Original instructions
BOHRMASCHINE
Originalbetriebsanleitung
PERCEUSE
Notice originale
TRAPANO
Istruzioni originali
TALADRADORA
Instrucciones de uso originales
BERBEQUIM
Manual original
WIERTARKA
DECLARATION OF CONFORMITY
following directives and the harmonized standards:
1 – 8
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
KONFORMITÄTSERKLÄRUNG
9 – 18
Hiermit versichern wir unsere persönliche Haftung, dass Produkt im Abschnitt "Technische Daten" beschrieben" allen einschlägigen
Bestimmungen folgender Richtlinien und entsprechender harmonisierten Standards entspricht:
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
19 – 28
Die technischen Unterlagen werden bei SPARKY ELTOS AD, Kubrat Str.9, 5500 Lovech, Bulgarien, aufbewahrt.
DECLARATION DE CONFORMITE
29 – 37
pertinentes des présentes directives, respectivement aux normes harmonisées:
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
Le dossier technique est conservé par SPARKY ELTOS AD, 9, rue Kubrat, 5500 Lovech, Bulgarie.
38 – 47
DICHIARAZIONE DI CONFORMITÀ
pertinenti della presente direttive e norme armonizzate:
48 – 56
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
Il fascicolo tecnico viene custodito presso la SPARKY ELTOS AD, 5500 Lovech, via Kubrat n. 9, Bulgaria.
DECLARACIÓN DE CONFORMIDAD
57 – 65
aplicables de la presente directrices aplicables y las correspondientes normas armonizadas:
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
66 – 75
DECLARAÇÃO DE CONFORMIDADE
76 – 85
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
86 – 95
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
2014/30/EU, 2011/65/EU,
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
EN 60745-1, EN 60745-2-1; EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3, EN 50581.
Manufacturer
SPARKY Power Tools GmbH
Leipziger Str. 20
10117 Berlin, GERMANY
BR 102E
6 March 2017
2014/30/EU, 2011/65/EU,
2014/30/EU, 2011/65/EU,
2014/30/UE, 2011/65/UE,
2014/30/UE 2011/65/UE,
2014/30/UE, 2011/65/UE,
2014/30/UE, 2011/65/UE,
2014/30/UE, 2011/65/UE,
2014/30/EU, 2011/65/EU,
2011/65/EU,
Signature of authorized person
A. Ivanov
Technical director of SPARKY ELTOS AD
