MOD-5178/5179

STEP 3:

Screw Bolts (A) into the bottom holes on the assembled Headboard (1&6) & Footboard (2) by hand .
Leaving 8~10mm space of the thread of Bolts (A) as shown for inserting the notch of assembled Side Rails (3&4&5).
Insert the notch of assembled Side Rails(3&4&5) into the space of thread of Bolts (A) which attached into the bottom
holes of assembled Headboard (1&6) & Footboard (2) as shown.
Screw Bolts (A) into the top holes on the assembled Headboard (1&6) & Footboard (2) as shown.
Tighten all Bolts (A) with Allen Wrench (D) after all assembled.
2
Bottom hole
AX8
Customer Service 908-368-1025︱www.modwayfurniture.com
TWIN BED
Top hole
Dx1
Hardware & Tool required
Assembly is completed. The bed is ready for using now!
1
3
Notch
6
Page 3 of 3
