- Page 1 LEVER Swing Gate Operator INSTALLATION MANUAL Latest Revision: 07.11.2006 Document Ref.:1110.D.01.0001_5...
-
Page 3: Basic Kit
1.0 Introduction A CENTURION GATE AUTOMATION system is a quality product designed to give many years of trouble free service. This MANUAL has been compiled to assist you, the customer, with a trouble free installation. PLEASE READ THE INSTRUCTIONS CAREFULLY 2.0 Basic Kit... -
Page 4: Recommended Tools
PLUMB BOB 4.0 Actuator Positioning ( Quick Reference Table) GATE CLOSED ß - GATE OPENING ANGLE WALL ß Model Gate Leaf With (m) 90° <1.5 120° LEVER4 90° <2.0 120° 90° <2.5 120° 90° 1057 <2.0 120° 90° 1043 LEVER5 <2.5... -
Page 5: Cable Requirements
5.0 Cable Requirements INTERCOM GOOSENECK 220V MAINS INTERCOM TABLE 2 - CABLE REQUIREMENTS TO HOUSE NO OF CABLE TYPE DESCRIPTION SIZE OPTIONAL CORES mm² MASTER MOTOR (MOTOR) G.P. IN CONDUIT OR NORSK SLAVE MOTOR (MOTOR) and G.P. IN CONDUIT OR NORSK 2 + E EITHER: 220V AC SUPPLY CABLE NORSK... -
Page 6: Mount Control Box
6.0 Mount Control Box Space to mount intercom power supply behind CP77 if required. CONTROL BOX PREFERABLY CP77 MOUNTED AT EYE LEVEL BATT CABLING ROUTE - REMOVE CHASSIS PLATE - MOUNT ENCLOSURE TO WALL - DRILL CABLE ENTRY HOLES - REPLACE CHASSIS PLATE AND WIRE EQUIPMENT 7.0 Position Actuator (Gate Inward Opening) 7.1 Determine Gate Opening Angle... - Page 7 Determine gate opening angle continued STEP 2 - SWING GATE TO DESIRED OPEN POSITION (70 - 120 DEGREES). - MAKE SECOND MARK "S2" ON THE GROUND. STEP 3 - MEASURE DISTANCE, Z, BETWEEN S1 & S2 IN mm.
- Page 8 7.2 Determine Dimensions of Mounting Brackets Fig. A Fig. B HINGE PILLAR GATE CLOSED BETA (Gate Opening Angle) GATE BRACKET GATE OPEN L= LENGTH OF GATE LEAF 1. Having measured Z as per STEPS 1 TO 3 on pages preceding, select value of Z in TABLE Lever 4 or Lever 5 below closest to that measured.
- Page 9 7.3 Mount Actuator Brackets HINGE - POSITION GATE BRACKET AT DIMENSION "C". CENTRE LINE - WELD BRACKET TO GATE. - POSITION PILLAR PLATE AT DIMENSION "A" - CENTRE LINE OF PILLAR PLATE MUST BE LEVEL WITH TOP HORIZONTAL FACE OF GATE BRACKET.
- Page 10 DETERMINE GATE OPENING ANGLE BY FOLLOWING STEP1 TO STEP 3 ON PAGE 4 AND 5. FOR THE PARTICULAR ACTUATOR AND CLOSEST GATE OPENING ANGLE (LEVER4 OR LEVER5) USE THE CORRECT TABLE ON PAGES 8 & 9 TO READ OFF THE VALUE OF A; B; C.
- Page 11 LENGTH OF GATE LEAF (L) metres LEVER 5 SMA/ 1.5 < L < 2.0 2.0 < L < 2.5 2.5 < L < 3.2 LEVER 5 DMA BETA 1147 1100 1093 1071 1218 1090 1081 1057 1286 1080 1069 1042 1351 1069 1056...
-
Page 12: Manual Override
10.0 Mount Actuator CONTROLLER ENCLOSURE MOUNT BACK OF ACTUATOR ONTO PILLAR BRACKET, AS SHOWN. MOUNT FRONT OF ACTUATOR ONTO GATE BRACKET AS SHOWN. WIRE ACTUATOR BACK TO CONTROLLER VIA WEATHERPROOF JUNCTION BOX NB. MAKE ANY JOINTS INSIDE WEATHERPROOF JUNCTION BOX LEAVE A LOOP IN MOTOR CABLE BETWEEN JUNCTION BOX AND ACTUATOR. -
Page 13: Motor Connections
12.0 Control Card Connections 12.1 Overall Schematic of CP77 controller DOUBLE/SINGLE SWING CONTROLLER WITH MULTIPLE FEATURES CP77 CONTROL CARD 9 10 11 12 13 14 15 16 12.2 Motor connections SLAVE MOTOR MASTER MOTOR 2x2.5mm² CABLE 2x2.5mm² CABLE NB: Polarity of CONTROLLER motor wires will MODEL... - Page 14 Determine gate opening angle continued 12.3 Pedestrian Keyswitch SPRING RETURN SWITCH SIGNAL COMMON 0,2mm CABLE CONTROL BOX CONTROLLER MODEL CP77 12.4 Holiday Lockout LOCK +12V ELECTRONICS 2 POSITION SWITCH LOCK N.O. LATCH TYPE RADIO RECEIVER 0,2mm RELAY MUST HAVE CABLE LATCHING CONTACT +12V ELECTRONICS...
- Page 15 Electrical Connections continued 12.5 Intercom Connections - Many different intercom types are available. NOTE: - Only signals necessary to interface intercom to Centurion's controller are shown. - Consult intercom manufacturer for full wiring diagrams. INTERCOM +12V NEG TRG 0,5mm CABLE...
- Page 16 12.6 Radio Connections - (Refer to CENTURION for coding details) CENTURION SMART EXAMPLE 1 NO CODING RECEIVER 1 2 3 4 5 SWITCHES +12V COM +12V ² 0,2mm TYPICAL RADIO RECEIVER TYPICAL CABLE TRANSMITTER +12V (REMOTE) EXAMPLE 2 POWER CONTROLLER...
- Page 17 12.8 Remote Autoclose Switch TOGGLE SWITCH IS SHOWN FITTED TO AN INTERCOM TELEPHONE SIGNAL COMMON AUTO CLOSE TOGGLE 0,2mm² CABLE CONTROLLER MODEL TO MOTOR CONTROLLER CP77 12.9 Remote Pillar Light Control TOGGLE SWITCH IS SHOWN FITTED TO AN INTERCOM LIGHT TELEPHONE AUTOCLOSE SIGNAL COMMON...
- Page 18 12.10 Remote Gate Status Light Emitting Diode (LED) FITTED TO HANDSET BASE SEPARATELY ANODE + SIGNAL COMMON CATHODE - STATUS LED 0,2mm² CABLE GATE STATUS LED INDICATION MAINS LOSS 2 FLASHES / 2 sec BATTERY LOW 3 FLASHES / 2 sec COLLISION 4 FLASHES / 2 sec DETECTION...
- Page 19 12.12 Solenoid Lock/Magnetic Lock OPTION 1 +12V SOLENOID LOCK +12V OPTION 2 Min. 1,5mm² 12V RELAY +12V CABLE MAGNETIC COIL LOCK N.C. MAGNET SUPPLY (Could be +12V from gate motor battery depending on type of magnetic lock used) CONTROLLER MODEL NOTE: SOLENOID LOCK, OR MAGNET, IS USED TYPICALLY ON SINGLE SWING GATES CP77...
- Page 20 12.14 Pillar Light(s) LIGHT LIVE ² 0,5mm NORSK CABLE OR (S.W.A.) E N L 220V AC SUPPLY (OR OTHER VOLTAGE TO SUIT TYPE OF GLOBES USED) CONTROLLER MODEL CP77 12.15 Recommend Earthing for Lightning Protection - USE ONE OF THE STUDS THAT SECURE THE TRANSFORMER IN POSITION CP77 TO ESCOM EARTH...
-
Page 21: Solar Panel
12.16 Solar Panel SOLAR REGULATOR TYPE WITH LOAD SHED TO SECOND (WITH LOAD SHED) SOLAR PANEL (IF FITTED) POWER CABLE 2.5mm² MINIMUM BLACK SENSE CABLE 0.2mm² SOLAR PANEL NOTE 2 X (NOTE1) LOAD e.g. FLUORESCENT LIGHT 12V DC 0,5mm² NOTE 2 CABLE MIN SENSE CABLE 0.2mm²... -
Page 22: Connecting Battery
13.2 Connecting Battery CP77 CABLE BATTERY CP4 BATTERY CONTROLLER MODEL CP77 NOTE: IF A LARGE BATTERY IS USED, THE CABLES CONNECTING THE BATTERY TO THE CP80 CARD ² SHOULD BE BETWEEN 6 & 10 mm FOR CABLE LENGTHS LESS THAN 5 METRES. 13.3 Control Card Setup GREEN POWER ON LED (ON WITH MAINS POWER PRESENT) - Page 23 13.4 Set Motor Polarity - TRIGGER CONTROL CARD. - MAKE SURE MOTOR DIRECTION(S) CORRESPOND(S) WITH STATUS LED. - SWOP MOTOR WIRES ON CONTROL CARD TO GIVE CORRECT MOTOR ROTATION. (SEE FIG BELOW) (VIEWED FROM INSIDE R.H.S. GATE MOTOR L.H.S. GATE MOTOR THE PROPERTY) CLOSING CLOSING...
- Page 24 CENTURION THE AUTOMATIC CHOICE CENTURION SYSTEMS (PTY) LTD HEAD OFFICE: TEL: +27 (0)11 699-2400, FAX: +27 (0)11 704-3412 or 462-6669 148 EPSOM AVENUE, NORTH RIDING P .O. BOX 506, CRAMERVIEW, 2060 SOUTH AFRICA WEB: http://www.centsys.co.za General information e-mail: info@centsys.co.za FOR TECHNICAL SUPPORT CONTACT: SOUTH AFRICA EAST RAND.
