Mocka Eclipse Change Table Assembly Instructions Manual page 7

Eclipse Change Table
Assembly Instructions
11
13
L
L
L
L
11
Attach panels [11] to panels [12] and panels [13] and secure
with 8x bolt (L). Tighten with an Allen Key (P).
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
P
L
11
12
L
L
L
12
L
13
12
Attach panels [12] to panel [2] as shown using 6x screws (O).
Tighten with a screwdriver.
3 12
O
3 2
O
O
3 12
O
O
O
O
7
