Condumax II Transportable
Sampling System User's Manual
Appendix A Technical Specifi cations
General Specifi cations
Case
Case Dimensions
Gas Connections
Gas Flow Rate
Gas Pressure
Filter
Power Supply
Gas Wetted Bore
Process Connection
Power Consumption
Weight
Michell Instruments
316 stainless steel
640 x 490 x 330mm (25 x 19.3 x 13")
Minimess quick connect, 316 stainless steel braided
Length - 3m each hose
0.06Nm³/h (2.1scfh)
100 barg (1450 psig) max
Coalescing, Borosilicate, glass-bonded micro-fi bers bonded with
Kynar fl uorocarbon (PVDF) resin
(99.5% removal of 0.1 micron particles and aerosols (BS4400)
110 V AC, 60Hz (CSA) OR 240 V AC, 50Hz (ATEX)
PTFE, 2mm internal diameter
316 stainless steel, 1/4 NPT male
< 300 W
60kg (132lbs) max
