Summary of Contents for Oricom Secure740
- Page 1 Video Baby Monitor Secure740 User Guide KEEP THIS USER GUIDE FOR FUTURE REFERENCE Always retain your proof of purchase in case of warranty service. AUSTRALIA: www.oricom.com.au...
-
Page 2: Table Of Contents
Do not leave your product unattended whilst charging the battery. Do not leave your child unattended with this product. Need Help? If you need assistance setting up or using your Oricom product now or in the future, call Oricom Support. Australia 02 4574 8888 www.oricom.com.au... -
Page 3: Safety Information
• It is very important that you read the User Guide carefully as it contains detailed information you will need to get the most from your Oricom baby monitor. If you have any issues setting up or using your Oricom baby monitor, please call our Customer Support team. - Page 4 Safety InformatIon • Never cover the parent or baby units with clothes, towels, blankets or any other item. Never use or place your parent or baby unit in or near moisture or water (e.g. near bath or pool). Immersing in water could cause electric shock and even death.
- Page 5 • If you believe the battery is damaged, remove product from the charger and stop using the product. Contact Oricom for assistance. Never use a damaged battery.
-
Page 6: Overview Of Functional Component Positions
oVerVIeW of fUnCtIonaL ComPonent PoSItIonS Disposal Always dispose of your products at the end of their life in accordance with your local waste disposal requirements. Packaging materials including cardboard and paper packaging, should be recycled in accordance with your local council waste regulations. Parent Unit 1 ON/OFF BUTTON 2 MENU AND BACK... - Page 7 1 Li-ion Polymer rechargeable battery pack for the parent unit 1 AC adaptor for the parent unit 1 User guide If any items are missing, contact Oricom customer support. WARNING: Rechargeable Lithium Ion batteries are potentially hazardous and can present a serious fire hazard if damaged, defective or improperly used.
-
Page 8: Setting Up Your Video Baby Monitor
SettIng UP yoUr VIdeo BaBy monItor 1. Setting up your Video Baby Monitor Power adaptor markings Please ensure you connect the correct power adaptor to parent and baby units. Each power adaptor is marked with a drawing showing the parent unit or camera unit as follows: Baby Unit Power Parent Unit Power... - Page 9 SettIng UP yoUr VIdeo BaBy monItor 1.1. Connecting the power adaptor for the baby unit • Connect the small plug of the adaptor to the back of the Baby Unit and the other end into the power socket. • Only use the included adaptor (5V DC/1A) Warning Do not place the AC Adaptor cable in a high "wear and tear"...
- Page 10 SettIng UP yoUr VIdeo BaBy monItor 1.2 Aligning the baby unit For optimal performance, place your baby unit between one and two metres away from your baby. Point the baby unit towards the baby. Check that the baby is suitably displayed on the parent unit screen. 1.3.
- Page 11 SettIng UP yoUr VIdeo BaBy monItor Desk stand In-use time and battery charging Depending on the usage, the parent unit will work for up to 8 hours on a fully charged battery with power save turned ON. When the battery charge becomes low on the parent unit, the battery icon will turn red.
- Page 12 When the in-use time becomes noticeably shorter than normal, it is time to purchase a new battery pack. How to purchase spare parts You can purchase battery packs (Part number: 2B0103) and extra camera units from Oricom www.oricom.com.au...
-
Page 13: Basic Operation Of The Keys
BaSIC oPerat Ion of the keyS 2. Basic operation of the keys PARENT UNIT Switch ON/OFF – Press and hold for 3 seconds ON/OFF BUTTON Screen Sleep/Wake – Briefly press MENU BUTTON Press to access the menu BACK KEY Press to return to previous option UP/DOWN BUTTONS Display brightness “+”... -
Page 14: Menu Options And Functions
menU oPtIonS and fUnCtIonS 3. MENU options and functions Camera Press MENU button. 1) Select Camera icon. Press “OK” button to confirm the selection. 2) Press add camera (SC740 supports up to 4 cameras). Press OK button to confirm the selection. 3) Press the “Pair”... - Page 15 menU oPtIonS and fUnCtIonS...
- Page 16 menU oPtIonS and fUnCtIonS View (multiple camera mode) Press MENU button: 1) Select the view icon for multiple camera options. Press “OK” button to confirm the selection. 2) Choose camera 1/ camera 2/ camera 3/camera 4 or choose to scan between the connected cameras.
- Page 17 menU oPtIonS and fUnCtIonS Lullabies Press MENU button: 1) Select the Lullabies icon. Press “OK” button to confirm the selection. 2) Choose the lullaby to play from the lullabies list. Your monitor will automatically replay the chosen lullaby. 3) Note: Select all to play all the lullabies. Select the VOL icon to adjust lullaby volume.
- Page 18 menU oPtIonS and fUnCtIonS Feeding Timer Press MENU button 1) Select Feeding Timer icon. Press “OK” button to confirm the selection. 2) Choose your preferred feeding reminder time. Once selected, a countdown will appear when monitor is in viewing mode. When the predefined time has elapsed, monitor will alarm for 5 seconds.
- Page 19 menU oPtIonS and fUnCtIonS Press MENU button 1) Select VOX icon. Press “OK” button to confirm the selection, when VOX is turned on, the screen and sound are muted. 2) Choose your preferred alarm sensitivity level. When this feature is turned on, your baby monitor will wake the screen, open the audio and sound an alarm when the noise level coming from the baby unit reaches the VOX threshold.
- Page 20 menU oPtIonS and fUnCtIonS...
-
Page 21: Settings
SettIngS 4. Settings... - Page 22 SettIngS 4.1 Language Setting You can select the language in the settings menu.
- Page 23 SettIngS 4.2 Brightness Setting You can set the brightness level in the settings menu.
- Page 24 SettIngS 4.3 Date & Time Setting You can set the date and time in the settings menu.
- Page 25 SettIngS 4.4 High-low Temperature alarm setting You can adjust the high and low temperature Alerts. When room temperature exceeds the limits set, parent unit will sound an alarm.
- Page 26 SettIngS 4.5 Temperature °C/°F switch You can switch between °C & °F in the Temp °C/°F setting.
- Page 27 SettIngS 4.6 Frequency You can switch between 60Hz & 50Hz in the Frequency setting.
- Page 28 SettIngS 4.7 Motion Detecting This feature will sound an audible alarm when motion is detected by the baby unit. You have the option to turn on an audible alarm alert by selecting "Alert Audible" or display alert only by selecting "ON". Note: When motion detection is turned on, zoom function is disabled.
- Page 29 SettIngS 4.8 Default Setting You can restore your monitor to its default factory settings with this option. Please note: System will lose all linked cameras and settings.
- Page 30 SettIngS 4.9 Power saving By turning this function ON, the monitor will enter power save mode within 10 seconds, The screen will be in sleep mode, and will only wake by briefly pressing the power button. Turn power saving ON when you turn on VOX or Motion detection.
-
Page 31: Customer Support
CUStomer SUPPort Customer Support Should you experience difficulties operating your SC740, please refer to the troubleshooting guide below. If you still experience difficulties, please contact Oricom Customer Support on (02) 4574 8888 for assistance. Troubleshooting Problems Solutions Equipment does − Check both parent unit and not function baby unit are turned on. -
Page 32: Troubleshooting
troUBLeShootIng No Link − Move the parent unit closer to displaying on the baby unit. parent unit Try resetting your monitor to avoid busy channels: 1. Turn both camera and parent units off and remove the battery i n t h e p a r e n t u n i t . L e a v e unplugged for 20 seconds. - Page 33 − After a period of time, the battery may need to be replaced due to everyday usage. Please visit www.oricom.com.au to purchase replacement batteries. Parent unit Move the parent unit closer beeping to the baby unit until they are within range.
-
Page 34: Express Warranty
In the event of a minor failure, Oricom reserves the right to choose to repair or replace the product. - Page 35 (30) days or for the remainder of the Express Warranty Period of the Oricom branded product in which they are installed, whichever is longer. During the Express Warranty Period, Oricom will where possible repair and if not replace the faulty product or part thereof.
- Page 36 Warranty Oricom will not be liable under this Express Warranty, and to the extent permitted by law will not be liable for any defect, loss, damage or injury arising out of or in connection with a: 1. Failure by you to adhere to the warnings and follow the instructions set out in this user guide for the proper installation and use of the product;...
- Page 37 Warranty How to make a claim under your Express Warranty in Australia Oricom has a simple warranty process for you to follow: • Please call or email our Customer Support Team, 02 4574 8888 or support@oricom.com.au. • A Customer Support Team member will verify after troubleshooting with you if your product qualifies under warranty.
- Page 38 Warranty Send the approved returns to: Oricom International Pty Ltd Locked Bag 658 South Windsor NSW 2756 Australia Please note that this Express Warranty excludes expenses incurred by you in returning any faulty product to us. You must arrange and pay any...
- Page 40 Oricom Support - Australia For all product enquiries, troubleshooting or to discuss the range of Oricom products, feel free to contact Oricom or visit our website for answers to frequently asked questions. (02) 4574 8888 Monday - Friday 8am –...
