MTC-8000
10.1"/15"/15.6"/21.5" Fanless Multi-Touch Computer with
Intel Atom
®
x7-E3950 Processor, 2 GigE LAN, 4 USB, 2 COM, DC 9-36V
USER
USER
Manual
Manual
1.0.0 Edition 20210707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTC-8000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Vecow MTC-8000 Series

  • Page 1 USER USER MTC-8000 Manual Manual 10.1"/15"/15.6"/21.5" Fanless Multi-Touch Computer with Intel Atom ® x7-E3950 Processor, 2 GigE LAN, 4 USB, 2 COM, DC 9-36V 1.0.0 Edition 20210707...
  • Page 2 Record of Revision Version Date Remark Page Description 1.00 2021/07/07 Official Release ©Vecow MTC-8000 User Manual...
  • Page 3 This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. Vecow Co., Ltd. is under no legal commitment to the details of this document. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of this document, the products, or any third party infringements, which may result from such use.
  • Page 4 15.6" Fanless Multi-Touch panel PC, Intel Atom™ x7-E3950, MTC-8015W-3950 2 GbE LAN, 2 COM, 4 USB, DC-in 9-36V ® 21.5" Fanless Multi-Touch panel PC, Intel Atom™ x7-E3950, MTC-8021W-3950 2 GbE LAN, 2 COM, 4 USB, DC-in 9-36V ©Vecow MTC-8000 User Manual...
  • Page 5 Block 4G Module Mini PCIe 4G/GPS Module with Antenna WiFi & Bluetooth WiFi+Bluetooth Module with Antenna Module Note : Vecow suggest to install wide operation temperature memory and storage devices when system work under rush environment. ©Vecow MTC-8000 User Manual...
  • Page 6: Table Of Contents

    2.1 Packing List 2.2 I/O & Functions 2.3 Connector/Jumper Locations 2.4 Main Board Jumper Settings CHAPTER 3 SYSTEM SETUP 3.1 Installing HDD/SDD Storage Devices 3.1.1 MTC-8010 3.1.2 MTC-8015/8015W/8021W 3.2 Installing Mini PCIe Cards 3.3 Mounting For MTC-8000 Series ©Vecow MTC-8000 User Manual...
  • Page 7 CHAPTER 4 BIOS SETUP 4.1 Entering Setup 4.2 Main Menu 4.3 Advanced 4.4 Chipset 4.5 Security 4.6 Boot 4.7 Save & Exit ©Vecow MTC-8000 User Manual...
  • Page 8: Chapter 1 General Introduction

    GENERAL INTRODUCTION 1.1 Overview Vecow's MTC-8000 series products are 10.1", 15", 15.6", and 21.5 fanless, high performance, low-power, all-in-one multi-touch panel computers which use as control panel on automation equipment, HMI for production line, control panel for self-service devices in digital signage, showroom interactive signage, and public service terminals, like meeting room control panel.
  • Page 9: Features

    • 2 GigE LAN Supporting IEEE 1588 Precision Time Protocol (PTP) • Supports Landscape and Portrait screen • DC 9V to 36V Wide Range Power Input (MTC-8010W is DC 12V) • 2 Mini PCIe for WiFi/4G/3G/LTE/GPRS/UMTS • IP65 Front Panel Protection • Fanless Design ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 10: Product Specification

    1 2.5" SATA III (6Gbps) mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Expansion 2 Full Size Mini PCIe Socket : Mini PCIe • 1 Full-size for PCIe/USB/Internal SIM Card • 1 Full-size for PCIe/USB/mSATA ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 11 10% to 95% Humidity, non-condensing Relative Humidity 95% at 60°C • IEC 60068-2-27 Shock • 20G, Half-sine, 11ms • IEC 60068-2-64 Vibration • Non-operation : 10Hz to 200Hz, 1Grms, X, Y, Z, 30 mins each Axis CE, FCC ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 12: Specifications Of Mtc-8015

    1 2.5" SATA III (6Gbps) mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Expansion 2 Full Size Mini PCIe Socket : Mini PCIe • 1 Full-size for PCIe/USB/Internal SIM Card • 1 Full-size for PCIe/USB/mSATA ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 13 10% to 95% Humidity, non-condensing Relative Humidity 95% at 60°C • IEC 60068-2-27 Shock • 20G, Half-sine, 11ms • IEC 60068-2-64 Vibration • Non-operation : 10Hz to 200Hz, 1Grms, X, Y, Z, 30 mins each Axis CE, FCC ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 14: Specifications Of Mtc-8015W

    1 2.5" SATA III (6Gbps) mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Expansion 2 Full Size Mini PCIe Socket : Mini PCIe • 1 Full-size for PCIe/USB/Internal SIM Card • 1 Full-size for PCIe/USB/mSATA ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 15 10% to 95% Humidity, non-condensing Relative Humidity 95% at 60°C • IEC 60068-2-27 Shock • 20G, Half-sine, 11ms • IEC 60068-2-64 Vibration • Non-operation : 10Hz to 200Hz, 1Grms, X, Y, Z, 30 mins each Axis CE, FCC ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 16: Specifications Of Mtc-8021W

    1 2.5" SATA III (6Gbps) mSATA 1 SATA III (Mini PCIe Type, 6Gbps) Expansion 2 Full Size Mini PCIe Socket : Mini PCIe • 1 Full-size for PCIe/USB/Internal SIM Card • 1 Full-size for PCIe/USB/mSATA ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 17 10% to 95% Humidity, non-condensing Relative Humidity 95% at 60°C • IEC 60068-2-27 Shock • 20G, Half-sine, 11ms • IEC 60068-2-64 Vibration • Non-operation : 10Hz to 200Hz, 1Grms, X, Y, Z, 30 mins each Axis CE, FCC ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 18: Mechanical Dimension

    218.0 (8.58) 1.4.2 MTC-8015 Mechanical Drawing 339.4 (13.36”) Unit : mm (inch) 157.0 (6.18”) 77.1 (3.04”) 67.0 (2.64”) 360.9 (14.21”) 28.0 (1.10”) 306.0 (12.04”) 100.0 (3.94”) Active View 75.0 (2.95”) 8-M4 For VESA MOUNT ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 19: Mtc-8015W Mechanical Drawing

    8-M4 For VESA MOUNT 1.4.4 MTC-8021W Mechanical Drawing 515.0 (20.28”) Unit : mm (inch) 157.0 (6.18”) 77.1 (3.04”) 67.0 (2.64”) 537.8 (21.17”) 28.0 (1.10”) 477.6 (18.80”) 100.0 (3.94”) Active View 75.0 (2.95”) 8-M4 For VESA MOUNT ©Vecow MTC-8000 User Manual GENERAL INTRODUCTION...
  • Page 20: Chapter 2 Getting To Know Your Mtc-8000

    GETTING TO KNOW YOUR MTC-8000 2.1 Packing List Item Description MTC-8000 Series Panel PC, (10.1" – 21.5") Driver/User Manual DVD • Waterproof rubber when panel mount use • Mounting clip • M2.5x6L screw for Mini PCIe Socket (P/N : 53-2426906-30B) •...
  • Page 21: I/O & Functions

    2.2.2 Power Input MTC-8000 supports 9V to 36V DC power input. Note : MTC-8010W is only DC 12V power input only Pin No. Definition Earth GND ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 22 2 standard USB 3.0 connections available supporting up to 5GB per second data rate. It also compliant with the requirements of Super Speed (SS), high speed (HS), full speed (FS) and low speed (LS). ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 23 Serial port can be configured for RS-232, RS-422, or RS-485 with auto flow control communication. The default definition is RS-232, but if you want to change to RS-422 or RS-485, you can find the settings in BIOS. ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 24 (9-wire) (3-wire) TXD- TXD- DATA- TXD+ TXD+ DATA+ RXD+ RXD+ ----------- RXD- RXD- ----------- 1, 2 ----------- RTS- ----------- ----------- RTS+ ----------- ----------- CTS+ ----------- ----------- CTS- ----------- TXD- TXD- DATA- ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 25: Connector/Jumper Locations

    2.3 Connector/Jumper Locations CON1 CN18 CPU_FAN1 CN 15 CN 13 CN 16 CN14 SO-DIMM1 JDIO1 JPS2 JUSB1 JDIO2 VGA2 JHDD1 CN10 CN12 CN11 JPWBTN1 JRESET1 JSTATUS1 ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 26 The pinouts of Miscellaneous port are listed in following table : Group Pin No. Description JPWBTN FP_PWR_BTN_IN JRESET FP_RST_BTN_N PWR_LED_N JSTATUS PWR_LED_P HDD_LED_N JHDD HDD_LED_P 2.3.2 JP5, CN15 : Mini PCIe, mSATA CN 15 ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 27 Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERp0 PERn0 +3.3Vaux PERST# Reserved Reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 28 Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERp0 PERn0 +3.3Vaux PERST# Reserved Reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 29 TXD- TXD- DATA- TXD+ TXD+ DATA+ RXD+ RXD+ ----------- RXD- RXD- ----------- 1, 2, 3, 4 ----------- RTS- ----------- ----------- RTS+ ----------- ----------- CTS+ ----------- ----------- CTS- ----------- TXD- TXD- DATA- ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 30: Main Board Jumper Settings

    To "open" a jumper, you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2, and 3. In this case you would connect either pins 1 and 2, or 2 and 3. Open Closed Closed 2-3 ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 31 JP3 provides LVDS voltage selection function, Closing Pin 1 and Pin 2 is for 3.3V LVDS power input; closing Pin 2 and Pin 3 is for 5V LVDS power input. Pin No. Function +3.3V (Default) +5V System Power ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 32 2.4.4 JP4 : USB Power Select Pin No. Function +5V Standby Power (Default) +5V System Power 2.4.5 JP5 : CN13 mSATA/Mini PCIe; CN1 SATA/NC Select Pin No. CN15 1-3/2-4 mSATA Mini PCIe (Default) SATA (Default) ©Vecow MTC-8000 User Manual GETTING TO KNOW YOUR MTC-8000...
  • Page 33: Chapter 3 System Setup

    Step 4 Lock up 4pcs screws (marked in red) to fix the SSD/HDD on the tray. Note 1 : We strongly recommend you to buy wide temp. RAM and pre-install by VECOW for MTC-8000 series panel pc. Note 2 : We strongly recommend you to buy storage and pre-install by VECOW for MTC-8010W, 10.1"...
  • Page 34: Mtc-8015/8015W/8021W

    3.1.2 MTC-8015/8015W/8021W Step 1 Remove 4pcs screws from external storage cover. Step 2 Loosen 2pcs screws from SSD/HDD bracket. ©Vecow MTC-8000 User Manual SYSTEM SETUP...
  • Page 35 Step 3 Put 2.5" SDD/HDD on HDD bracket and lock up storage with 4 pcs screws on the 2.5" SSD/HDD back side. Note : Please notice direction of SATA connector when lock up storage device. SATA Connector on this side ©Vecow MTC-8000 User Manual SYSTEM SETUP...
  • Page 36 Note 1 : We strongly recommend you to buy wide temp. RAM and pre-install by VECOW for MTC-8000 series panel pc. Note 2 : We strongly recommend you to buy storage and pre-install by VECOW for MTC-8010W, 10.1" Multi-touch panel pc.
  • Page 37: Installing Mini Pcie Cards

    Step 1 Remove 4pcs screws from system chassis. Step 2 Install Mini PCIe card into Mini PCIe socket. Step 3 Install Mini PCIe card into the Step 4 Fasten one M2.5 screw. Mini PCIe slot. ©Vecow MTC-8000 User Manual SYSTEM SETUP...
  • Page 38: Mounting For Mtc-8000 Series

    3.3 Mounting For MTC-8000 Series Step 1 Put the panel PC into the wall or device you want. Step 2 Put our panel mounting clips and fasten it to panel mount hole. Step 3 Lock screw and finish. ©Vecow MTC-8000 User Manual...
  • Page 39: Chapter 4 Bios Setup

    Figure 4-1 : Entering Setup Screen BIOS provides an interface for users to check and change system configuration. The BIOS setup program is accessed by pressing the <Del> key when POST display output is shown. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 40: Main Menu

    Set the time. Use <Tab> to switch between time elements. 4.3 Advanced Figure 4-3 : BIOS Advanced menu Select advanced tab to enter advanced BIOS setup options, such as CPU configuration, Network configuration, and USB configuration. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 41 Serial Port 1 to port 4 Configuration Options for Serial Port 1 to Serial Port 4. Entering the corresponding Port option then end user can change the settings such as I/O resource and UART mode. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 42 Both computers should have the same or compatible settings. Legacy Console Redirection Legacy Console Redirection Settings. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console redirection enable or disable. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 43 Enable this to disable core in each processor package. Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. VT-d Enable/Disable CPU VT-d. Figure 4-3-6-2 : CPU Information Socket specific CPU Information. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 44 Enable Ipv6 PXE boot Support. If disabled IPV6 PXE boot option will not be created. PXE boot wait time Wait time to press ESC key to abort the PXE boot. Media detect count Number of times presence of media will be checked. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 45 Controls the execution of UEFI and Legacy Storage OpROM. Video Controls the execution of UEFI and Legacy Video OpROM. Other PCI devices Determines OpROM execution policy for devices other than Network, Storage, or Video. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 46: Chipset

    Figure 4-4-1 : North Bridge Settings Max TOLUD Maximum Value of TOLUD. Above 4GB MMIO BIOS assignment Enable/Disable above 4GB MemoryMappedIO BIOS assignment. This is disabled automatically when Aperture Size is set to 2048MB. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 47 Select the target OS. 4.4.3 LVDS Configuration Figure 4-4-3 : LVDS Panel Settings The LVDS Configuration option will be present if LVDS panel is connected on system. LCD Panel Type Select LCD Panel Resolution. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 48 Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device DVMT Total Gfx Mem Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device Cd Clock Frequency Select the highest Cd Clock frequency supported by the platform ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 49 Compliance Mode Enable/Disable. Riser Card Slot Riser Card Slot settings. Intel(R) Ethernet Controller I210 Intel(R) Ethernet Controller I210 Settings Mini PCIe Slot with SMI Mini PCIe Slot with SIM settings. Mini PCIe/mSATA Mini PCIe/mSATA Slot Settings. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 50 Otherwise all drives spin up at boot. SATA Device Type Identify the SATA port is connected to Solid State Drive or Hard Disk Drive. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 51 Enable/Disable the SC BIOS Lock Enable feature. Required to be enabled to ensure SMM protection of flash. RTC Lock Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. Flash Protection Range Registers (FPRR) Enable Flash Protection Range Registers. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 52: Security

    Discard or save changes option in setup dies not have any impact on HDD when password is set or removed. If the "Set HDD User Password" option is grayed out, do power cycle to enable the option again. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 53: Boot

    Select the keyboard NumLock state. Quiet Boot Enables or disables Quiet Boot option. Boot Option #x Sets the system boot order. New Boot Option Policy Controls the placement of newly detected UEFI boot options. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 54: Save & Exit

    Restore Defaults Restore/Load Default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options. ©Vecow MTC-8000 User Manual BIOS SETUP...
  • Page 55 No part of this publication may be reproduced in any form or by any means, electric, photocopying, or recording, without prior authorization from the publisher. The rights of all the brand names, product names, and trademarks belong to their respective owners. © Vecow Co., Ltd. 2021. All rights reserved.
