Note
If any item is missing or damaged, contact Siemens for assistance.
2.3
Mounting the Device
The RUGGEDCOM RS969 is designed to be mounted on a panel by affixing the top
and bottom flanges of the device to a panel using screws.
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with panel mount hardware installed, refer to
"Dimension Drawings" (Page 29).
To mount the device to a panel, do the following:
1.
RUGGEDCOM RS969
Equipment Manual, 10/2023, C79000-G8976-1038-05
NOTICE
Place the device against the panel and align the flanges with the mounting
holes.
Installing the Device
2.3 Mounting the Device
11
