Condumax II Transportable
Sampling System User's Manual
2.1
Orientation for Transportation/Storage and Operation
!
Michell Instruments
The Condumax II Transportable must NOT be transported in the
upright/vertical orientation as the shock absorbent design is
only effective in the horizontal position.
Horizontal Orientation for Transportation/Storage
Figure 4
NOTE: Lid must be in place and clasps tightly shut
Vertical Orientation for Operation
Figure 5
