Handset Description

2 Handset Description
This chapter gives an overview of the key features of the Ascom i63 VoWiFi Handset, including the physical
design description, the use of icons and texts, as well as basic instructions for using alphanumeric keys.
This chapter includes the following sections:
• 2.1 Handset Overview, page 2
• 2.2 User Interface, page 4
• 2.3 Display Icons and Text, page 5
• 2.4 Alphanumeric Keys, page 7
2.1

Handset Overview

All handset models share the same external characteristics.
1
2
3
4
5
6
7
8
9
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
10
11
12
Number External
Characteristics
1 Top button
2 Earpiece speaker
3 Volume button (up)
2
18
17
16
15
14
13
Description
In case of Messenger or Talker, the button can be configured for
different functions. Refer to the
38.
In case of Protector , the button is used as a push-button alarm.
Refer to the 6.1 Push-button and Test Alarms, page
Using the button as Push-to-Talk (PTT) requires a Messenger
handset.
Used in voice communication.
Used for increasing the speaker volume.
Ascom i63 VoWiFi Handset
Define Multifunction Button
30.
TD 93289EN / 09 April 2020 / Ver. C
USER MANUAL
, page
