Introduction
1.2 Description
•
1.2

Description

The RUGGEDCOM RS900G features various ports, controls and indicator LEDs on the
front panel for connecting, configuring and troubleshooting the device.
1
2
3
4
1
2
3
4
5
6
7
Figure 1.1
Communication Ports
RS-232 Console Port
POWER LED
ALARM LED
2
CSA/UL 62368-1 safety approved to 85 °C (185 °F)
5
6
ALARM LED
POWER LED
Fiber Optic or SFP (Small Form-Factor Pluggable) Ethernet Ports
Copper Ethernet Ports
RS-232 Console Port (DB9)
Failsafe Alarm Relay
Power Supply Terminal Block
RUGGEDCOM RS900G
7
Receive and transmit network traffic, as well as provide remote Web
access to the RUGGEDCOM RS900G operating system. For more
information, refer to:
• "Connecting to the Device (Page 17)"
• "Communication Ports (Page 19)"
The serial console port is for interfacing directly with the device
and accessing initial management functions. For information
about connecting to the device via the serial console port, refer to
"Connecting to the Device (Page
Illuminates when power is being supplied to the device.
Color
Green
Off
Illuminates when an alarm condition exists.
17)".
Description
Device is receiving power
No power
RUGGEDCOM RS900G
