© 2007. All rights reserved. Black Box Corporation.
G.SHDSL Two-Wire Extender/NTUs
Use just two wires to extend Ethernet,
Use just two wires to extend Ethernet,
E1/T1, X.25, or V.35 networks and
E1/T1, X.25, or V.35 networks and
achieve G.SHDSL performance!
achieve G.SHDSL performance!
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
Advertisement
Related Manuals for Black Box LB510A
Summary of Contents for Black Box LB510A
- Page 1 © 2007. All rights reserved. Black Box Corporation. G.SHDSL Two-Wire Extender/NTUs Use just two wires to extend Ethernet, Use just two wires to extend Ethernet, E1/T1, X.25, or V.35 networks and E1/T1, X.25, or V.35 networks and achieve G.SHDSL performance! achieve G.SHDSL performance!
- Page 2 OVERVIEW Bring symmetric high-speed digital subscriber line tech- nology to your network users without spending extra for your cable infrastructure. The BLACK BOX ® G.SHDSL Two-Wire Extender/NTUs inter- face with Ethernet, T1/E1, X.21, or V.35 networks to extend services point-to-point to remote users at speeds up to 4.6 Mbps in both directions.
- Page 3 Web server and can be configured remotely from an IP network-based GUI simply by entering the LB510A’s IP address into a standard browser. Because it has an EOC management channel, the extender/NTU can be remotely managed end to end.
- Page 4 G.SHDSL: All: (1) RJ-45 (2-wire polarity insensitive on Pins 4 and 5); Console: All: (1) RJ-11 (RS-232) Indicators — LB510A: Power LED (solid yellow during normal operation); WAN: Link LED (solid yellow when DSL link in established, blinks when DSL link is in training);...
