4.8 four point eight

Montage Tische quadratisch & rund

Assembly tables square & round

Notice de montage Table carré & rond

Füße mit Längstraverse verschrauben 8 Nm

Screw legs to bars of table depth 8 Nm

Visser les pieds sur les traverses 8 Nm

Abdeckkappen einstecken und festschrauben 5 Nm

Position and screw covers of cantilevers 5 Nm

Monter et visser les cache bras support 5 Nm

1.2

Quertraversen festschrauben 8 Nm

Screw horizontal bars to side frames 8 Nm

3.0

1.4

Plattenverbinder festschrauben

Screw top adapters to cantilevers

2/3

Visser les longerons 8 Nm

Visser les adaptateurs

1.3

1.5
