Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it sustained damage
during transport. If damage is discovered, immediately record a complete description of the damage on the bill of lading. If the
product is undamaged, discard the packaging.
NOTES:
The end-user is solely responsible for confirming that product design, installation, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Table of Contents
Signal words................................................................................................................................................ 2
Safe use recommendations............................................................................................................................. 2
FIG. 1A: CBFC-500 exploded parts diagram & bill of materials................................................................................ 3
FIG. 1B: CBFC-500 rated loads for specified boom lengths.................................................................................... 4
FIG. 2A: CBFC-1000 exploded parts diagram & bill of materials.............................................................................. 5
FIG. 2B: CBFC-1000 rated loads for specified boom lengths........................................................................................ 6
FIG. 3A: CBFC-2000 exploded parts diagram & bill of materials................................................................................... 7
FIG. 3B: CBFC-2000 rated loads for specified boom lengths.................................................................................. 8
FIG. 4: Manual hydraulic pump exploded parts diagram & bill of materials................................................................. 9
Operation.................................................................................................................................... ................ 10
Operating the manual hydraulic pump................................................................................................................ 10
Boom length adjustment................................................................................................................................. 11
Inspections......................................................................................................................................................... 11
Maintenance................................................................................................................................................. 12
Labeling diagram........................................................................................................................................... 12
Limited Warranty............................................................................................................................................ 13
Copyright 2017 Vestil Manufacturing Co.
CBFC C
OUNTERBALANCED
O
PERATION AND
Rev. 3/6/2017
V
M
ESTIL
ANUFACTURING
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com
F
LOOR
M
M
AINTENANCE
CBFC, manual.doc
C
ORP
e-mail:
sales@vestil.com
C
RANE
ANUAL
Page 1 of 13
.
Advertisement
Table of Contents
Related Manuals for Vestil CBFC
Summary of Contents for Vestil CBFC
-
Page 1: Table Of Contents
Table of Contents Signal words….………………………………………………………………………………………………………………………….. 2 Safe use recommendations………………………………………………………………..…………………………………………… 2 FIG. 1A: CBFC-500 exploded parts diagram & bill of materials…………………………………………………………………….. 3 FIG. 1B: CBFC-500 rated loads for specified boom lengths…….………………………………………………………………….. 4 FIG. 2A: CBFC-1000 exploded parts diagram & bill of materials…….…………………………………………………………….. 5 FIG. -
Page 2: Signal Words
(e.g. rigging). Periodically lubricate pivot points. Keep the product clean & dry. Only use approved replacement parts. To order replacement or spare parts for this equipment, contact the factory. Copyright 2017 Vestil Manufacturing Co. Page 2 of 13... - Page 3 Rev. 3/6/2017 CBFC, manual.doc FIG. 1A: CBFC-500 Exploded Parts Diagram & Bill of Materials Item Item Part no. Description Quantity Part no. Description Quantity 28-514-089 Frame, inner boom weldment 37032 ” nylon insert jam nut 08-145-001 Swivel hook, 2-ton 99-024-003...
- Page 4 Rev. 3/6/2017 CBFC, manual.doc FIG 1B: CBFC-500 rated loads for specified boom lengths NOTE: DO NOT use the crane unless the inner and outer booms are securely pinned together. Although the outer boom has only one set of pin holes, the inner boom has 3 sets to allow boom length to be adjusted.
- Page 5 Rev. 3/6/2017 CBFC, manual.doc FIG. 2A: CBFC-1000 Exploded Parts Diagram & Bill of Materials Item no. Part no. Description Quantity Item no. Part no. Description Quantity ” – 13 x 1 ” HHCS #2 zinc- 28-514-089 Frame, inner boom weldment...
- Page 6 Rev. 3/6/2017 CBFC, manual.doc FIG 2B: CBFC-1000 rated loads for specified boom lengths NOTE: DO NOT use the crane unless the inner and outer booms are securely pinned together. Although the outer boom has only one set of pin holes, the inner boom has 3 sets to allow boom length to be adjusted.
- Page 7 Rev. 3/6/2017 CBFC, manual.doc FIG. 3A: CBFC-2000 Exploded Parts Diagram & Bill of Materials Item no. Part no. Description Quantity Item no. Part no. Description Quantity 28-514-089 Frame, inner boom weldment 37032 ” nylon insert jam nut 08-145-001 Swivel hook, 2-ton...
- Page 8 Rev. 3/6/2017 CBFC, manual.doc FIG. 3B: CBFC-2000 rated loads for specified boom lengths NOTE: DO NOT use the crane unless the inner and outer booms are securely pinned together. Although the outer boom has only one set of pin holes, the inner boom has 3 sets to allow boom length to be adjusted.
- Page 9 Clamp, worm gear hose, 2 in. – 1.13 99-025-023 Handle, release 99-145-061 1.14 99-144-004 Seal, square profile 01-116-003 Breather, in. NPT 1.15 99-041-004 Plunger/piston, pump 99-031-033 Close pipe nipple 99-144-001 Replacement seals (kit) Copyright 2017 Vestil Manufacturing Co. Page 9 of 13...
-
Page 10: Operation
4. Circulate oil to the cylinder by slowly moving the handle back and forth. Air and oil will sputter from the fitting. When no more air is present, tighten the fitting and reconnect the cylinder to the crane. Copyright 2017 Vestil Manufacturing Co. Page 10 of 13... -
Page 11: Boom Length Adjustment
AW 32 or HO 150 hydraulic oil, or a non-synthetic transmission fluid. You may use a synthetic transmission fluid if you flush the system with the synthetic fluid before filling the reservoir. Copyright 2017 Vestil Manufacturing Co. Page 11 of 13... -
Page 12: Maintenance
The floor crane should be labeled as shown below. Replace all labels that are missing, faded, or not easily readable. Label 206: hydraulic fluid specifications Label 287 (on counterweight): model & capacity Maximum rated load for each boom length (both sides of boom) Label 586 (on counterweight): use-related warnings Copyright 2017 Vestil Manufacturing Co. Page 12 of 13... -
Page 13: Limited Warranty
(you) for warranty service. Who may request service? Only a warrantee may request service. You are a warrantee if you purchased the product from Vestil or from an authorized distributor AND Vestil has been fully paid.
