IMPORTANT
Le remplacement de composants pourrait compromettre l'admissibilité à la Classe I,
Division 2.
2.4
Mounting the Device
The RUGGEDCOM RS900G is designed for maximum mounting and display flexibility.
It can be equipped with adapters that allow it to be attached to a DIN rail or panel.
IMPORTANT
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with either DIN rail or panel hardware installed,
refer to
2.4.1
Mounting the Device on a DIN Rail
For DIN rail installations, the RUGGEDCOM RS900G can be ordered with a DIN rail
adapter preinstalled on the back of the chassis. Use the adapter to mount the device
to a standard 35 mm (1.4 in) IEC/EN 60715 or TS35 DIN rail.
RUGGEDCOM RS900G
Installation Manual, 01/2021, C79000-G8976-1025-08
"Dimension Drawings (Page
25)".
Installing the Device
2.4 Mounting the Device
7
