display beep sounds provide an estimation of the point at which you should turn the steering wheel when parallel parking. If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used.
Page 434 4-5. Using the driving support systems Perpendicular parking (estimated course line display mode) Screen description ■ Vehicle width extension guide line The line indicates a guide path when the vehicle is being backed straight up. The displayed width is wider than the actual vehicle width. The line aligns with the estimated course lines when the steering wheel is straight.
Page 435 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Turn the steering wheel so that the estimated course lines are within the parking...
Page 436 4-5. Using the driving support systems Once the vehicle width extension guide lines and the parking space lines are parallel, straighten the steering wheel and back up slowly until the vehicle has completely entered the parking space. Stop the vehicle in an appropriate place, and finish parking. Perpendicular parking (parking assist guide line display mode) Screen description ■...
Page 437 4-5. Using the driving support systems Parking operation ■ When parking in a space which is in the reverse direction to the space described in the procedure below, the steering directions will be reversed. Shift the shift lever to the R position. Back up until the parking assist guide line meets the edge of the left-hand divid-...
Page 438 4-5. Using the driving support systems Parallel parking Vehicle movement procedure ■ Approx. 1 m (3 ft.) Keeping parallel with the road, stop the vehicle leaving a gap of approximately 1 m (3 ft.) between your vehicle and the parked vehicle (Step in “Parking operation”).
Page 439 4-5. Using the driving support systems Parking operation ■ The following example describes the procedure for pulling into a parking space on the right. For pulling into a parking space on the left, substitute left for right and vice versa in all steps. Stop the vehicle in the position as described below, and straighten the steering wheel.
Page 440 4-5. Using the driving support systems With the steering wheel straight, back up slowly to a position at which the black and yellow vertical pole just overlaps the rear end of the parked vehicle. Then stop the vehicle. Black and yellow vertical pole Back the vehicle up to here...
Page 441 4-5. Using the driving support systems Turn the steering wheel with the vehicle stopped until the blue outline meets the desired parking space. Blue outline Black and yellow vertical pole Extended line If the extended line from the blue outline is displayed, the parallel parking assist is oper- ational.
Page 442 4-5. Using the driving support systems A curved blue line will appear on the screen. Keep the steering wheel in its current position and back up slowly. Stop when the curved blue line meets the corner of the desired parking space. Curved blue line Back up keeping the steer- ing wheel in its current...
Page 443 If Toyota parking assist-sensor detects an object while you attempt to park in a parking space on the left, the black and yel- low vertical pole could be obscured by Toyota parking assist-sen- sor display. In this event, turn Toyota parking assist-sensor switch off (P.
Page 444 4-5. Using the driving support systems Narrow mode ■ If the position the vehicle is to be parked in is narrower than usual, narrow mode can be used. Normal mode Narrow mode The engine switch is turned off when the parking assist monitor is canceled with narrow mode, the caution screen is displayed first when the parallel parking...
Page 445 4-5. Using the driving support systems ● Operating narrow mode Select while in parallel parking assist mode. Confirm the warning on the caution screen. If you agree, select “I Agree”. To cancel narrow mode, select When the system is switched to narrow mode, the indicator on will be turned on.
Page 446 4-5. Using the driving support systems Toyota parking assist monitor precautions Area displayed on screen ■ The parking assist monitor dis- plays an image of the view from the bumper of the rear area of the vehicle. The image on the rear view monitor system screen can be adjusted, refer to the “Naviga-...
Page 447 4-5. Using the driving support systems Toyota parking assist monitor camera ■ Vehicles with back door Vehicles with under floor   mounted spare tire mounted spare tire ● Using the camera If dirt or foreign matter (such as water droplets, snow, mud etc.) is adhering to the camera, it cannot transmit a clear image.
Page 448 4-5. Using the driving support systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than the actual dis- tance. Because this, objects will appear to be far- ther away than they actually are.
Page 449 4-5. Using the driving support systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of passengers or the distribu- tion of the load, there is a margin of error between the guide lines on the screen and the actual distance/course on A margin of error...
Page 450 4-5. Using the driving support systems ● Distance guidelines Visually check the surround- ings and the area behind the vehicle. On the screen, it appears that a truck is park- ing at point . However, in reality if you back up to point , you will hit the truck.
Page 451 If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Likely cause Solution  The image is difficult to see •...
Page 452  The guide lines are very far out of alignment The camera position is out of align- Have the vehicle inspected by your ment. Toyota dealer. • The vehicle is tilted (there is a If this happens due to these causes, heavy load on the vehicle, tire it does not indicate a malfunction.
Page 453 4-5. Using the driving support systems WARNING When using the Toyota parking assist monitor system ■ The parking assist monitor is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding.
Page 454 Estimated course line display mode: If the steering wheel is straight and the vehicle width extension guide lines and the estimated course lines are not in alignment, have the vehicle inspected by your Toyota dealer. When using the parallel parking assist screen ■...
Page 455 ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible. LC150_OM_OM60R93E_(GE)
Page 456: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 457 4-5. Using the driving support systems ◆ Hill-start assist control (if equipped) Refer to the “Off-road Driving Owner’s Manual” ◆ KDSS (Kinetic Dynamic Suspension System) (if equipped) Refer to the “Off-road Driving Owner’s Manual” ◆ Emergency brake signal (if equipped) ...
Page 458 PCS warning light will come on and the message will be shown on the multi-information display. (P. 377) ■ When the “TRC OFF” indicator light comes on even if not been pressed TRC is temporary deactivated. If the indicator light continues to remain on, contact your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 459 4-5. Using the driving support systems ■ Sounds and vibrations caused by the ABS, brake assist, VSC, Trailer Sway Control, TRC and hill-start assist control systems A sound may be heard from the engine compartment when the brake pedal ● is depressed repeatedly, when the engine is started or just after the vehicle begins to move.
Page 460 OFF” indicator light turns off. (There is no problem with continuing normal driving.) ■ KDSS (if equipped) Some difference of vehicle height between left and right side can appear. This does not indicate a malfunction in the KDSS system. For more information, contact your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 461 4-5. Using the driving support systems WARNING The ABS does not operate effectively when ■ ● The limits of tire gripping performance have been exceeded (such as excessively worn tires on a snow covered road). The vehicle hydroplanes while driving at high speed on wet or slick road. ●...
Page 462 The ABS, TRC, Trailer Sway Control and VSC systems will not function cor- rectly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■...
Page 463: (Blind Spot Monitor)
4-5. Using the driving support systems  BSM (Blind Spot Monitor) Summary of the Blind Spot Monitor The Blind Spot Monitor is a system that has 2 functions; ● The Blind Spot Monitor function Assists the driver in making the decision when changing lanes ●...
Page 464 4-5. Using the driving support systems Multi-information display The BSM function/RCTA function can be turned on/off. (P. 463) The RCTA function is available when the BSM function is on. Outside rear view mirror indicator BSM function: When a vehicle is detected in the blind spot, the outside rear view mirror indicator comes on while the turn signal lever is not operated.
Page 465 ■ When “Check BSM system” is shown on the multi-information display There may be a sensor malfunction or voltage abnormality. Have the vehicle inspected at your Toyota dealer. Certification for the Blind Spot Monitor ■  For vehicles sold in South Africa ...
Page 466 4-5. Using the driving support systems  For vehicles sold in the United Arab Emirates  For vehicles sold in Qatar  For vehicles sold in El Salvador  For vehicles sold in Philippines LC150_OM_OM60R93E_(GE)
Page 467 Do not modify the sensor or surrounding area on the bumper. ● ● Do not paint the rear bumper any color other than an official Toyota color. If the sensor needs to be replaced, contact your Toyota dealer. ● LC150_OM_OM60R93E_(GE)
Page 468: The Blind Spot Monitor Function
4-5. Using the driving support systems The Blind Spot Monitor function The Blind Spot Monitor function uses radar sensors to detect vehicles that are traveling in an adjacent lane in the area that is not reflected in the outside rear view mirror (the blind spot), and advises the driver of the vehicles existence via the outside rear view mirror indicator.
Page 469 4-5. Using the driving support systems ■ The Blind Spot Monitor function is operational when ● The Blind Spot Monitor system turned on. ● Vehicle speed is greater than approximately 16 km/h (10 mph). ■ The Blind Spot Monitor function will detect a vehicle when A vehicle in an adjacent lane overtakes your vehicle.
Page 470: The Rear Cross Traffic Alert Function
4-5. Using the driving support systems ● Instances of the Blind Spot Monitor function unnecessarily detecting a vehi- cle and/ or object may increase under the following conditions: • When there is only a short distance between your vehicle and a guardrail, wall etc.
Page 471 4-5. Using the driving support systems The Rear Cross Traffic Alert function detection areas The areas that vehicles can be detected in are outlined below. To give the driver a more consistent time to react, the buzzer can alert for faster vehicles from farther away. Example: Approximate Approaching vehicle...
Page 472 4-5. Using the driving support systems ■ Conditions under which the Rear Cross Traffic Alert function will not detect a vehicle The Rear Cross Traffic Alert function is not designed to detect the following types of vehicles and/or objects. ● Small motorcycles, bicycles, pedestrians etc.
Page 473: 4-6. Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 474 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Use the correct tire chain size when mounting the snow chains.
Page 475 4-6. Driving tips Regulations on the use of tire chains Regulations regarding the use of tire chains vary depending on loca- tion and type of road. Always check local regulations before installing chains. ■ Tire chain installation Observe the following precautions when installing and removing chains: Install and remove tire chains in a safe location.
Page 476 Repairing or replacing snow tires (vehicles with the tire pressure warn- ■ ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 477: Eco-Friendly Driving Tips
4-6. Driving tips Eco-friendly driving tips For improved fuel economy and reduced CO emissions, pay attention to the following points: ◆ Use of Eco Driving Indicator (vehicles with an automatic trans- mission) The Eco-friendly driving is possible by keeping the Eco Driving Indi- cator light on and keeping the bar display of the Eco Driving Indica- tor shown in the multi-information display within the Zone of Eco driving.
Page 478 4-6. Driving tips ◆ Air conditioning Use the air conditioning only when necessary. Doing so can help reduce excessive fuel consumption. In summer: When the ambient temperature is high, use the recircu- lated air mode. Doing so will help to reduce the burden on the air conditioning system and reduce fuel consumption as well.
Page 479 4-6. Driving tips ◆ Regular maintenance ● Make sure to check the tire inflation pressure frequently. Improper tire inflation pressure can cause poor fuel economy. Also, as snow tires can cause large amounts of friction, their use on dry roads can lead to poor fuel economy. Use tires that are appropriate for the season and road conditions.
Page 480: Audio System
Audio system 5-1. Basic Operations 5-4. Playing an audio CD and MP3/WMA discs Audio system types ...480 CD player operation...491 Steering wheel audio switches......482 5-5. Using an external device AUX port/USB port ....483 Listening to an iPod ...500 5-2. Using the audio system Listening USB memory device ......508 Optimal use of the...
Page 481: Basic Operations
5-1. Basic Operations  Audio system types  Vehicles with a navigation system or a multimedia system Refer to the “Navigation System Owner’s Manual”, “Navigation and Multimedia System Owner’s Manual” or “Multimedia Owner’s Man- ual”.  Vehicles without a navigation system or multimedia system CD player with AM/FM radio ●...
Page 482 5-1. Basic Operations ● Type B These illustrations are for left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles. Using cellular phones ■ Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 483: Steering Wheel Audio Switches
5-1. Basic Operations  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system or navigation system. For details, refer to the manual provided with the audio system or navigation system.
Page 484: Aux Port/Usb Port
5-1. Basic Operations AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Press the “MODE” button to select “iPod”, “USB” or “AUX”. Connecting using the AUX port/USB port iPod ■...
Page 485: 5-2. Using The Audio System
5-2. Using the audio system Optimal use of the audio system The sound quality, volume balance and ASL settings can be adjusted. Type A Type B   Displays the “SETUP” menu/Selecting the mode Changes the following settings • Sound quality and volume balance P.
Page 486 5-2. Using the audio system Using the audio control function Changing sound quality modes ■ Press the tune/scroll knob. Turn the knob to select “Sound Setting”. Press the knob. Turn the knob as corresponds to the desired mode. “BASS”, “TREBLE”, “FADER”, “BALANCE”, or “ASL” can be selected. Press the knob.
Page 487: 5-3. Using The Radio
5-3. Using the radio Radio operation Press the “MODE” button until “AM” or “FM” is displayed. Type A  AM/FM mode button Station selectors Tune/scroll knob Power/volume knob Adjusting the frequency Press: Turning the audio sys- tem on or off Seeking the frequency Turn: Adjusting the volume LC150_OM_OM60R93E_(GE)
Page 488 5-3. Using the radio  Type B AM/FM mode button Station selectors Tune/scroll knob Displaying the station list (FM Press: AF/region code/TA mode only) mode setup Power/volume knob Turn: Adjusting the frequency Press: Turning the audio sys- Seeking the frequency tem on or off Turn: Adjusting the volume Setting station presets...
Page 489 5-3. Using the radio Using the station list (type B only) Updating the station list ■ Press (LIST). The station list will be displayed. Press (UPDATE) to update the list. “Updating” is displayed while the searching is in process, and then avail- able stations will be listed on the display.
Page 490 5-3. Using the radio Traffic information ■ Press the tune/scroll knob. Turn the knob to “RADIO” and press the knob. Turn the knob to “FM TA” mode. Press the knob to select “ON” or “OFF”. TP mode: The system automatically switches to traffic information when a broadcast with a traffic information signal is received.
Page 491 5-3. Using the radio ■ EON (Enhanced Other Network) system (for traffic announcement func- tion) (type B only) If the RDS station (with EON data) you are listening to is not broadcasting a traffic information program and the audio system is in the TA (traffic announcement) mode, the radio will be switched automatically to a station broadcasting a traffic information program in the EON AF list when traffic information begins.
Page 492: Cd Player Operation
5-4. Playing an audio CD and MP3/WMA discs CD player operation Insert a disc, press the “MODE” button to begin listening to a Type A  Disc eject Selecting a folder (MP3/WMA discs only) Changing the audio source/ playback Displaying track/folder list Tune/scroll knob Displaying text message Selecting a track/file...
Page 493 5-4. Playing an audio CD and MP3/WMA discs  Type B Disc eject Selecting a folder (MP3/WMA discs only) Changing the audio source/ playback Displaying track/folder list Tune/scroll knob Displaying text message Selecting a track/file Power/volume knob Selecting a track/file, fast-for- Press: Turning the audio sys- warding or rewinding tem on or off...
Page 494 5-4. Playing an audio CD and MP3/WMA discs Using the CD player Selecting a track ■ Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to move up or down until the desired track number is dis- played.
Page 495 5-4. Playing an audio CD and MP3/WMA discs Playing back MP3 and WMA discs Selecting folders one at a time ■ Press (<FOLDER) or (FOLDER>) to select the desired folder. Selecting a folder and file from folder list ■ Press (LIST).
Page 496 ■ Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause Correction procedures • The disc is dirty or •...
Page 497 5-4. Playing an audio CD and MP3/WMA discs ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 for- mat.
Page 498 5-4. Playing an audio CD and MP3/WMA discs ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD- RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 499 5-4. Playing an audio CD and MP3/WMA discs ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 500 5-4. Playing an audio CD and MP3/WMA discs NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs. Also, do not use 8 cm (3 in.) disc adapters, DualDiscs or printable discs. Doing so may damage the player and/or the disc insert/eject function. ●...
Page 501: 5-5. Using An External Device
5-5. Using an external device Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “iPod” is displayed. Connecting an iPod P. 483 Control panel  Type A Changing the audio source/ iPod menu mode, playback playback Displaying song list...
Page 502 5-5. Using an external device  Type B Changing the audio source/ iPod menu mode, playback playback Displaying song list Tune/scroll knob Displaying text message Selecting an iPod menu/song Power/volume knob Selecting a song, fast-forward- Press: Turning the audio sys- ing or rewinding tem on or off Random play or back button...
Page 503 5-5. Using an external device Play mode list ■ First Second Third Fourth Play mode selection selection selection selection Playlists “Playlists” Songs select select Albums “Artists” Artists select Songs select select Albums “Albums” Songs select select “Songs” Songs select Podcasts Episodes “Podcasts”...
Page 504 5-5. Using an external device Selecting songs Turn the tune/scroll knob or press the “<” or “>” button of “SEEK TRACK” to select the desired song. Selecting a song from the song list Press (LIST). The song list will be displayed. Turn the tune/scroll knob to select a song.
Page 505 5-5. Using an external device ■ About iPod ● “Made for iPod” and “Made for iPhone” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance stan- dards.
Page 506 Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the iPod or its con- “ERROR”...
Page 507 5-5. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. Made for ● • iPod touch (5th generation) •...
Page 508 5-5. Using an external device WARNING While driving ■ Do not connect iPod or operate the controls. Doing so may cause an acci- dent, resulting in death or serious injury. NOTICE ■ To prevent damage to iPod or its terminal ●...
Page 509: Listening Usb Memory Device
5-5. Using an external device Listening USB memory device Connecting a USB memory enables you to enjoy music from the vehicle speakers. Press the “MODE” button until “USB” is dis- played. Connecting a USB memory P. 483 Control panel Type A ...
Page 510 5-5. Using an external device  Type B Changing the audio source/ Selecting a folder playback Displaying folder list Tune/scroll knob Displaying text message Selecting a file Power/volume knob Selecting a song, fast-forward- Press: Turning the audio sys- ing or rewinding tem on or off Random play or back button Turn: Adjusting the volume...
Page 511 5-5. Using an external device Selecting a folder Selecting folders one at a time ■ Press (<FOLDER) or (FOLDER>) to select the desired folder. Selecting a folder and file from folder list ■ Press (LIST). The folder list will be displayed. Turn and press the tune/scroll knob to select a folder and file.
Page 512 5-5. Using an external device Fast-forwarding and rewinding files Press and hold the “<” or “>” button of “SEEK TRACK”. Random play Pressing (RDM) changes modes in the following order: Folder randomAll folder randomOff Repeat play Pressing (RPT) changes modes in the following order: Off File repeatFolder repeat : Available except when RDM (random play) is selected...
Page 513 ■ If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the USB memory “ERROR”...
Page 514 5-5. Using an external device ● MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 515 5-5. Using an external device ● File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
Page 516 5-5. Using an external device ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz. • There is a wide variety of freeware and other encoding software for MP3 and WMA files on the market, and depending on the status of the encod- ing and the file format, poor sound quality or noise at the start of playback may result.
Page 517: Using The Aux Port
5-5. Using an external device Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Press the “MODE” button until “AUX” is displayed. Connecting a portable player P.
Page 518: Audio/Phone
® 5-6. Using Bluetooth devices  ® Bluetooth audio/phone ® The following can be performed using Bluetooth wireless com- munication: ® ◆ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication.
Page 519 ® 5-6. Using Bluetooth devices Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio system (P. 524) ® 2. Connect the registered Bluetooth device to be used (P. 525, 526) 3. Set automatic connection of the device (P.
Page 520 ® 5-6. Using Bluetooth devices Audio unit  Type A Power/volume knob Press: Turning the audio sys- tem on or off Turn: Adjusting the volume ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used.
Page 521 ® 5-6. Using Bluetooth devices  Type B Power/volume knob Press: Turning the audio sys- tem on or off Turn: Adjusting the volume ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc.
Page 522 ® 5-6. Using Bluetooth devices ® Menu list of the Bluetooth audio/phone To enter a menu, press the tune/scroll knob and navigate menus by using the knob. First menu Second menu Third menu Operation details Registering “Pairing” ® Bluetooth device Listing the registered “List Phone”...
Page 523 ® 5-6. Using Bluetooth devices First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
Page 524: Using The Steering Wheel Switches
® 5-6. Using Bluetooth devices Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone, or portable digital audio player (portable player). ® Operating Bluetooth phone using the steering wheel switches Volume The voice guidance volume cannot be adjusted using this button.
Page 525: Device
® 5-6. Using Bluetooth devices ® Registering a Bluetooth device ® Before using the Bluetooth audio/phone, it is necessary to reg- ® ister a Bluetooth device in the system. You can register up to 5 ® Bluetooth devices. ® How to register a Bluetooth device Press the tune/scroll knob and select “Bluetooth ”...
Page 526: Using The "Setup" Menu " Menu)
5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth*” menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: Registering a portable player Select “Pairing” using the tune/scroll knob (P. 521), and perform the procedure for registering a portable player.
Page 527 5-7. “SETUP” menu Listing the registered portable players Select “List Audio” using the tune/scroll knob. (P. 521) The list of registered portable players will be displayed. ● Connecting the registered portable player to the audio system Select the name of the portable player to be connected using the tune/scroll knob.
Page 528 5-7. “SETUP” menu Changing the passkey Select “Passkey” using the tune/scroll knob. (P. 521) Select a 4 to 8-digit passkey using the knob. Input the number 1 digit at a time. When the entire number to be registered as a passkey has been input, press (ENTER).
Page 529 5-7. “SETUP” menu Initialization Select “Initialize” using the tune/scroll knob. (P. 521) ● Initializing the sound settings Select “Sound setting” using the tune/scroll knob and press (YES). For details about sound settings: P. 484 ● Initializing the device information Select “Car device info” using the tune/scroll knob and press (YES).
Page 530: Menu)
5-7. “SETUP” menu Using the “SETUP” menu (“PHONE” or “TEL” menu) Adding a new phone number Select “Add contacts” using the tune/scroll knob. (P. 521) ● Transferring all contacts from the cellular phone Select “Overwrite all” using the tune/scroll knob and press (YES).
Page 531 5-7. “SETUP” menu ● Deleting incoming call history Select “Incoming Calls” using the tune/scroll knob. Select the desired phone number using the knob and press (YES). To delete all incoming call history data, press (ALL) and then press (YES). ● Deleting missed call history Select “Missed Calls”...
Page 532 5-7. “SETUP” menu Deleting a registered phone number Select “Delete contacts” using the tune/scroll knob. (P. 521) Select the desired phone number using the knob and press (YES). To delete all the registered phone numbers, press (ALL) and then press (YES).
Page 533 5-7. “SETUP” menu Setting ring tone volume Select “Ringtone volume” using the tune/scroll knob. (P. 521) Change the ring tone volume. To decrease the volume: Turn the knob counterclockwise. To increase the volume: Turn the knob clockwise. To set the volume, press (BACK).
Page 534: Operating A Bluetooth
® 5-8. Bluetooth Audio ® Operating a Bluetooth enabled portable player  Type A Changing the audio source/ Selecting an album playback Playback/pause Selecting a track, fast-forward- Displaying text message ing or rewinding Power/volume knob Random play or back button Press: Turning the audio sys- Repeat play tem on or off...
Page 535 ® 5-8. Bluetooth Audio  Type B Changing the audio source/ Selecting an album playback Playback/pause Selecting a track, fast-forward- Displaying text message ing or rewinding Power/volume knob Random play or back button Press: Turning the audio sys- Repeat play tem on or off Turn: Adjusting the volume LC150_OM_OM60R93E_(GE)
Page 536 ® 5-8. Bluetooth Audio Selecting an album Press (<FOLDER) or (FOLDER>) to select desired album. Selecting a track Press the “<” or “>” button of “SEEK TRACK” to select the desired track. Fast-forwarding and rewinding tracks Press and hold the “<” or “>” button of “SEEK TRACK”. Repeat play Pressing (RPT) changes modes in the following order:...
Page 537: Making A Phone Call
® 5-9. Bluetooth Phone Making a phone call To enter the “PHONE” or “TEL” mode, press the off-hook switch. Dialing by selecting a name Select “Phonebook” using the tune/scroll knob. Select the desired name using the knob and press the off-hook switch.
Page 538 ® 5-9. Bluetooth Phone Dialing by entering the number Select “Dial by number” using the tune/scroll knob. Enter the phone number and press the off-hook switch. Dialing from call histories Select “All Calls”, “Missed Calls”, “Incoming Calls” or “Outgoing Calls” using the tune/scroll knob. Select a desired number using the knob and press the off-hook switch.
Page 539: Receiving A Phone Call
® 5-9. Bluetooth Phone Receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch. Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Adjusting the ring tone volume when receiving a call To decrease the volume: Turn the power/volume knob counterclock- wise.
Page 540: Speaking On The Phone
® 5-9. Bluetooth Phone Speaking on the phone Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the following methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the operation of the phone.
Page 541 ® 5-9. Bluetooth Phone ■ When talking on the phone ● Do not talk simultaneously with the other party. ● Keep the volume of the received voice down. Otherwise, voice echo will increase. ■ Automatic volume adjustment When vehicle speed is 80 km/h (50 mph) or more, the volume automatically increases.
Page 542: Bluetooth
® 5-10. Bluetooth ® Bluetooth ® When using the Bluetooth audio/phone ■ In the following situations, the system may not function. ● ® • The portable player does not support Bluetooth • The cellular phone is located outside the service area ®...
Page 543 ® 5-10. Bluetooth ■ Compatible models ® Bluetooth specifications: ● Ver. 1.1, or higher (Recommended: Ver. 2.1 + EDR or higher) Following Profiles: ● • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 or higher (recom- mended: Ver. 1.2 or higher) •...
Page 544 ® 5-10. Bluetooth ■ Certification LC150_OM_OM60R93E_(GE)
Page 545 ® 5-10. Bluetooth LC150_OM_OM60R93E_(GE)
Page 546 ® 5-10. Bluetooth LC150_OM_OM60R93E_(GE)
Page 547 ® 5-10. Bluetooth LC150_OM_OM60R93E_(GE)
Page 548 ® 5-10. Bluetooth LC150_OM_OM60R93E_(GE)
Page 549 ® 5-10. Bluetooth  For vehicles sold in Jamaica  For vehicles sold in the Dominican Republic  For vehicles sold in Republic of Paraguay LC150_OM_OM60R93E_(GE)
Page 550 ® 5-10. Bluetooth WARNING While driving ■ Do not use the portable audio player, cellular phone or connect a device to ® the Bluetooth system. Caution regarding interference with electronic devices ■ ® Your audio unit is fitted with Bluetooth antennas.
Page 551 ® 5-10. Bluetooth LC150_OM_OM60R93E_(GE)
Page 552: Interior Features
Interior features 6-1. Using the air conditioning 6-2. Using the interior lights system and defogger Interior lights list....579 Front manual air • Personal/interior lights conditioning system ..552 main switch....580 • Personal/interior Front automatic air lights ......580 conditioning system ..558 • Lounge illumination Rear manual air control switches.....581 conditioning system ..567...
Page 553: Front Manual Air
6-1. Using the air conditioning system and defogger  Front manual air conditioning system The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles. Adjusting the temperature setting ■ Press “”(warm) or “” (cool). If the “A/C”...
Page 554 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time the button is pressed. Defogging the windshield ■...
Page 555 6-1. Using the air conditioning system and defogger Windshield wiper de-icer (if equipped) ■ This feature is used to prevent ice from building up on the wind- shield and wiper blades. Turns on/off The windshield wiper de-icer will automatically turn off after a period of time.
Page 556 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. : Some models Adjusting the air flow direction and opening/closing the air ■ outlets ...
Page 557 6-1. Using the air conditioning system and defogger ■ Fogging up of the windows ● The windows will easily fog up when the humidity in the vehicle is high. Turning the “A/C” button on will dehumidify the air from the outlets and defog the windshield effectively.
Page 558 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up ■ ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 559: Front Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Front automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. The illustration below is for left-hand drive vehicles. The button positions and shapes may differ slightly for right-hand drive vehicles.
Page 560 6-1. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode ■ Press the “AUTO” button. Adjust the temperature setting. To stop the operation, press Automatic mode indicator ■ If the fan speed setting or air flow modes are operated, the auto- matic mode indicator goes off.
Page 561 6-1. Using the air conditioning system and defogger Changing the rear seat settings (vehicles with rear automatic air conditioning system) Adjusting the temperature setting ■ Press the “REAR” button. “REAR” is shown on the display. Press “”(increase) or “”(decrease) on the passenger’s side. Adjusting the fan speed setting ■...
Page 562 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time the button is pressed. Defogging the windshield ■...
Page 563 6-1. Using the air conditioning system and defogger Windshield wiper de-icer (if equipped) ■ This feature is used to prevent ice from building up on the wind- shield and wiper blades. Turns on/off The windshield wiper de-icer will automatically turn off after a period of time.
Page 564 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. : Some models Adjusting the air flow direction and opening/closing the air ■ outlets ...
Page 565 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after the “AUTO”...
Page 566 6-1. Using the air conditioning system and defogger ■ Ventilation and air conditioning odors To let fresh air in, set the air conditioning system to the outside air mode. ● During use, various odors from inside and outside the vehicle may enter into ●...
Page 567 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up ■ ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the wind- shield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 568: Rear Manual Air Conditioning System
6-1. Using the air conditioning system and defogger  Rear manual air conditioning system Press the “REAR” button on the front manual air conditioning control panel to use the rear manual air conditioning system. Adjusting the temperature setting ■ Turn clockwise (warm) or counterclockwise (cool).
Page 569 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected air flow mode. Adjusting the air flow direction and opening/closing the air ■ outlets Direct air flow to the left or right, up or down.
Page 570: Rear Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Rear automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Vehicles without outer second Vehicles with outer second   seat heaters seat heaters Adjusting the temperature setting ■...
Page 571 6-1. Using the air conditioning system and defogger Air conditioning controls Using the automatic mode ■ Press the “AUTO” button. Adjust the temperature setting. To stop the operation, press the “OFF” button. If the system is operated manually in automatic mode ■...
Page 572 6-1. Using the air conditioning system and defogger NOTICE To prevent battery discharge ■ Do not leave the air conditioning system on longer than necessary when the engine is off. LC150_OM_OM60R93E_(GE)
Page 573: Power Heater
6-1. Using the air conditioning system and defogger  Power heater This feature is used to keep the cab warm in cold conditions. On/off The power heater turns on about 30 seconds after you press the switch and it takes about another 55 seconds to warm up.
Page 574 If the pipes become clogged, this can cause the heater to malfunction. ● If you notice anything unusual, such as a fluid leak, smoke or poor opera- tion, turn off the heater and have your vehicle checked by your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 575: Heated Steering Wheel/ Seat Heaters/ Seat Ventilators
6-1. Using the air conditioning system and defogger   Heated steering wheel /seat heaters /seat  ventilators Heated steering wheel and seat heaters heat the side grips of the steering wheel and seats. Seat ventilators maintain good airflow by blowing air from the seats. WARNING ●...
Page 576 6-1. Using the air conditioning system and defogger Heated steering wheel (if equipped) Turns the steering wheel heater on/off The indicator light comes on when the heater is operating. ■ The heated steering wheel can be used when  Vehicles without a smart entry & start system The engine switch is in the “ON”...
Page 577 6-1. Using the air conditioning system and defogger Front seat ventilators (if equipped)  Vehicles with an automatic transmission Vehicles with a manual transmission  Blows air from the seat The indicator light comes on. The higher the number is, the stronger the airflow becomes. LC150_OM_OM60R93E_(GE)
Page 578 6-1. Using the air conditioning system and defogger Seat heaters and ventilators (if equipped) Front seats ■  Vehicles with an automatic transmission  Vehicles with a manual transmission Turns the seat heater on The indicator light comes on. The higher the number is, the warmer the seat becomes. Blows air from the seat The indicator light comes on.
Page 579 6-1. Using the air conditioning system and defogger ■ The seat heaters/seat ventilators can be used when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 580: 6-2. Using The Interior Lights
6-2. Using the interior lights Interior lights list Personal/interior lights (P. 580) Ornament illumination (if equipped) Inside door handle lights (if equipped) Shift lever light (if equipped) Footwell lights (if equipped) Engine switch light Door pocket lights (if equipped) Running board lights (if equipped) Outer foot lights (if equipped) : The brightness of the lights can be adjusted (P.
Page 581: Personal/Interior Lights Main Switch
6-2. Using the interior lights Personal/interior lights main switch The personal/Interior lights and interior light can be individually turned on or off. Door position The personal/interior lights come on when a door is opened. They turn off when the doors are closed. The personal/interior lights cannot be individually turned off.
Page 582: Lounge Illumination Control Switches
6-2. Using the interior lights  Rear (without personal lights) Turns the lights on Turns the door position on Door position: When the personal/ interior light main switch is in the “OFF” position, the lights will not turn on. Rear (with personal lights) ...
Page 583 6-2. Using the interior lights ■ Illuminated entry system  Vehicles without a smart entry & start system The lights automatically turn on/off according to the engine switch position, whether the doors are locked/unlocked, and whether the doors are open/ closed.
Page 584: Using The Storage Features
6-3. Using the storage features List of storage features Cup holders (P. 587) Bottle holders/door pockets (P. 588) Auxiliary boxes (P. 591) Glove box (P. 584) Card holder (right-hand drive vehicles) (P. 585) Console box (if equipped) (P. 585) Cup holders (vehicles with bench front seats) (P. 587) Cool box (if equipped) (P.
Page 585: Glove Box
6-3. Using the storage features WARNING Do not leave glasses, lighters or spray cans in the storage spaces, as this ● may cause the following when cabin temperature becomes high: • Glasses may be deformed by heat or cracked if they come into contact with other stored items.
Page 586: Card Holder
6-3. Using the storage features Card holder (right-hand drive vehicles) The card holder is located in the glove box. Console box (if equipped) Your vehicle is equipped with either a console box or cool box. For vehicles with the cool box, refer to P. 599. Lift the lid while pulling up the knob to release the lock.
Page 587 6-3. Using the storage features ■ Using the console box vent (if equipped) Air from the air conditioner can be distrib- uted into the console box by opening and closing the vent. Open Close Items unsuitable for the console box ■...
Page 588: Cup Holders/Bottle Holders/Door Pockets
6-3. Using the storage features Cup holders/bottle holders/door pockets Cup holders ■  Front (vehicles with an auto-  Front (vehicles with a manual matic transmission) transmission) Press down and release the Press down and release the cup cup holder lid. holder lid.
Page 589 6-3. Using the storage features  Rear (type A) (if equipped)  Rear (type B) (if equipped) Pull the armrest down. Pull the armrest down and press in and release the button.  Rear (type C) (if equipped)  Rear (type D) (if equipped) Push the lid.
Page 590 6-3. Using the storage features ■ Removing the holder, separate tray and adapter of the cup holder  Front (vehicles with an automatic transmission) Pull up the holder.  Front (vehicles with a manual transmission) Pull up the separate tray. ...
Page 591 6-3. Using the storage features WARNING Items unsuitable for the cup holder ■ Do not place anything other than cups, mugs or beverage cans in the cup holders. Even when the lid is closed, items must not be stored in the cup holders.
Page 592: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes  Type A  Type B (if equipped) Press in the lid. Push the lid. The auxiliary box is useful for tem- porarily storing sunglasses and similar small items. Type C (if equipped) Type D (vehicles with an auto- ...
Page 593 6-3. Using the storage features  Type E (vehicles with a man- ual transmission) WARNING Do not place cups, beverage cans or bottles in the box. They may be ● thrown out of the box in the event of sudden braking, sudden swerving or an accident, resulting in injury.
Page 594: Luggage Compartment Features
6-3. Using the storage features Luggage compartment features Deck rail (if equipped) To attach the deck hooks, use the deck rails. The deck hook itself is not included as an original equipment. Vehicles with the third seats (power seat): When using the deck rail, the third seat must be fold down.
Page 595 6-3. Using the storage features Warning reflector holder Open the cover. Turn the knob clockwise. Open the cover. Secure the warning reflector. The warning reflector itself is not included as an original equipment. Cargo net hooks Type A Type B To hang the cargo net, use the cargo net hooks.
Page 596 6-3. Using the storage features Auxiliary box (if equipped)  Type A  Type B Remove the cover. Auxiliary tray (if equipped) LC150_OM_OM60R93E_(GE)
Page 597 6-3. Using the storage features Luggage cover (if equipped) Installing the luggage cover ■ Install the side of the luggage cover with the cutout to the holder on the left side of the vehicle. While pushing the opposite end of the cover in, install it to the holder on the right side.
Page 598 6-3. Using the storage features Pull out the luggage cover and hook it on the anchors. Removing the luggage cover ■ Detach the sub cover hooks, remove the luggage cover from the left and right holders, and roll the luggage cover up. Retract the cover and release both ends, then lift it out.
Page 599 6-3. Using the storage features ■ Adjusting the sub cover (if equipped) Fasten the button when the second seats are in the rear-most position. Unfasten the buttons before sliding the second seats forward. WARNING ● To avoid injury, always return the cargo hooks to their stowed positions. Keep the auxiliary box closed.
Page 600: Other Interior Features
6-4. Using the other interior features Other interior features Cool box (if equipped) Lift the lid while pulling up the knob to release the lock. Turns the cool box on/off When on, the indicator light comes The cool box can be operated when ■...
Page 601 If the indicator light continues to flash, there may be a malfunction in the sys- tem. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ When using the cool box lid as an armrest (if equipped) Slide the cool box lid forward or backward as needed.
Page 602: Sun Visors
6-4. Using the other interior features Sun visors  Type A To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. ...
Page 603: Conversation Mirror
6-4. Using the other interior features NOTICE To prevent battery discharge, do not leave the vanity lights on for extended periods when the engine is not running. Conversation mirror The conversation mirror can provide the driver and the front passen- ger with a view of the rear seat area without the need to turn around.
Page 604: Clock
6-4. Using the other interior features Clock Adjusts the hours Adjusts the minutes Rounds the nearest hour : e.g. 1:00 to 1:29 1:00 1:30 to 1:59 2:00 ■ The clock is displayed when  Vehicles without a smart entry & start system The engine switch is in the “ACC”...
Page 605: Power Outlet
6-4. Using the other interior features Power outlet The power outlet can be used for the following components: 12 V DC: Accessories that run on less than 10 A. Accessories that run on less than 10 A should be used when using several power outlets at the same time.
Page 606 6-4. Using the other interior features Luggage compartment (12 V DC) (if equipped) ■ 3 door models 5 door models   Luggage compartment (220 V AC) (if equipped) ■  3 door models  5 door models The power outlet can be used when ■...
Page 607 6-4. Using the other interior features NOTICE To avoid damaging the power outlet ■ Close the power outlet lid when the power outlet is not in use. Foreign objects or liquids that enter the power outlet may cause a short cir- cuit.
Page 608: Armrest
6-4. Using the other interior features Armrest (if equipped)  Front (vehicles with bench front seats) Pull the center seatback lock release knob and fold it down to its lowest position. Raise armrest desired angle.  Rear Fold down the armrest for use. NOTICE To prevent damage, do not apply too heavy a load on the armrest.
Page 609: Coat Hooks
6-4. Using the other interior features Coat hooks The coat hooks are provided with the rear assist grips. WARNING Vehicles with SRS curtain shield airbags: Do not hang coat hangers or other hard or sharp objects on the hook. If the SRS curtain shield airbags deploy, these items may become projectiles, causing death or serious injury.
Page 610: Ashtray
6-4. Using the other interior features WARNING Do not use the assist grip (Type A) when getting in or out of the vehicle or rising from your seat. NOTICE To prevent damage, do not hang heavy objects or put a heavy load on the assist grip.
Page 611 6-4. Using the other interior features LC150_OM_OM60R93E_(GE)
Page 612: Maintenance And Care
Maintenance and care 7-1. Maintenance and care Cleaning and protecting the vehicle exterior ..612 Cleaning and protecting the vehicle interior ...617 7-2. Maintenance Maintenance requirements....620 Scheduled maintenance ....623 7-3. Do-it-yourself maintenance Do-it-yourself service precautions ......639 Hood ........642 Engine compartment..643 Tires........664 Tire inflation pressure ..684 Wheels.......686 Air conditioning filter ..689...
Page 613: Maintenance And Care Cleaning And Protecting
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 614 7-1. Maintenance and care ■ Notes for a smart entry & start system (if equipped) If the door handle becomes wet while the electronic key is within the effective range, the door may lock and unlock repeatedly. In this case, follow the fol- lowing correction procedures to wash the vehicle: •...
Page 615 ■ Precautions regarding the Blind Spot Monitor (if equipped) If the paint of the rear bumper is chipped or scratched, the system may mal- function. If this occurs, consult your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 616 7-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 617 7-1. Maintenance and care NOTICE When using a high pressure car wash ■ ● Do not bring the nozzle tip close to boots (rubber or resin manufactured cover), connectors or the following parts. The parts may be damages if they come into contact with high-pressure water. •...
Page 618: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 619 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 620 Vehicle systems such as the audio system may be damaged if water comes into contact with electrical components such as the audio system above or under the floor of the vehicle. Water may also cause the body to rust. When cleaning the inside of the windshield (vehicles with Toyota ■ Safety Sense) Do not allow glass cleaner to contact the lens.
Page 621: 7-2. Maintenance
● Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for maintenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips and in-dealership train- ing programs.
Page 622: Maintenance
Engine coolant temperature continually higher than normal ● If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. LC150_OM_OM60R93E_(GE)
Page 623 7-2. Maintenance WARNING If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. Handling of the battery ■ Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 624: Scheduled Maintenance
7-2. Maintenance Scheduled maintenance Perform maintenance by the schedule as follows: Maintenance schedule requirements Your vehicle needs to be serviced according to the normal maintenance schedule. (See “Maintenance schedule”.) If you mainly operate your vehicle under one or more of the spe- cial operating conditions below, some of the maintenance sched- ule items need to be serviced more frequently in order to keep your vehicle in good condition.
Page 625 7-2. Maintenance A. Road Condition B. Driving Condition 1. Operating rough 1. Heavily loaded vehicle. muddy roads, or roads with (Example: Towing a trailer melted snow. [with towing hitch], using a camper, using a car top car- 2. Operating on dusty roads. rier, etc.) (Roads in areas where their pavement rate is low, or a...
Page 626 7-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 627 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 628 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 629 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 630 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 631 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary R = Replace, change or lubricate L = Lubricate T = Tighten to specified torque SERVICE ODOMETER READING INTERVAL: (Odometer x1000 km 10 20 30 40 50 60 70 80 MONTHS reading or months,...
Page 632 5. The interval should be 1/2 if impure fuel is used. 6. EURO IV is emission standards. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. 7. Replace the blade with new one and never reuse the blade.
Page 633 7-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe condi- tions. (For outline, see “Maintenance schedule requirements”.) A-1: Operating on rough or muddy roads, or roads with melted snow. ...
Page 634 7-2. Maintenance A-2: Operating on dusty roads. (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.)  Replacement of engine oil Every 5000 km (3000 miles) or (gasoline engine) 6 months ...
Page 635 7-2. Maintenance A-2: Operating on dusty roads. (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.)  Lubrication propeller shaft Every 5000 km (3000 miles) or grease <<See note 1.>> 3 months Every 5000 km (3000 miles) or 3 ...
Page 636 7-2. Maintenance B-1: Heavily loaded vehicle. (Example: Towing a trailer [with towing hitch], using a camper, using a car top carrier, etc.)  Replacement of engine oil Every 5000 km (3000 miles) or (gasoline engine) 6 months  1KD-FTV engine for South Africa and 1GD-FTV engine: Every 5000 km (3000 miles) or 6 months...
Page 637 7-2. Maintenance B-1: Heavily loaded vehicle. (Example: Towing a trailer [with towing hitch], using a camper, using a car top carrier, etc.)  Inspection of front and rear sus- Every 5000 km (3000 miles) or pensions 3 months  Tightening of bolts and nuts on Every 10000 km (6000 miles) or chassis and body 6 months...
Page 638 7-2. Maintenance B-3: Extensive idling and/or low speed driving for a long distance such as police, professional/private use like taxi or door-to-door delivery use.  Replacement of engine oil Every 5000 km (3000 miles) or (gasoline engine) 6 months  1KD-FTV engine for South Africa and 1GD-FTV engine: Every 5000 km (3000 miles) or...
Page 639 7-2. Maintenance B-4: Continuous high speed driving (80 % or more of maximum vehicle speed) for over 2 hours.  Replacement of manual transmis- Every 40000 km (24000 miles) or sion oil 48 months I: Every 40000 km (24000 miles) or ...
Page 640: Do-It-Yourself Maintenance Do-It-Yourself Service
Battery condition • Conventional wrench (for terminal clamp bolts) (P. 655) • Distilled water • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology. “Toyota Super level (P.
Page 641: Do-It-Yourself Maintenance
7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions: ■ When working on the engine compartment Keep hands, clothing and tools away from the moving fan and engine ●...
Page 642 7-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner filter ■ Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. If the fluid level is low or high ■ It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 643: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Move the auxiliary catch lever to side direction and lift the hood.
Page 644: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment  1GR-FE engine Discharging dust valve Engine oil filler cap (P. 651) (P. 662) Fuse box (P. 696) Air cleaner (P. 661) Battery (P. 655) Engine oil level dipstick Radiator cooling fan (P. 649) Cooling fan (if equipped) Engine coolant reservoir Condenser (P.
Page 645 7-3. Do-it-yourself maintenance  2TR-FE engine Discharging dust valve Engine oil level dipstick (P. 662) (P. 649) Air cleaner (P. 661) Fuse box (P. 696) Engine coolant reservoir Battery (P. 655) (P. 653) Radiator (P. 655) Radiator cooling fan Cooling fan (if equipped) Engine oil filler cap (P.
Page 646 7-3. Do-it-yourself maintenance  5L-E engine Discharging dust valve Radiator cooling fan (P. 662) Fuse box (P. 696) Air cleaner (P. 661) Fuel filter (P. 663, 782) Engine coolant reservoir Battery (P. 655) (P. 653) Condenser (P. 655) Engine oil level dipstick Cooling fan (if equipped) (P.
Page 647 7-3. Do-it-yourself maintenance  1KD-FTV engine Discharging dust valve Fuse box (P. 696) (P. 662) Fuel filter (P. 663, 782) Air cleaner (P. 661) Battery (P. 655) Engine coolant reservoir Intercooler (P. 655) (P. 653) Condenser (P. 655) Engine oil level dipstick Radiator cooling fan (P.
Page 648 7-3. Do-it-yourself maintenance  1GD-FTV engine Discharging dust valve Engine oil level dipstick (P. 662) (P. 649) Air cleaner (P. 661) Fuse box (P. 696) Sub battery Fuel filter (P. 663, 782) (if equipped) (P. 655) Battery (P. 655) Engine coolant reservoir Intercooler (P.
Page 649 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ Installing the clips ■ Push up center portion Insert Press NOTICE ■ After installing an engine compartment cover Make sure the cover is securely installed in its original position. LC150_OM_OM60R93E_(GE)
Page 650 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 651 7-3. Do-it-yourself maintenance Holding a rag under the end, pull the dipstick out and check the oil level. Normal Excessive  Type A  Type B  Type C The shape of the dipstick may differ depending on the type of vehicle or engine.
Page 652 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 653 ● not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 654 7-3. Do-it-yourself maintenance NOTICE To prevent serious engine damage ■ Check the oil level on regular basis. ■ When replacing the engine oil Be careful not to spill engine oil on the vehicle components. ● ● Avoid overfilling, or the engine could be damaged. Check the oil level on the dipstick every time you refill the vehicle.
Page 655 “Toyota Super Long Life Coolant” is a mixture of 50% coolant and 50% deion- ized water. (Enabled: -35C [-31F]) For more details about engine coolant, contact your Toyota dealer.
Page 656 Check the radiator, condenser and intercooler (if equipped) and clear any foreign objects. If any of the above parts are extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING When the engine is hot ■...
Page 657 7-3. Do-it-yourself maintenance Battery exterior ■ Make sure that the battery terminals are not corroded and that there are no loose connections, cracks, or loose clamps. Terminals Hold-down clamp Checking battery fluid ■ Check that the level is between the “UPPER LEVEL” and “LOWER LEVEL”...
Page 658 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the system will not start even after multiple attempts, contact your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 659 7-3. Do-it-yourself maintenance WARNING Chemicals in the battery ■ Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near battery: Do not cause sparks by touching the battery terminals with tools.
Page 660 7-3. Do-it-yourself maintenance NOTICE When recharging the battery ■ Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. When adding distilled water ■ Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 661 7-3. Do-it-yourself maintenance ■ Using the gauge (if equipped) The washer fluid level is checked by observing the position of the level on the liquid covered holes in the gauge. If the level falls below the second hole Current from the bottom (“LOW” position), refill the fluid level washer fluid.
Page 662 7-3. Do-it-yourself maintenance Air cleaner filter Check the air cleaner filter as follows: Release the clips. Lift the cover and take out the air cleaner filter. Inspect the outer surface of the filter, and replace the filter if it is extremely dirty.
Page 663 7-3. Do-it-yourself maintenance Discharging dust valve Squeeze rubber remove the dust if the discharging dust valve is dirty. Shape of the valve differs slightly in accordance with the engine. NOTICE To prevent damaging the engine ■ Do not drive with the discharging dust valve removed. Doing so causes excessive engine wear.
Page 664 7-3. Do-it-yourself maintenance Draining the fuel filter water (diesel engine only) The water in the fuel filter must be drained immediately if the following symptom occurs:  Vehicles with the multi-information display type A When the fuel filter warning light comes on (1KD-FTV engine for South Africa and 5L-E engine) or the fuel system warning light flashes (1KD-FTV engine except for South Africa and 1GD-FTV engine) and buzzer sounds.
Page 665: Tires
Replace the tire if the treadwear indicators are showing on a tire. Tire rotation Rotate the tires in the order shown. To equalize tire wear and help extend tire life, Toyota recom- mends that you rotate your tires approximately every 5000 Front (3000 miles).
Page 666 7-3. Do-it-yourself maintenance Tire pressure warning system (if equipped) Your vehicle is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire infla- tion pressure before serious problems arise. ● If the tire pressure drops below a predetermined level, the driver is warned by a warning light.
Page 667 7-3. Do-it-yourself maintenance How to initialize the tire pressure warning system ■ Park the vehicle in a safe place and turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry & start system). Initialization cannot be performed while the vehicle is moving.
Page 668 7-3. Do-it-yourself maintenance ◆ Registering ID codes The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code. When registering the ID codes, perform the following procedure: How to register the ID codes ■...
Page 669 A tire goes flat repeatedly or cannot be properly repaired due to the size or ● location of a cut or other damage If you are not sure, consult with your Toyota dealer. Replacing tires and wheels (vehicles with the tire pressure warning sys- ■...
Page 670 In the following cases, the tire pressure warning system may not operate ● properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 671 10 to 30 minutes. If initialization is still not complete, have the vehicle inspected by your Toyota dealer. : Except when making a left/right turn ● In the following situations, the tire inflation pressure will not be recorded and the system will not operate properly.
Page 672 7-3. Do-it-yourself maintenance ■ When registering ID codes (vehicles with the tire pressure warning sys- tem) Initialize the tire pressure warning system after ID code registration. Initial- ● ization is disabled if the system was initialized before registration. ● After ID code registration, the tires are hot by driving. Initialize the tire pres- sure warning system after the tires become cold.
Page 673 10 to 30 minutes. If registration is still not complete, have the vehicle inspected by your Toyota dealer. : Except when making a left/right turn ● When the tire pressure warning light does not blink slowly 3 times, the ID code will not be registered and the system will not operate properly.
Page 674 7-3. Do-it-yourself maintenance ■ Certification for tire pressure warning system  For vehicles sold in Tahiti, New Caledonia and Saint Martin LC150_OM_OM60R93E_(GE)
Page 675 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 676 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 677 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 678 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 679 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 680 7-3. Do-it-yourself maintenance LC150_OM_OM60R93E_(GE)
Page 681 7-3. Do-it-yourself maintenance  For vehicles sold in the United Arab Emirates  For vehicles sold in Jordan  For vehicles sold in South Africa LC150_OM_OM60R93E_(GE)
Page 682 7-3. Do-it-yourself maintenance  For vehicles sold in Taiwan  For vehicles sold in Morocco LC150_OM_OM60R93E_(GE)
Page 683 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 684 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
Page 685: Tire Inflation Pressure
Reduced tire life due to wear ● ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: Check only when the tires are cold.
Page 686 7-3. Do-it-yourself maintenance WARNING Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: Excessive wear ●...
Page 687: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 688 ■ When replacing wheels (vehicles with the tire pressure warning system) The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advance warning in the event of a loss in tire inflation pressure. Whenever wheels are replaced, tire pressure warning valves and transmitters must be installed.
Page 689 ● Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 690: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with a smart entry & start system: Turn the engine switch off.
Page 691 7-3. Do-it-yourself maintenance Remove the filter cover. Replace it with a new one. The “UP” marks shown on the filter should be pointing up. ■ Changing interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required.
Page 692: Wireless Remote Control/Electronic Key Battery
7-3. Do-it-yourself maintenance Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver (vehicles with a smart entry & start sys- tem) ●...
Page 693 7-3. Do-it-yourself maintenance Open the case cover using a coin protected with tape etc. and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. When installing, reverse the steps listed. Vehicles with a smart entry & start system ...
Page 694 7-3. Do-it-yourself maintenance Remove the depleted battery. When removing the cover, if the battery cannot be seen due to the electronic key module attaching to the upper cover, remove the elec- tronic key module from the cover so that the battery is visible as shown in the illustration.
Page 695 Vehicles without a smart entry & start system: CR2016 Vehicles with a smart entry & start system: CR2032 ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. Replace only with the same or equivalent type recommended by the manu- ●...
Page 696 7-3. Do-it-yourself maintenance NOTICE For normal operation after replacing the battery ■ Observe the following precautions to prevent accidents: ● Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other component inside the remote control. ●...
Page 697: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 698 Type A Replace the blown fuse with one of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type B, C, D and E Contact your Toyota dealer. Type A Type B ...
Page 699 7-3. Do-it-yourself maintenance  Type C  Type D  Type E LC150_OM_OM60R93E_(GE)
Page 700 Never use a fuse of a higher amperage rating than indicated, or use any ● other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. Do not modify the fuses or fuse boxes. ●...
Page 701: Light Bulbs
Light bulbs You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 702 7-3. Do-it-yourself maintenance Rear ■ Vehicles with under floor mounted spare tire  Running board lights Rear fog light (if equipped) (if equipped) License plate lights Rear turn signal light Back-up light  Vehicles with back door mounted spare tire Running board lights Rear fog light (if equipped) (if equipped)
Page 703 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beams (halogen headlights) ■ Unplug the connector while depressing the lock release. Turn the light bulb counter- clockwise. Replace the light bulb. Align the 3 tabs on the light bulb with the mounting, and insert. Turn and secure the light bulb.
Page 704 7-3. Do-it-yourself maintenance Set the connector. Shake the light bulb gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. Headlight high beams (halogen headlights) ■...
Page 705 7-3. Do-it-yourself maintenance Turn and secure the light bulb. Set the connector. Shake the light bulb gently to check that it is not loose, turn the headlights on once and visu- ally confirm that no light is leak- ing through the mounting. Front position lights (vehicles without daytime running light ■...
Page 706 7-3. Do-it-yourself maintenance Open the fender liner. Turn the bulb base counter- clockwise. The shape of the bulb base dif- fers slightly on the let and right sides. Remove the light bulb. When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 707 7-3. Do-it-yourself maintenance Front turn signal lights ■ Remove the fender liner bolts. To allow enough working space, turn the steering wheel to the opposite side of the bulb to be replaced. Open the fender liner. LC150_OM_OM60R93E_(GE)
Page 708 7-3. Do-it-yourself maintenance Turn the bulb base counterclockwise. Vehicles with halogen head- Vehicles with LED headlights   lights Remove the light bulb. When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 709 7-3. Do-it-yourself maintenance Rear turn signal lights and back-up lights ■ Open the back door.  Left-hand side Remove the bolts and lamp assembly.  Right-hand side Remove the bolts. Close the back door half way and remove the lamp assembly.
Page 710 7-3. Do-it-yourself maintenance Unplug the connector while pushing the lock release. Turn the bulb bases counter- clockwise. Rear turn signal light Back-up light Remove the light bulb. Rear turn signal light Back-up light When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 711 7-3. Do-it-yourself maintenance Rear fog lights (if equipped) ■ Remove the under cover bolts and pull down the under cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 712 7-3. Do-it-yourself maintenance License plate lights ■ Vehicles with under floor mounted spare tire  Remove the screws. Remove lens license plate light unit. Remove the light bulb. When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 713 7-3. Do-it-yourself maintenance  Vehicles with back door mounted spare tire Remove the screws. Remove lens license plate light unit. Remove the light bulb. When installing, reverse the steps listed. LC150_OM_OM60R93E_(GE)
Page 714 Lights other than the above ■ If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Headlight low beams (LED headlights) ● Headlight high beams (LED headlights) ● Front position lights/daytime running lights ●...
Page 715 ■ Condensation build-up on the inside of the lens Temporary condensation build-up on the inside of the headlight lens does not indicate a malfunction. Contact your Toyota dealer for more information in the following situations: ● Large drops of water are built up on the inside of the lens.
Page 716: When Trouble Arises
When trouble arises 8-1. Essential information 8-2. Steps to take in an emergency Emergency flashers...716 If your vehicle needs If your vehicle has to to be towed ......720 be stopped in an emergency.......717 If you think something is wrong ......727 If the vehicle is trapped in rising water ......719 Fuel pump shut off system...
Page 717: Essential Information
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road due to a breakdown, etc. 5L-E engine Except for 5L-E engine   Press the switch. All the turn signal lights will flash.
Page 718: If Your Vehicle Has To Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 719 8-1. Essential information Vehicles with a smart entry & start system: To stop the engine, press and hold the engine switch for 2 consecutive seconds or more, or press it briefly 3 times or Press and hold for 2 seconds or more, more in succession.
Page 720: If The Vehicle Is Trapped In Rising Water
However, an emergency hammer can not shatter the windshield as it is lam- inated glass. : Contact your Toyota dealer or aftermarket accessory manufacturer for fur- ther information about an emergency hammer. Escaping the vehicle from the window ■...
Page 721: Steps To Take In An Emergency If Your Vehicle Needs To Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or a flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 722 8-2. Steps to take in an emergency Towing with a wheel-lift type truck  From the front  From the rear Use a towing dolly under the rear Use a towing dolly under the wheels. front wheels. Using a flatbed truck If your vehicle is transported by a flatbed truck, it should be tied down at the locations shown in the...
Page 723 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing hooks. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
Page 724 8-2. Steps to take in an emergency Emergency towing procedure Vehicles with front spoilers: Remove the front spoilers. Turn and pull out the clips. Move the front spoilers in the direction of the arrow, and then remove it. Securely attach cables or chains to the towing hooks. Take care not to damage the vehicle body.
Page 725 8-2. Steps to take in an emergency Vehicles without a smart entry & start system: Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to the “ON” posi- tion. Vehicles with a smart entry & start system: Enter the vehicle being towed and start the engine.
Page 726 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When towing the vehicle Be sure to transport the vehicle with all four wheels raised off the ground. If the vehicle is towed with the tires contacting the ground, the drivetrain or related parts may be damaged, the vehicle may fly off...
Page 727 8-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle when towing using a wheel-lift type ■ truck ● Vehicles without a smart entry & start system: Do not tow the vehicle from the rear when the engine switch is in the “LOCK” position or the key is removed.
Page 728: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
Page 729: Fuel Pump Shut Off System (Gasoline Engine Only)
8-2. Steps to take in an emergency Fuel pump shut off system (gasoline engine only) To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 730: If A Warning Light Turns On Or A Warning Buzzer Sounds
• The brake fluid level is low; or • The brake system is malfunctioning.  Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Page 731 SRS warning light Indicates a malfunction in: • The SRS airbag system; or • The seat belt pretensioner system.  Have the vehicle inspected by your Toyota dealer immediately. ABS warning light Indicates a malfunction in: • The ABS/Multi Terrain ABS (if equipped); or •...
Page 732 • The Crawl Control (If equipped). The light will flash when any of the above systems other than the Multi-terrain Select are operating.  Have the vehicle inspected by your Toyota dealer immediately. Automatic transmission fluid temperature warning light • Indicates that the automatic transmission fluid tempera- ture is too high if the light comes on.
Page 733 • The amount of accumulated water in the fuel filter has reached the specified level if the light flashes.  P. 663 • Malfunction in the fuel system if the light comes on.  Have the vehicle inspected by your Toyota dealer (If equipped) (Comes on or flashes) immediately.
Page 734 Toyota dealer. When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system  Have the system checked by your Toyota dealer. Low windshield washer fluid warning light Low level of washer fluid  Fill the tank.
Page 735 8-2. Steps to take in an emergency Warning light Warning light/Details/Actions Automatic headlight leveling system warning light Indicates a malfunction in the automatic headlight leveling system  Have the vehicle inspected by your Toyota dealer (If equipped) immediately. Toyota parking assist-sensor...
Page 736 8-2. Steps to take in an emergency : Vehicles with the multi-information display type B: This light illuminates on the multi-information display. : Open door warning buzzer: The open door warning buzzer sounds to alert one or more of the doors is not fully closed (with the vehicle having reached a speed of 5 km/h [3 mph]).
Page 737 8-2. Steps to take in an emergency : Saudi Arabia, Sultanate of Oman, Bahrain, United Arab Emirates, Qatar, Kuwait : The speed warning buzzer will sound if your vehicle speed reaches or exceeds 120 km/h (75 mph) and will stop sounding after 6 seconds or if you decelerate below 120 km/h (75 mph).
Page 738 8-2. Steps to take in an emergency Smart entry & start system warning light and buzzer procedures (vehicles with the multi-information display type A) After taking the specified steps to correct the suspected problem, check that the warning light turns off. Interior Exterior Warning...
Page 739 8-2. Steps to take in an emergency Interior Exterior Warning Details/Actions buzzer buzzer light Indicates that a door other than the driver’s door has been opened or closed with the engine switch in any mode other than off, the shift lever was in P (auto- Sounds matic transmission) or N (manual trans- Once...
Page 740 Go to service warning light (warning buzzer) Indicates a malfunction in the electronic engine control system or electronic throttle control system.  Have the vehicle inspected by your Toyota dealer (If equipped) Front passenger detection sensor and passenger seat belt reminder ■...
Page 741 “ON” position (vehicles without a smart entry & start system) or IGNITION ON mode (vehicles with a smart entry & start system), have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 742 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 743: If A Warning Message Is Displayed
Multi-information display Handling method Follow the instructions of the mes- sage on the multi-information dis- play. If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer.  : If equipped LC150_OM_OM60R93E_(GE)
Page 744 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 745 ■ If “Engine oil pressure low” is shown (if equipped) Indicates abnormal engine oil pressure. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. ■ If a message instructing to refer to the Owner’s Manual is displayed ●...
Page 746 If “Check air suspension system” is shown (vehicles with the rear height control air suspension) Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. Refer to the “Off-road Driving Owner’s Manual” for more information regard- ing rear height control air suspension.
Page 747 ■ If “Visit Your Dealer” is shown The system or part shown on the multi-information display is malfunctioning. Have the vehicle inspected by your Toyota dealer immediately. ■ Warning buzzer In some cases, the buzzer may not be heard due to being in a noisy location or audio sound.
Page 748: If You Have A Flat Tire
8-2. Steps to take in an emergency If you have a flat tire Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 664 WARNING If you have a flat tire ■...
Page 749 8-2. Steps to take in an emergency Location of the spare tire, jack and tools  Vehicles with under floor mounted spare tire Jack Tool box Spare tire LC150_OM_OM60R93E_(GE)
Page 750 8-2. Steps to take in an emergency  Vehicles with back door mounted spare tire 5-door models 3-door models Jack Spare tire Tool box LC150_OM_OM60R93E_(GE)
Page 751 8-2. Steps to take in an emergency WARNING Using the tire jack ■ Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Do not use the tire jack for any purpose other than replacing tires or install- ●...
Page 752 8-2. Steps to take in an emergency Taking out the jack Remove the cover.  3-door models  5-door models Unhook the rubber band and take out the jack. For loosening For tightening 3-door models 5-door models   LC150_OM_OM60R93E_(GE)
Page 753 8-2. Steps to take in an emergency Taking out the tool box Open the cover. Take out the tool box. LC150_OM_OM60R93E_(GE)
Page 754 8-2. Steps to take in an emergency Taking out the spare tire cover (if equipped) Remove the bolt cover Bolt cover Remove the bolt which fixes the spare tire cover. Unlock the latch and unhook the spare tire cover. Opening the back door makes unlocking the latch easier.
Page 755 8-2. Steps to take in an emergency Taking out the spare tire  Vehicles with back door mounted spare tire Unlock the spare tire lock sys- tem. Insert the key into the cylin- der. Remove the key and the cyl- inder.
Page 756 8-2. Steps to take in an emergency  Vehicles with under floor mounted spare tire Assembling the jack handle. Remove the jack handle and the jack handle extension bar from the tool box and assemble by following these steps. Loosen the bolt and the screw using either the jack handle end or a screwdriver.
Page 757 8-2. Steps to take in an emergency Insert the jack handle extension into the lowering screw. Lower Raise Place a rag under the jack han- dle extension to protect the rear bumper. Lower the spare tire completely to the ground. Pull out the spare tire and remove the holding bracket.
Page 758 8-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Flat tire Wheel chock positions Left-hand side Behind the rear right-hand side tire Front Right-hand side Behind the rear left-hand side tire Left-hand side In front of the front right-hand side tire Rear Right-hand side In front of the front left-hand side tire...
Page 759 8-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack handle bar from the tool box and assemble by following these steps. Loosen the bolt and the screw using either the jack handle end or a screwdriver.
Page 760 8-2. Steps to take in an emergency Position the jack at the jack points as shown. Front Under the chassis frame side rail Rear Under the rear axle housing Raise the vehicle until the tire is slightly raised off the ground. Remove all the wheel nuts and the tire.
Page 761 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing a tire, only use wheel nuts that have been specifically designed for that wheel.
Page 762 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire to come off.
Page 763 8-2. Steps to take in an emergency Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque Steel wheels: 112 N•m (11.4 kgf•m, 83 ft•lbf) Aluminum wheels: 103 N•m (10.5 kgf•m, 76 ft•lbf) Reinstall the wheel ornament.
Page 764 8-2. Steps to take in an emergency Stowing the flat/spare tire, jack and tools  Vehicles with back door mounted spare tire Install the tire and loosely tighten each nut by hand to approximately same amount. Spare tire lock nut Firmly tighten each nut two or three times in the order shown in the illustration.
Page 765 8-2. Steps to take in an emergency  Vehicles with under floor mounted spare tire Lay down the tire with the valve stem facing up and install the holding bracket, inserting the claw into the wheel lug nut hole. Turn the jack handle extension clockwise to take up slack in incorrect the chain.
Page 766 8-2. Steps to take in an emergency Confirm that the tire is not loose after tightening: Push and pull the tire Try rotating Visually check to ensure the tire is not hung on surrounding parts. If looseness or misassembly exists, repeat step and step Repeat step , any time the tire is lowered or disturbed.
Page 767 8-2. Steps to take in an emergency WARNING After using the tools and jack ■ Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.
Page 768: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 291, 295), consider each of the fol- lowing points: The engine will not start even when the starter motor operates normally.
Page 769 ● There may be a malfunction in the steering lock system. (vehicles with a smart entry & start system) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart entry & start...
Page 770: If The Electronic Key Does Not Operate Properly (Vehicles With A Smart Entry & Start System)
Locks all doors Closes the windows and moon roof (turn and hold) Unlocks all doors Opens the windows and moon roof (turn and hold) : These settings must be customized at your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 771 8-2. Steps to take in an emergency Starting the engine  Automatic transmission Ensure that the shift lever is in P and depress the brake pedal. Touch the Toyota emblem side of the electronic key to the engine switch. When electronic...
Page 772 8-2. Steps to take in an emergency ■ Stopping the engine  Vehicles with an automatic transmission Shift the shift lever to P and press the engine switch as you normally do when stopping the engine.  Vehicles with a manual transmission Shift the shift lever to N and press the engine switch as you normally do when stopping the engine.
Page 773: If The Vehicle Battery Is Discharged
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your Toyota following the steps below. Confirm that the key is being carried.
Page 774 8-2. Steps to take in an emergency  1GD-FTV engine Lift the edge of the cover to disen- gage the fixed pins, and then pull the cover towards you to remove Connect the jumper cables according to the following procedures: Positive (+) battery terminal on your vehicle Positive (+) battery terminal on the second vehicle Negative (-) battery terminal on the second vehicle...
Page 775 8-2. Steps to take in an emergency  1GR-FE engine  2TR-FE engine LC150_OM_OM60R93E_(GE)
Page 776 8-2. Steps to take in an emergency  5L-E engine  1KD-FTV engine LC150_OM_OM60R93E_(GE)
Page 777 Vehicles with 1GR-FE and 1GD-FTV engines: To install the engine cover, conduct the removal procedure in reverse. After installing, check that the fixed pins are inserted securely. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. LC150_OM_OM60R93E_(GE)
Page 778 8-2. Steps to take in an emergency ■ Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting. ■ To prevent battery discharge ● Turn off the headlights and the audio system while the engine is off. Turn off any unnecessary electrical components when the vehicle is running ●...
Page 779 8-2. Steps to take in an emergency WARNING Avoiding battery fires or explosions ■ Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery: Make sure the jumper cable is connected to the correct terminal and that it ●...
Page 780: If Your Vehicle Overheats
Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radiator) for any leaks. Radiator Radiator cooling fan Cooling fan (if equipped) If a large amount of coolant leaks, immediately contact your Toyota dealer. LC150_OM_OM60R93E_(GE)
Page 781 8-2. Steps to take in an emergency The coolant level is satisfactory if it is between the “FULL” and “LOW”/“F” and “L” lines on the reservoir. Reservoir “FULL” or “F” “LOW” or “L” Radiator cap (if equipped) Add coolant if necessary. Water can be used in an emergency if coolant is unavailable.
Page 782 8-2. Steps to take in an emergency If the fans are not operating: Stop the engine immediately and contact your Toyota dealer. If the fans are operating: Have the vehicle inspected at the nearest Toyota dealer. WARNING When inspecting under the hood of your vehicle ■...
Page 783: If You Run Out Of Fuel And The Engine Stalls (Diesel Engine Only)
If the engine does not start after the above steps have been performed, wait for 10 seconds and try step again. If the engine still does not start, contact your Toyota dealer. After starting the engine, depress the accelerator pedal lightly until the engine runs smoothly.
Page 784: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow: Stop the engine. Set the parking brake and put the shift lever in P (automatic transmission) or N (manual transmission).
Page 785 8-2. Steps to take in an emergency WARNING When attempting to free a stuck vehicle ■ If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear, to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 786 Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...786 Fuel information ....823 9-2. Customization Customizable features ..826 9-3. Items to initialize Items to initialize ....838 LC150_OM_OM60R93E_(GE)
Page 787: 9-1. Specifications
9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions 4840 mm (190.6 in.) 5-door models 5010 mm (197.2 in.) 4980 mm (196.1 in.) Overall length 4565 mm (179.7 in.) 3-door models 4535 mm (178.5 in.) Overall width 1885 mm (74.2 in.) 5, 6 1835 mm (72.2 in.) 5, 7...
Page 788 9-1. Specifications  Weights (with towing hitch) 2830 kg (6239 lb.) 1GR-FE engine 2900 kg (6393 lb.) 2950 kg (6504 lb.) 2600 kg (5732 lb.) 2TR-FE engine Gross vehicle 2850 kg (6283 lb.) mass 5L-E engine 2990 kg (6592 lb.) 1KD-FTV engine 2990 kg (6592 lb.) 1GD-FTV engine...
Page 789 9-1. Specifications : 2-seat models : Except for 9-seat GRJ150L-GKTEKV models with sub fuel tank sys- tem, VX grade 7-seat GRJ150L-GKTEKV models with sub fuel tank system, VX-E grade 7-seat GRJ150L-GKTEKV models with sub fuel tank system and 2-seat models : 9-seat GRJ150L-GKTEKV models with sub fuel tank system, VX grade 7-seat GRJ150L-GKTEKV models...
Page 790 The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. It is forbidden to cover, paint, weld, drill, alter or remove the vehicle identification number (VIN).
Page 791 9-1. Specifications This number is also on the manufacturer’s label (except GCC countries ) or the Certifi- cation Regulation label (GCC countries ) on the left-hand side pillar. : Saudi Arabia, Sultanate of Oman, Bahrain, United Arab Emirates, Qatar, Kuwait Year of manufacture and country of origin (GCC countries ■...
Page 792 9-1. Specifications Engine number ■ The engine number is stamped on the engine block as shown. 1GR-FE engine 2TR-FE engine   5L-E engine 1KD-FTV engine    1GD-FTV engine LC150_OM_OM60R93E_(GE)
Page 793 9-1. Specifications Engine  Gasoline engine Model 1GR-FE 2TR-FE 6-cylinder V type, 4-cylinder in line, Type 4-cycle, gasoline 4-cycle, gasoline 94.0  95.0 mm 95.0  95.0 mm Bore and stroke (3.70  3.74 in.) (3.74  3.74 in.) Displacement 3956 cm (241.4 cu.in.) 2694 cm (164.4 cu.in.)
Page 794 9-1. Specifications  Diesel engine Model 5L-E, 1KD-FTV, 1GD-FTV  5L-E engine 4-cylinder in line, 4-cycle, diesel Type  1KD-FTV, 1GD-FTV engine 4-cylinder in line, 4-cycle, diesel (with turbo- charger)  5L-E engine 99.5  96.0 mm (3.92  3.78 in.) ...
Page 795 9-1. Specifications  5L-E engine 10.0  14.0 mm (0.39  0.55 in.) : 15.0  20.0 mm (0.59  0.79 in.) : 10.0  15.0 mm (0.39  0.59 in.) Drive belt tension  1KD-FTV, 1GD-FTV engine Automatic adjustment ...
Page 796 For Argentina Fuel type Unleaded gasoline which does not contain metallic additives (Manga- nese-based, etc.) only For details about gasoline, contact your Toyota dealer.  Except for Argentina Unleaded gasoline only  1GR-FE engine 95 (Octane rating 91) or higher Research octane number ...
Page 797 9-1. Specifications  Diesel engine  1KD-FTV and 5L-E engine Diesel fuel only  1GD-FTV engine When you find these types of fuel label at the gas station, use only the fuel Fuel type with one of the following labels. Diesel fuel that contains 10 ppm or less of sulfur Cetane number...
Page 798 : EURO III is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 799 9-1. Specifications Recommended viscosity (SAE): If you use SAE 10W-30 or a higher viscosity engine oil in extremely low temperatures, the engine may become difficult to start, so SAE 5W-30 engine oil is recommended. Temperature range anticipated before next oil change Oil viscosity (5W-30 is explained here as an example): •...
Page 800 : EURO IV is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity.
Page 801 9-1. Specifications How to read oil container labels: Either or both API registered marks are added to some oil contain- ers to help you select the oil you should use. API Service Symbol Top portion: “API SERVICE SN” means the oil quality designa- tion by American Petroleum Ins- titute (API).
Page 802 : EURO V is emission standards. If it is not clear that your vehicle meets rel- evant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 803 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 804 : EURO III is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 805 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 806 : EURO III is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 807 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 808 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity. Oil grade: API CF-4, CF or ACEA B3, B4, B5 or JASO DL-0...
Page 809 9-1. Specifications How to read oil container label: Japanese Automobile Standard Organization (JASO) DL-0 Mark is added to some oil containers to help you select the oil you should use. Oil viscosity (10W-30 is explained here as an example): • The 10W in 10W-30 indicates the characteristic of the oil which allows cold startability.
Page 810 : EURO IV is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 811 9-1. Specifications How to read oil container label: Japanese Automobile Standard Organization (JASO) DL-0 Mark is added to some oil containers to help you select the oil you should use. Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability.
Page 812 : EURO IV is an emission standard. If it is not clear that your vehicle meets relevant standards, contact your Toyota dealer. “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat- isfy the following grade and viscosity.
Page 813 Engine oil selection ■ “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Toyota recommends the use of approved “Toyota Genuine Motor Oil”. Another motor oil of matching quality can also be used.
Page 814 9-1. Specifications Cooling system  With rear air conditioning system With 12.8 L (13.5 qt., 11.3 Imp.qt.)  Without rear air conditioning warmer system With auto- 11.0 L (11.6 qt., 9.7 Imp.qt.) matic  With rear air conditioning trans- system mission With- 12.3 L (13.0 qt., 10.8 Imp.qt.)
Page 815  Without rear air conditioning system 10.1L (10.7 qt., 8.9 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • A similar high-quality eth- ylene glycol-based non-sili- Coolant type cate, non-amine, non-nitrite, and non-borate coolant with...
Page 816 9-1. Specifications Ignition system (spark plug of the gasoline engine) 1GR-FE engine DENSO SK16HR11 Make 2TR-FE engine DENSO FK20HR-A8 1GR-FE engine 1.1 mm (0.043 in.) 2TR-FE engine 0.8 mm (0.032 in.) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system Battery ■...
Page 817 Toyota Genuine Differential Gear Oil LT Oil type and viscosity 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equiva- lent oil of matching quality to satisfy the above specification.
Page 818 Toyota dealer. NOTICE Transmission fluid type ■ Using transmission fluid other than “Toyota Genuine ATF WS” may cause shift quality, locking up of the transmission accompanied by vibration and, ultimately, damage to the vehicle’s transmission. Manual transmission ...
Page 819 Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 820 9-1. Specifications Brakes 1GR-FE, 1KD-FTV and 1GD-FTV 104 mm (4.1 in.) Min. engines  With automatic transmission Pedal 105 mm (4.1 in.) Min. Left-hand clear- 2TR-FE drive  With manual transmission ance 102 mm (4.0 in.) Min. 5L-E engines Right- hand 108 mm (4.3 in.) Min.
Page 821 9-1. Specifications Chassis lubrication (Propeller shafts) Spider Lithium base chassis grease, NLGI No.2 Molybdenum-disulfide lithium base chassis grease, Slide yoke NLGI No.2 or lithium base chassis grease, NLGI No.2 Steering Free play Less than 30 mm (1.18 in.) ® Power steering fluid type Automatic transmission fluid DEXRON II or III Tires and wheels...
Page 822 9-1. Specifications  18-inch tires Tire size 265/60R18 110H Front tire Rear tire Tire inflation pressure (kgf/cm or bar, psi) (kgf/cm or bar, psi) (Recommended cold tire inflation pressure) 200 (2.0, 29) 200 (2.0, 29) 220 (2.2, 32) 18  7 1/2J Wheel size Wheel nut torque 103 N•m (10.5 kgf•m, 76 ft•lbf)
Page 823 9-1. Specifications Light bulbs Light bulbs Type Headlights (halogen bulbs Low beam High beam Front turn signal lights Front position lights (halogen bulbs Exterior Rear turn signal lights Back-up lights Rear fog lights License plate lights Running board lights Personal/interior lights Front Rear (without personal lights) Interior...
Page 824: Fuel Information
9-1. Specifications Fuel information ◆ Gasoline engine When you find these types of fuel label at the gas station, use only the fuel with one of the following labels.  1GR-FE engine For Argentina: You must only use unleaded gasoline. Select premium unleaded gasoline with a Research Octane Num- ber of 95 or higher for optimum engine performance.
Page 825 ■ Use of ethanol blended gasoline in a gasoline engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 10 %. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 826 9-1. Specifications NOTICE Notice on fuel quality ■ ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. Gasoline engine: Do not use gasoline with metallic additives, for example ● manganese, iron or lead, otherwise it may cause damage on your engine or emission control system.
Page 827: 9-2. Customization
The settings of these fea- tures can be changed by using the steering wheel switches, nav- igation system, multimedia system or at your Toyota dealer. It is also possible to customize certain vehicle features yourself using the multi-information display.
Page 828 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using the meter control switches Settings that can be changed using the navigation system or the...
Page 829 9-2. Customization Smart entry & start system and wireless remote control ■ (  P. 133, 185) Customized Function Default setting setting Operation signal (buzzer) Level 5 – Level 1 to 7 Operation signal (Emer- – gency flashers) Time elapsed before the 60 seconds automatic door lock func- tion is activated if a door is...
Page 830 9-2. Customization Wireless remote control (  P. 133) ■ Customized Function Default setting setting Wireless remote control – – Driver’s door unlocked doors one step, all Unlocking operation unlocked – doors one step unlocked two steps (  P. 235) Driving position memory ■...
Page 831 9-2. Customization Interior lights (  P. 579) ■ Customized Function Default setting setting Time elapsed before the 15 seconds 7.5 seconds – interior lights turn off 30 seconds Operation after the engine switch is turned to the “LOCK” position (without a smart entry &...
Page 832 9-2. Customization Exterior lights (P. 579) ■ Customized Function Default setting setting Time elapsed before the 15 seconds 7.5 seconds – exterior lights turn off 30 seconds Operation of the outer foot lights and the running board lights when you –...
Page 833 9-2. Customization Meters (P. 111) ■ Customized Function Default setting setting Sensitivity of the ambient light sensor used for dim- Standard -2 to 2 – – ming the meter lights etc. Sensitivity of the ambient light sensor used Standard -2 to 2 –...
Page 834 9-2. Customization Power windows (  P. 252) and moon roof 1, 2 (  P. 256) ■ Customized Function Default setting setting Mechanical linked – – operation (close) Mechanical linked – – operation (open) Wireless remote control – – linked operation (close) Wireless remote control...
Page 835 9-2. Customization 1, 2 (  P. 407) Toyota parking assist-sensor ■ Customized Function Default setting setting Detection distance of the Near – front center sensor Detection distance of the Near – rear center sensor Buzzer volume Level 5 Level 1 to 5 –...
Page 836 9-2. Customization Multi-information display (P. 119) ■ Customized Function Default setting setting English (American) French German Spanish English Italian Language – (British) Traditional Chinese Russian Turkish Arabic Units km (km/L) – (L/100km) Driving Indicator – Light Desired status switch settings After start –...
Page 837 9-2. Customization LDA (Lane Departure Alert) (P. 378) ■ Default Customized Function setting setting Alert sensitivity Standard High – Vehicle sway warning – function Vehicle sway warning Standard – sensitivity High : If equipped BSM (Blind Spot Monitor) (P. 462) ■...
Page 838 9-2. Customization ■ In the following situations, customize mode will automatically be turned off. A warning message appears after the customize mode screen is displayed. ● ● The engine switch is turned to the “LOCK” position (without a smart entry & start system) or the engine switch is turned to OFF (with a smart entry &...
Page 839: 9-3. Items To Initialize
9-3. Items to initialize Items to initialize The following item must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference • When rotating the tires •...
Page 840: Index
Index What to do if... (Troubleshooting) .....840 Alphabetical index ......844 For vehicles with a navigation system or a multimedia sys- tem, refer to the “Navigation System Owner’s Manual”, “Nav- igation and Multimedia System Owner’s Manual” or “Multimedia Owner’s Manual” for information regarding the equipment listed below.
Page 841 You lose your keys ● If you lose your keys or mechanical keys, new genuine keys or mechanical keys can be made by your Toyota dealer. (P. 134) ● Vehicles with a smart entry & start system If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 842 What to do if... (Troubleshooting) If you think something is wrong The engine does not start (vehicles without a smart entry & start system) ● Vehicles with a manual transmission Do you turn the key with the clutch pedal depressed firmly? (P. 291) ●...
Page 843 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without a smart entry & start system It is locked to prevent theft of the vehicle if the key is removed from the engine switch.
Page 844 What to do if... (Troubleshooting) An alarm is activated and the horn sounds (if equipped) ● Did anyone inside the vehicle open a door during setting the alarm? The sensor detects it and the alarm sounds. (P. 93) To stop the alarm, turn the engine switch to IGNITION ON mode or start the engine.
Page 845: Alphabetical Index
Alphabetical index Alphabetical index Anchor brackets ......81 Antennas (smart entry & start A/C..... 552, 558, 567, 569 system)........185 Air conditioning filter....689 Anti-lock brake system Active Traction Control ..455 (ABS) ........455 ABS (Anti-lock Brake Function ........ 455 System) ........
Page 846 Alphabetical index Back door ......... 172 Care........612, 617 Back-up lights Aluminum wheels....613 Replacing light bulbs..... 708 Exterior ......... 612 Wattage......... 822 Interior........617 Battery ........655 Seat belts......618 Battery checking ....655 Cargo hooks......593 If the vehicle battery is Center differential discharged ......
Page 847 Alphabetical index Installing child restraints..73 Moon roof precautions ..259 DAC (Downhill Assist Control Power window lock switch ..252 system) Power window precautions ... 255 Daytime running light Rear door child-protectors ..167 system........333 Removed key battery Defogger precautions ......
Page 848 Alphabetical index Driving ........262 If you run out of fuel and the AVS switch engine stalls ....... 782 Break-in tips ......265 If your vehicle becomes Correct posture .......36 stuck ........783 Driving mode select If your vehicle needs to be switches......
Page 849 Alphabetical index Front turn signal lights ... 316 Replacing light bulbs..... 706 Flat tire........747 Turn signal lever ....316 Floor mats ........34 Wattage ........ 822 Fluid Fuel ........... 795 Automatic transmission..817 Capacity........ 795 Brake........819 Fuel gauge......111 Clutch........
Page 850 Alphabetical index Hands-free system (for Identification cellular phone)....... 536 Engine........791 Head restraints......239 Vehicle ........789 Headlights ........ 324 Ignition switch (engine Automatic High Beam switch)......291, 295 system ........ 336 Ignition switch light....579 Follow me home system ..326 Illuminated entry system ..
Page 851 Alphabetical index Light Automatic High Beam Keyless entry system ........ 336 Smart entry & start Engine switch light ....579 system ......162, 172 Fog light switch ..... 341 Wireless remote Follow me home system ..326 control......162, 172 Headlight switch....
Page 852 Alphabetical index Meter ......... 111 Indicators ......102 Odometer........111 Instrument panel light control......... 113 Engine oil ......797 Meters ........111 Front differential oil ....816 Multi-information Rear differential oil....816 display ......115, 119 Opener Warning lights ....... 102 Back door......
Page 853 Alphabetical index Power heater ......572 Rear window wiper ....350 Power outlet ......604 Refueling ........354 Power steering Capacity........ 795 Warning light ......730 Fuel types ..... 354, 795 Power windows......252 Opening the fuel tank cap..356 Jam protection function..
Page 854 Steering wheel ......242 Automatic headlight Adjustment......242 system ........ 333 Audio switches...... 482 Inside rear view mirror ..246 Heated steering wheel ..575 Toyota parking Steering wheel position assist-sensor ...... 407 memory ......235 Rain-sensing windshield Stop/tail lights wipers ......... 348 Wattage ........
Page 855 Alphabetical index Switch Multi-terrain Select ON/OFF “2nd START” button....306 switch Airbag manual on-off Multi-terrain Select mode system ........57 selector dial Audio remote control “ODO TRIP” button ..113, 116 switches...... 482, 523 Outside rear view mirror Automatic High Beam switches......
Page 856 Initializing ......665 Trailer Sway Control ..... 456 Installing tire pressure Trailer towing ......277 warning valves and Toyota Safety Sense ....358 transmitters......665 Trailer Sway Control....456 Registering ID codes..... 667 TRC (Traction Control).... 455 Tire pressure warning Transmission reset switch......
Page 857 Downshifting ......309 Timing belt replacement ..731 Fuel system......732 Tire pressure......733 Key reminder......737 Toyota parking Open back door ....735 assist-sensor ...... 734 Open door ......735 Windshield washer fluid ..733 Seat belt remainder....735...
Page 858 Alphabetical index Warning reflector holder ..594 Washer........344 Checking ....... 659 Preparing and checking before winter....... 472 Switch ........344 Washing and waxing ....612 Weight........787 Welcome light illumination control ........335 Wheels ........686 Replacing wheels....686 Size ........
Page 859 Certification (for multimedia system) LC150_OM_OM60R93E_(GE)
Page 860 LC150_OM_OM60R93E_(GE)
Page 861 GAS STATION INFORMATION Auxiliary catch lever Fuel filler door P. 642 P. 356 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 642 P. 356 P. 820 Vehicles with sub 150 L (39.6 gal., 33.0 Imp.gal.) Fuel tank fuel tank system capacity Vehicles without sub...

Toyota LAND CRUISER PRADO Owner's Manual

1 For Safety and Security

2 Instrument Cluster

4 Driving

5 Audio System

6 Interior Features

7 Maintenance and Care

8 When Trouble Arises

Quick Links

Related Manuals for Toyota LAND CRUISER PRADO

Summary of Contents for Toyota LAND CRUISER PRADO
