Installing cable connector
1
Insert cable for distribution into open slot
2
Insert cable for power into open slot
1
Plug unit in
Plug power supply into switched GFCI outlet.
3
Rotate orange lever to lock into place
4
Slide cable end protector over exposed cable
4
2
SERVO-DRIVE
3
NOTE:
Dimensions in millimeters (inch equivalents as noted)
Ensure piercing pins are not damaged
ST-CSDOC-68 Rev Feb 2015
