PA 358
5.2.1

Jumper settings

IMPORTANT!
The jumper settings depend on the version of the board (voltage or
current output channels)
The following jumper settings are given for channel 0.The settings are identical for
all channels on the board. See the corresponding jumper designations in fig. 5-2.
The watchdog function is valid for all channels.
Jumper
J1
J2
J4
J25, J26,
J41
8

Table 5-1: Jumper settings - Channel 0

Settings
Set Value of the DAC I after reset
Unipolar zero
Not set Value of the DAC I after reset
Bipolar zero
Output range for channel 0
Bipolar
Output range for channel 0
Unipolar
Output range for channel 0
0-10 V
Output range for channel 0
0-5 V
Output range for channel 0
4-20 mA
Output range for channel 0
0-20 mA
Technical description
Functions
Chapter 5
Settings at
delivery
Unipolar zero
Unipolar
0-10 V
4-20 mA
