Automatic Technology Auto-Ki Installation Instructions

Wireless Smart Hub Installation Instructions
For use only with the following garage door operators:
ATS-2AM & GDO-12AM
Conçu pour être utilisé uniquement avec les ouvre
portes de garage suivants : ATS-2AM et GDO-12AM
AUTO-KI SMART HUB KIT - ORDER NO. 87480
ITEM DESCRIPTION
1 WIRELESS HUB200 WT B&D
2 POWER SUPPLY AU 240V
3 WALL BRACKET HUB100
4 PLASTIC WALL PLUG 6.9 X 25
5 SELF TAPPING SCREW 6 X 25
AUTO-KI SMART MODULE FOR HIRO NTR-1V1AM - ORDER NO. 14817
ITEM DESCRIPTION
6 NETWORK TRANSCEIVER NTR-1V1 AY
AUTO-KI SMART MODULE FOR TEMPO NTR-2V1AM - ORDER NO. 87463
ITEM DESCRIPTION
7 NETWORK TRANSCEIVER NTR-2V1 AY
8 TIMING HARNESS 400MM VR12 AY
WARNING!
Changes or modifications not expressly approved by the
party responsible for compliance could void the user's
authority to operate the equipment.
This network device allows for unattended operation of the
door when not in line-of-sight of the door opener.
The door may operate unexpectedly, therefore do not allow
anything to stay in or near the path of the door. When the door
is not operating automatically, watch the door when it is moving
and keep people away until the door is completely opened
or closed. Contact with the moving door can cause serious
personal injury or damage to property.
Your opener must be fitted with SAFETY BEAMS.
Beams detect any obstructions in the door's path and override
automatic operation if one presents. These must be installed as
in accordance with UL 325 and CSA C222.2 No 247.
This is in addition to regular professional servicing, and monthly
obstruction tests as detailed in your opener's Owners Manual.
The compliance to FCC radiation exposure limits for an
uncontrolled environment, and a minimum of 20cm separation
between antenna and body.
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Doc # 160453_00
Part # 87466
Released 06/04/21
Auto-Ki Smart Hub
QTY
QTY
QTY
CLASS B DEVICE
This equiment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
1
installation. If this equipment does cause harmful interference to radio or
1
television reception, which can be determined by turning the equipment
1
off and on, the user is encourage to try to correct the interference by one
2
or more of the following measures:
• Reorient or relocate the receiving antenna
2
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or experienced radio/TV technician for help.
1
To comply with FCC/IC RF exposure limits for general population /
uncontrolled exposure, the antenna(s) used for this transmitter must be
installed to provide a separation distance of at least 7.87in (20cm) from all
persons and must not be co-located or operating in conjunction with any
1 other antenna or transmitter.
1
AVERTISSEMENT!
Tout changement ou toute modification non expressément
approuvée par la partie responsable de la conformité est
susceptible d'annuler le droit de l'utilisateur d'utiliser
l'équipement.
La télécommande radio permet d'actionner la porte lorsque
l'utilisateur est hors de la ligne de vue de la porte et de l'appareil.
En conséquence, la porte risque de s'ouvrir ou se fermer
inopinément et vous devez éviter de laisser des objets sur
sa course ou à proximité. Lorsque la porte ne fonctionne pas
automatiquement, surveillez-la lorsqu'elle bouge et éloignez
toute personne jusqu'à ce qu'elle soit complètement ouverte
ou fermée. Le contact avec la porte en mouvement peut
provoquer des blessures graves ou des dommages matériels.
Safety Votre ouvre-porte doit être équipé de FAISCEAUX DE
SÉCURITÉ. Les faisceaux de sécurité détectent tout obstacle
sur le trajet de la porte et annulent alors le fonctionnement
automatique. Ceux-ci doivent être installés conformément aux
normes UL 325 et CSA C222.2 N° 247.Ceci s'ajoute à l'entretien
professionnel régulier et aux tests d'obstruction mensuels
détaillés dans le mode d'emploi de votre ouvre-porte.
Conformité aux limites d'exposition aux rayonnements FCC
pour un environnement non contrôlé, et distance minimale de
20 cm entre l'antenne et le corps.
Ce dispositif est conforme à la partie 15 des règles de la Federal
Communications Commission (FCC). Son fonctionnement est
assujetti aux deux conditions suivantes: (1) Ce dispositive ne
doit pas provoquer de brouillage préjudiciable, et (2) il doit
accepter tout brouillage reçu, y compris le brouillage pouvant
entraîner un mauvais fonctionnement.
CAN ICES-3 (B)/NMB-3 (B)
