2. System Specifications

Factory Default Settings
Maximum motor run time
Courtesy light time
Obstruction force margin
Auto close time
Technical Specifications
Model
Input Voltage
Current (Max)
Transformer secondary output
Voltage
Motor type
Shuttle travel distance in the
C-Rail
Maximum shuttle travel
distance in the C-Rail
Peak Short Term Pulling Force
Maximum door hanging weight
Receiver type
Receiver code storage capacity
Transmitter frequency
Coding type
Number of code combinations
Code generation
Remote control battery
Courtesy light
Control board fuse
Battery backup
Network connectivity
NOTE: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn trigger the safety obstruction detection system intermittently.
Default Maximum
1 Minute -
180 secs -
0.7 amp 1.5 amp
0 seconds -
SYNCRO ATS-3AMB SYNCRO ATS-3AM
120Vac / 60Hz 120Vac / 60Hz
2.0A 2.0A
24Vac 24Vac
24Vdc geared motor with 24Vdc geared motor with
permanent magnet permanent magnet
9.19ft (2.8m) 9.19ft (2.8m)
approximately (standard) approximately (standard)
16.4ft (5m) (with 16.4ft (5m) (with
extended C-Rail) extended C-Rail)
1000N 1000N
520lbs (236kg) 520lbs (236kg)
UHF Multifrequency FM- UHF Multifrequency FM-
Receiver Receiver
14 X 4 button transmitter 14 X 4 button transmitter
codes codes
433.47MHz; 433.92MHz; 433.47MHz; 433.92MHz;
434.37MHz 434.37MHz
TrioCode128™ TrioCode128™
Over 4.29 billion random Over 4.29 billion random
codes codes
Nonlinear encryption Nonlinear encryption
algorithm algorithm
CR2032 3 Volts CR2032 3 Volts
2 LED Modules 2 LED Modules
10A (slow blow) 10A (slow blow)
2 x 12PCA 1.3 - 12V1.3 Battery compatible,
AH Batteries (requires optional Battery
Backup kit)
Network ready, Network ready,
Smart hub already Smart hub already
installed installed
TEMPO ATS-2AMB
120Vac / 60Hz
2.0A
24Vac
24Vdc geared motor with
permanent magnet
9.19ft (2.8m)
approximately (standard)
16.4ft (5m) (with
extended C-Rail)
1000N
440lbs (200kg)
UHF Multifrequency FM-
Receiver
14 X 4 button transmitter
codes
433.47MHz; 433.92MHz;
434.37MHz
TrioCode128™
Over 4.29 billion random
codes
Nonlinear encryption
algorithm
CR2032 3 Volts
2 LED Modules
10A (slow blow)
2 x 12PCA 1.3 - 12V1.3
AH Batteries
Network compatible,
(requires optional Smart
Phone Control Kit)
Dominator Tempo & Syncro Instruction Manual
Diamond PD Power Drive : Instruction Manual
© Copyright 2019
TEMPO ATS-2AM
120Vac / 60Hz
2.0A
24Vac
24Vdc geared motor with
permanent magnet
9.19ft (2.8m)
approximately (standard)
16.4ft (5m) (with
extended C-Rail)
1000N
440lbs (200kg)
UHF Multifrequency FM-
Receiver
14 X 4 button transmitter
codes
433.47MHz; 433.92MHz;
434.37MHz
TrioCode128™
Over 4.29 billion random
codes
Nonlinear encryption
algorithm
CR2032 3 Volts
2 LED Modules
10A (slow blow)
Battery compatible,
(requires optional Battery
Backup kit)
Network compatible,
(requires optional Smart
Phone Control Kit)
5
ATS-3AM & ATS-2AM
