ECtemp Next Plus HW
5 Basic features
• Floor temperature setting and measurement.
• Auto recovery, Defrost (low temperature protection).
• Clock, Timer and 6 period programming.
• Working mode selection.
• Keypads Lock.
6 Status display
• Thermostat output display.
• Floor temperature display.
• Floor temperature setting display.
• Clock display.
• Low temperature protection display.
• Working mode selection display.
7 Operation
• On/Off thermostat: Press "
again to turn off thermostat and its output.
• Setting temperature: press "
press "
• Working Mode Selection: When thermostat turns on,
press "
means thermostat at Timer mode, icon "
Programming mode, without these two icons means at
manual mode.
© Danfoss | Produced by FEC | 2020.10
" to raise temperature (0.5 °C changed each press).
" to select different working mode, icon
" to turn on, press "
" to reduce temperature,
" means at
AN347136888492-010101 | 9
EN
"
