USER MANUAL
Ascom i63 VoWiFi Handset
2. Place the battery in the charging slot. Slide the battery lock to the left. If the battery has been correctly
inserted, the LED indicator on the battery charger turns red to show that the battery is charging.
3. The battery is fully charged when the LED indicator turns green.
11.1.3

Replace the Battery

The battery of the handset is exchanged easily. This is useful when there is limited time for charging, or if
additional battery time is needed. If the battery capacity and performance drops significantly, replace it with
a new one. Please contact the system administrator or handset supplier for a new battery.
To replace the battery follow the instruction below:
1. Switch off the handset to prevent data loss or damage to the handset.
2. Slide the battery cover lock to the right to release the battery.
3. While pressing and holding the upper part of the clip, remove the battery from the handset the way it is
shown in Figure 9. Replace the Battery, page
4. Insert a fully charged/ new battery while pressing and holding the upper part of the clip.
5. Slide the battery cover lock to the left to lock it. The handset starts automatically after the battery is
inserted.
Figure 9. Replace the Battery
11.1.4

Energy Efficiency

Recommendations on how to save energy and battery lifetime:
• Do not charge a battery when the ambient room temperature is above 45°C or below 0°C (above 113°F or
below 32°F). Charging below 0°C harms the battery and shortens the lifetime.
• Note that storing Li-Polymer batteries at high temperature dramatically reduces its capacity. For example
storage around maximum temperature reduces capacity with 20% in less than a month, permanently.
• When extended battery lifetime is needed, set the handset screen saver to the Black also in call option.
Refer to the 8.6.4 Display Settings, page 42
• The handset can be configured to switch off when placed in the charger. When removed from the
charger, the handset switches on automatically. For more information, refer to the
Action, page 36.
• If the charger is not used for a longer period of time, remove the power adapter to the charger.
• Do not put the handset in charger if no charging is needed.
TD 93289EN / 09 April 2020 / Ver. C
53.
dection.
Maintenance
8.2.4 In Charger
53
