U8551 Universal Unit

1. General specifications
Compatible logger LR8450/LR8450-01 Memory HiLogger
Operating Indoors, Pollution Degree 2, altitude up to 2000 m (6562 ft.)
environment
Operating temperature −10°C to 50°C (14°F to 122°F), 80% RH or less (non-condensing)
and humidity range
Storage temperature −20°C to 60°C (−4°F to 140°F), 80% RH or less (non-condensing)
and humidity range
Standards Safety: EN 61010
EMC: EN 61326, Class A
Standard compliance Thermocouples: JIS C1602:2015, IEC 60584-1:2013
Resistance temperature detector (Pt100, Pt1000): JIS C1604:2013, IEC 60751:2008
Resistance temperature detector (JPt100): JIS C1604:1989
Vibration resistance JIS D 1601:1995 5.3 (1)
Class 1: Passenger vehicles; conditions: Class A equivalent
(4 h along X-axis and 2 h along Y- and Z-axes at a vibration acceleration of 45 m/s
[4.6 G])
Dimensions
Approx. 134W × 70H × 63D mm (5.28"W × 2.76"H × 2.48"D) (including cover)
Mass Approx. 318 g (11.2 oz.)
Product warranty 3 years
period
Accessories Instruction Manual
Installation screws × 2
Options Z2000 Humidity Sensor
2. Input, output, and measurement specifications
-1. Basic specifications
Number of input 15 (Set voltage, thermocouple, humidity, resistance temperature detector, or resistor for
channels each channel.)
Input terminals Push-button type terminal block (4 terminals per channel), outfitted with terminal block
cover
Measurement target Voltage
Thermocouples (K, J, E, T, N, R, S, B, C)
Humidity (using the Z2000 Humidity Sensor)
Resistance temperature detector (Pt100, Jpt100, Pt1000)
Resistor (connection: 4-wire; measurement current: 1 mA ±5%)
Input type Scanning by semiconductor relays, floating unbalanced input
All channels isolated (The SoL terminals used to connect resistance temperature
detectors and resistors are not isolated as they are shorted for all channels internally.)
A/D resolution 16 bits
Maximum input ±100 V DC
voltage
Maximum channel-to-
300 V DC (The SoL terminals used to connect resistance temperature detectors and
channel voltage resistors are not isolated as they are shorted for all channels internally.)
(Connection: 3-wire/4-wire)
(Measurement current: 1 mA ±5% [Pt100 and Jpt100 measurement];
0.1 mA ±5% [Pt1000 measurement])
(During Pt1000 measurement, setting available when the data refresh interval is
greater than 100 ms.)
