Altronix Trove T1SAK3F4 Installation Manual page 8

T2SAK7F8 and T2SAK75F12 Enclosure Dimensions (H x W x D):
1.25"
(31.75mm)
6.25"
(21.59mm)
(158.75mm)
1.5"
1.25"
(31.75mm) (38.1mm)
G
(685.8mm)
1.00"
(25.4mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A.
IITrove / SALTO
- 8 -
27.25" x 21.75" x 6.5" (692.15mm x 552.5mm x 165.1mm)
2.00" 5.25"
(50.8mm) (133.35mm)
0.85"
27.00"
0.85"
(21.59mm)
2.00" 5.25"
(50.8mm) (133.35mm)
21.50"
(546.1mm)
3.50" 3.50"
(88.9mm) (88.9mm)
0.5625"
(14.29mm)
1.77"
(44.96mm)
2.415"
(61.34mm)
19.80"
(502.92mm)
7.00"
(177.79mm)
K05S
5.25"
(133.35mm)
0.685"
(17.399mm)
Knockouts
6.25"
1.125" (28.32mm)
(158.75mm)
0.885" (22.479mm)
1.25"
(31.75mm)
5.25" 2.00"
(133.35mm) (50.8mm)
2.00"
(50.8mm)
6.75"
(171.45mm)
8.25"
(209.54mm)
8.00"
(203.2mm)
2.00"
(50.8mm)
1.25"
(31.75mm)
MEMBER
Trove / SALTO Kits
