1.0
IMPORTANT N N OTES
DO NOT use this heater immediately below a fixed socket outlet.
DO NOT use this heater in the immediate vicinity of a bath, shower or swimming pool.
CAUTION!: T T his h h eater m m ust n n ot b b e u u sed i i n c c onjunction w w ith a a ny t t imer, , p p rogramme o o r t t hermal c c ontrol, , o o r a a ny o o ther d d evice t t hat w w ill s s witch
on t t he a a ppliance a a utomatically, , a a s a a f f ire r r isk m m ay o o ccur i i f t t he h h eater i i s a a ccidentally c c overed o o r d d isplaced.
Do not allow the heater to be covered as this may cause overheating. The appliance must not be placed near curtains or similar material. A
clearance space of at least one metre should be allowed in front of the appliance.
The electrical socket that the appliance uses MUST be easily accessible. Do not route the supply cord directly below the heater unit. If the
cord is damaged, it must be replaced by a service agent or competent person.
2.0
INSTALLATION REQUIREMENTS
It is necessary for a suitable electrical socket to be located, and be easily accessible within a distance of 1.8 metres the appliance in order
that the prewired plug can reach this point.
The appliance is suitable for installation into all proprietary surrounds with an opening of 406mm by 559mm (16" by 22").
The appliance is supplied fitted with 2 spacer frames enabling it to be fitted with no need for a recess in to a wall or surround back panel.
Each spacer frame has a different depth, and once detached from the frame and fitted individually the mounting depths can be either 70 or
45mm. Alternatively the appliance can be fully recessed if the opening depth is 120mm or greater and neither spacer is used. To detach the
spacer assembly remove the screws located around the perimeter of the appliance frame. The two spacers can seperated by removing the
screws from their inside faces and then re-attached to the appliance frame, (if required) to give the correct recess depth. It may be installed
directly into any proprietary surround which can house this size of rebate, without the need to recess the appliance into a wall opening or
fabricate a false chimney breast.
This appliance should be positioned on a firm level surface that is free of dust and lint and should be maintained as such. If the fire is to be
sited in a fire surround then the suitability of the surround for use with electrical heaters should be established with the fire surround manu-
facturer.
3.0
APPLIANCE D D ATA
Supply Voltage
Heating Elements
If fitted into an open draught fireplace, it is advisable to blank off the chimney to reduce the risk of draught through the fire, which may cause
the safety cut out system in the fan heater to operate.
4.0
UNPACKING THE APPLIANCE
Read all the instructions before continuing to unpack or install this appliance. Remove the boxes/bags containing the marbles or other loose
fittings from around the heater. When all loose parts have been removed, carefully lift the appliance from the carton. Check that the contents
correlate with the component checklist below. Please dispose of all packaging with care at your local recycling centre.
4.1
COMPONENT CHECKLIST
QUA A NTITY
1
1
1
1
1
5.0
ASSEMBLING T T HE F F UEL B B ED
1.
Ensure that the appliance is disconnected from the mains.
2.
Remove the loose marbles from their packaging. Position the marbles onto the fuel bed 'shelf' evenly (after the Fireframe with
integral bars has been fitted) , so as to create a realistic effect.
Warning: The marbles supplied are for decorative effect only and can present a chok
ing hazard, especially to small children and pets. If children or animals are to be left
unsupervised in the same room as the appliance, it is recommended that a fireguard
guard (conforming to BS8423) should be installed for safety purposes.
