BLUM 21KA000 Manual

BLUM 21KA000 Manual

Servo-drive for aventos opens and closes automatically
Hide thumbs

Advertisement

Table of Contents

SERVO-DRIVE for AVENTOS
Opens and closes automatically

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21KA000 and is the answer not in the manual?

Questions and answers

Related Manuals for BLUM 21KA000

Summary of Contents for BLUM 21KA000

  • Page 1 SERVO-DRIVE for AVENTOS Opens and closes automatically...
  • Page 2 AVENTOS lift systems open with just a light touch ‒ and then close again with the press of a button. An inspiring feature that is certain to impress, thanks to SERVO-DRIVE for AVENTOS, the electrical opening support for lift systems. © 2016 Blum, Inc.

  • Page 3: Table Of Contents

    SERVO-DRIVE for AVENTOS HS SERVO-DRIVE for AVENTOS HL SERVO-DRIVE for AVENTOS HK Electrical Specifications Wiring Options Assembly for AVENTOS HF/HS/HL Assembly for AVENTOS HK Overview of Functions Cover Cap Assembly Battery Replacement Assembly Aids Part Number Index © 2016 Blum, Inc.

  • Page 4: Servo-Drive For Aventos

    Provided by the easy to reach switch on the cabinet side. This enables the doors to close easily and ergonomically. The proven BLUMOTION function also ensures silent and effortless closing. © 2016 Blum, Inc. Subject to technical modifications without notice...
  • Page 5 Thanks that share one wide door. to the “collision avoidance” function, you can set drive units so that only one front opens at a time. Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.
  • Page 6 SERVO-DRIVE for Overview of Components AVENTOS Blum distance bumper Power supply and wall mount bracket Cabling Lift mechanism Drive unit Cover plate SERVO-DRIVE switch © 2016 Blum, Inc. Subject to technical modifications without notice...
  • Page 7 ▀ Wireless connection to the drive unit ▀ Please see the AVENTOS brochure (LIT.AVT1000) Frequency 2.4 GHz ▀ for all other lift system components. Certified for use worldwide ▀ Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.

  • Page 8: Servo-Drive For Aventos Hf

    ▀ Cable connector Non-handed cover cap (qty 2) ▀ ▀ Cable end protector (qty 2) SERVO-DRIVE switches (qty 2) ▀ ▀ Ø5 mm Blum distance bumper (qty 6) ▀ Color: gray ▀ Part no. Part no. SERVO-DRIVE set 21FA000 21F8000.NA...

  • Page 9: Servo-Drive For Aventos Hs

    ▀ ▀ ▀ Cable end protector (qty 2) SERVO-DRIVE switches (qty 2) ▀ ▀ Ø5 mm Blum distance bumper (qty 4) ▀ Color: gray ▀ NOTE: Stabilizer rod cutting dimension for SERVO-DRIVE application is length = interior cabinet width minus 164 (6-7/16") Part no.

  • Page 10: Servo-Drive For Aventos Hl

    Stabilizer rod cover cap (qty 2) ▀ ▀ ▀ Cable end protector (qty 2) SERVO-DRIVE switches (qty 2) ▀ ▀ Ø5 mm Blum distance bumper (qty 4) ▀ NOTE: Stabilizer rod Color: gray ▀ cutting dimension for SERVO-DRIVE application is length = interior cabinet width minus 164 (6-7/16")

  • Page 11: Servo-Drive For Aventos Hk

    ▀ Cable connector Non-handed cover cap (qty 2) ▀ ▀ Cable end protector (qty 2) SERVO-DRIVE switches (qty 2) ▀ ▀ Ø5 mm Blum distance bumper (qty 4) ▀ Color: gray ▀ Part no. Part no. SERVO-DRIVE set 21KA000 21K8000.NA...
  • Page 12 General specifications Efficiency ≥ 87% Switching frequency 65 kHz No load loss (standby) < 0.5 W Energy Star Level V Safety / Approvals EN / IEL 60950, 60335-1 UL 60950-1, 1310 © 2016 Blum, Inc. Subject to technical modifications without notice...

  • Page 13: Wiring Options

    Insert cable for distribution into open slot Rotate orange lever to lock into place Insert cable for power into open slot Slide cable end protector over exposed cable NOTE: Ensure piercing pins are not damaged Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.

  • Page 14: Assembly For Aventos Hf/Hs/Hl

    The activation switch should be installed by pressing into the cabinet side with your hand. Do not use hammer to install. NOTE: Use of boring template (M31.2000) recommended, see page 27 Installation of Blum distance bumpers For AVENTOS HF – install into drawer front. For AVENTOS HS/HL ‒...
  • Page 15 To lock drive unit to the lift mechanism, slide the lift mechanism selection switch to the locked position (reference noted positions on drive unit). There will be an audible click when locked. Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.

  • Page 16: Assembly For Aventos Hk

    Do not use hammer to install. NOTE: Use of boring template (M31.2000) recommended, see page 27 Installation of Blum distance bumpers Install into door front. Use of four distance bumpers is recommended. Two may be sufficient for smaller, lighter doors.
  • Page 17 Position drive unit onto lift mechanism with locator pin. To lock drive unit to the lift mechanism, hold drive unit in place and press down the three orange lock tabs. Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.
  • Page 18 Function buttons layout Drive unit ▀ <Reset Motion> button ▀ Motion LED ▀ <SWITCH> button ▀ <SYNC> button ▀ <COLL> button ▀ <Reset Wireless> button ▀ Wireless LED ▀ SERVO-DRIVE switch ▀ © 2016 Blum, Inc. Subject to technical modifications without notice...
  • Page 19 NOTE: If the reference run is interrupted, it should be reset. See reset motion on page 25 then restart reference run. Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.
  • Page 20 2nd drive unit until the until the LED flashes LED lights up continuously (the same will happen in the first cabinet) NOTE: Repeat steps 1 through 4 for all additional cabinets © 2016 Blum, Inc. Subject to technical modifications without notice...
  • Page 21 Operating mode display Reference run successfully Flashes green quickly Deactivation confirmation completed Flashes orange Reset motion confirmation quickly Lights up continuously Last process was not completed successfully Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.

  • Page 22: Battery Replacement

    Remove battery carrier tray by pressing Remove dead battery Replace battery carrier tray into ▀ ▀ ▀ up or down on the battery display switch switch housing Insert new battery ▀ © 2016 Blum, Inc. Subject to technical modifications without notice...

  • Page 23: Assembly Aids

    M31.2000 Specifications Mark switch location ▀ Set drilling depth Align mark ▀ Secure template to cabinet panel with clamp ▀ Use provided Torx driver bit to bore hole ▀ Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.
  • Page 24 SERVO-DRIVE for Part Number Index AVENTOS Part no. Page no. 21KA000 21K8000.NA 21L3200.01 21L3500.01 21L3800.01 21L3900.01 21L8000.NA 21FA000 8, 10, 12 21F8000.NA 21P5020 21S3500.01 M31.2000 Z10M200U Z10NE020G © 2016 Blum, Inc. Subject to technical modifications without notice...
  • Page 25 Notes SERVO-DRIVE for AVENTOS Dimensions in millimeters (inch equivalents as noted) © 2016 Blum, Inc.
  • Page 26 Blum, Inc. Headquarters, Stanley, NC © 2016 Blum, Inc.
  • Page 27 Why Choose Blum Blum, Inc. is a leading manufacturer of functional hardware for the kitchen cabinet and commercial casework industries specializing in lift systems, concealed hinges and drawer runner systems. Virtually all of the hardware needed to assemble and make cabinets functional is available within the wide range of quality Blum products.
  • Page 28 Blum, Inc. 7733 Old Plank Rd. Stanley, NC 28164 800-438-6788 blum.com © 2016 Blum, Inc. Subject to technical modifications without notice...
