Unpacking Information

This section provides instructions for safely unpacking and handling the InfiniPath
adapter. To avoid damaging the adapter card, always take normal precautions to
avoid electrostatic discharge.
2.3.1

Verify Package Contents

The InfiniPath adapter system should arrive in good condition. Before unpacking,
check for any obvious damage to the packaging. If you find any obvious damage
to the packaging or to the contents, please notify your reseller immediately.
2.3.2

List of the Package Contents

The package contents for the QMI7140 adapter are:
InfiniPath QMI7140
■
An illustration of the QMI7140 is not yet available.
The package contents for the QLE7140 adapter are:
InfiniPath QLE7140
■
Standard PCIe risers can be used, typically supplied by your system or motherboard
vendor. The contents are illustrated in
The package contents for the QHT7140 adapter are:
InfiniPath QHT7140
■
HTX riser card for use in 1U or 2U chassis
■
The contents are illustrated in
The IBA6120 and the IBA6110 are the QLogic InfiniPath Interconnect ASICs, which
are the central components of the interconnect. The IBA6120 is shown in
and the IBA6110 is shown in
