MAINTENANCE
2. Partially pull out the axle (2).
3. Take out the caliper assembly by dislocating it
from the disc and the swing arm lug.
4. Carefully hang the caliper assembly in the
swing arm itself. Take out the spacer and pull
out the axle fully.
5. Remove the wheel assembly by gently tapping
it along with the disc.
6. For locating and reassembling the rear wheel
easily, engage gear. This will arrest the free
movement of the drum sprocket. Reverse the
procedure for reassembly.
Warning
While assembling the caliper assembly ensure that
the slot provided in the caliper is properly located to
the lug provided in the swingarm assembly.
Always make sure that whenever the wheel is
removed, axle nut is properly retightened to the
specified torque.
STORAGE PROCEDURES
For storage of your motorcycle for longer periods
of over a month and above, we recommend to
carry out the following steps:
1. Clean the vehicle thoroughly. Park the vehicle
on centre stand.
2. Warm up the engine and drain engine cum
transmission oil. Store the oil, if new, in a dust
free container.
Warning
The exhaust system becomes hot after a run. Park the
vehicle in a place where pedestrians or children are
not likely to touch the vehicle.
Caution
Do not park the vehicle on a slope or soft ground or
else it may fall.
During storage, the battery must be recharged on a
constant current battery charger at recommended
amperage atleast once in a month.
-47-
