1. Z-Axis Guide Rod
5. Y-Axis Guide Rod
9. Build Plate
13. Servo
17. Power Switch
Getting to Know Your Inventor II
14
3
4
12
2. Filament Outlet
6. X-Axis Guide Rod
10. Leveling Knob
14. Nozzle
18. Power Input
13
15
2
1
11
3. Filament Cartridge
7. Touch Screen
11. USB Cable Input
15. Turbo Fan Baffle
02
16
17
18
4. Filament Inlet
8. Touch Screen Button
12. USB Stick Input
16. Turbo Fan
