  • Page 1 USER USER ECX-1200/1100 Manual Manual Gen Intel ® Xeon ® /Core™ i7/i5/i3 Expandable Fanless System Workstation-grade, 6 GigE LAN w/4 M12 PoE , 2 SSD Tray, PCI/PCIe Slot 1.0.0 Edition 20190115...
  • Page 2 Record of Revision Version Date Page Description Remark 0.10 2019/01/09 Preliminary Release 1.00 2019/01/15 Official Release ©Vecow ECX-1200/1100 User Manual...
  • Page 3 This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation or any infringements upon the rights of third parties, which may result from such use.
  • Page 4 , 2 SSD Tray, 6 USB 3.1, 4 COM, 3 SIM, 32 Isolated DIO ® ® ECX-1100 with NVIDIA GeForce GTX 1050, 2 GigE LAN, ECX-1100 GTX1050 2 SSD Tray, 6 USB 3.1, 4 COM, 3 SIM, 16 GPIO ©Vecow ECX-1200/1100 User Manual...
  • Page 5 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm Terminal Board with One 20-pin Terminal Block Connector and TMB-TMBK-20P DIN-Rail Mounting 4G Module Mini PCIe 4G/GPS Module with Antenna WiFi & Bluetooth WiFi & Bluetooth Module with Antenna ©Vecow ECX-1200/1100 User Manual...

  • Page 6: Table Of Contents

    Table of Contents CHAPTER 1 GENERAL INTRODUCTION 1.1 Overview 1.2 Features 1.3 Product Specification 1.3.1 Specifications of ECX-1210M 1.3.2 Specifications of ECX-1201M 1.3.3 Specifications of ECX-1210 1.3.4 Specifications of ECX-1201 1.3.5 Specifications of ECX-1110 1.3.6 Specifications of ECX-1101 1.3.7 Specifications of ECX-1200 GTX1050 1.3.8 Specifications of ECX-1100 GTX1050...
  • Page 7 4.5 Security 4.6 Boot 4.7 Save & Exit APPENDIX A : Isolated DIO Guide APPENDIX B : Software Functions APPENDIX C : RAID Functions APPENDIX D : Power Consumption APPENDIX E : Supported Memory & Storage List ©Vecow ECX-1200/1100 User Manual...

  • Page 8: Chapter 1 General Introduction

    GENERAL INTRODUCTION 1.1 Overview Vecow ECX-1200/1100 Series is a compact and rugged workstation-grade expandable Fanless Embedded System. LGA1151 Socket supports workstation- ® ® grade 6-core 8th Generation Intel Xeon /Core™ i7/i5/i3 processor (Coffee ® Lake-S) running with workstation-grade Intel C246 chipset, dual channel DDR4 ®...

  • Page 9: Features

    HD displays (ECX-1200/1100 GTX1050) • 6V to 36V DC Power Input with 80V Surge Protection • 12V to 36V DC Power Input with 80V Surge Protection (ECX-1200/1100 GTX1050) • Configurable Ignition Power Control ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 10: Product Specification

    1.3 Product Specification 1.3.1 Specifications of ECX-1210M System ® ® Processor 6 cores Intel Xeon /Core™ i7/i5/i3 Processor (Coffee Lake-S) ® Chipset Intel C246 Chipset BIOS IT8786E Memory • DDR4 2666MHz (ECC/Non-ECC) • Up to 64GB • 2 260-pin SO-DIMM Socket...
  • Page 11 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 12: Specifications Of Ecx-1201M

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 13 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 14: Specifications Of Ecx-1210

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 15 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 16: Specifications Of Ecx-1201

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 17 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 18: Specifications Of Ecx-1110

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 19 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 20: Specifications Of Ecx-1101

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 21 Relative Humidity 95% at 75°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 22: Specifications Of Ecx-1200 Gtx1050

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 23 Relative Humidity 95% at 60°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 24: Specifications Of Ecx-1100 Gtx1050

    • 2 Front-access 2.5" SSD/HDD Tray Audio Audio Codec Realtek ALC892, 5.1 Channel HD Audio Audio Interface 1 Mic-in, 1 Line-out Ethernet ® LAN 1 Intel I219LM GigE LAN supports iAMT 12.0 ® LAN 2 Intel I210 GigE LAN ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...
  • Page 25 Relative Humidity 95% at 60°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN50155, EN50121-3-2 ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 26: Supported Cpu List

    ® Intel Core™ i3-8100 Up to 3.6GHz ® Intel Core™ i3-8100T Up to 3.1GHz 1.5 Mechanical Dimension 1.5.1 Dimensions of ECX-1210M 297.0 (11.69”) Unit : mm (inch) 282.0 (11.10”) 260.0 (10.24”) 5.0 (0.20”) A Detail 260.0 (10.24”) 13.0 (0.51”) 107.5 (4.23”) 94.5 (3.72”)

  • Page 27: Dimensions Of Ecx-1210

    107.5 (4.23”) 94.5 (3.72”) 215.0 (8.46”) 1.5.5 Dimensions of ECX-1110 297.0 (11.69”) 282.0 (11.10”) Unit : mm (inch) 260.0 (10.24”) 5.0 (0.20”) A Detail 260.0 (10.24”) 13.0 (0.51”) 107.5 (4.23”) 94.5 (3.72”) 215.0 (8.46”) ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 28: Dimensions Of Ecx-1101

    107.5 (4.23”) 94.5 (3.72”) 215.0 (8.46”) 1.5.8 Dimensions of ECX-1100 GTX1050 297.0 (11.69”) 282.0 (11.10”) Unit : mm (inch) 260.0 (10.24”) 5.0 (0.20”) A Detail 260.0 (10.24”) 13.0 (0.51”) 107.5 (4.23”) 94.5 (3.72”) 215.0 (8.46”) ©Vecow ECX-1200/1100 User Manual GENERAL INTRODUCTION...

  • Page 29: Chapter 2 Getting To Know Your Ecx-1200/1100

    ECX-1200 Expandable Fanless Embedded System (According to the configuration of you order, the ECX-1200 series may contain SSD/ HDD and DDR4 SO-DIMM. Please verify these items if necessary.) ECX-1200 series accessory box, which contains • Vecow Drivers & Utilities DVD Item Description Outlook...
  • Page 30 ECX-1100 Expandable Fanless Embedded System (According to the configuration of you order, the ECX-1100 series may contain SSD/ HDD and DDR4 SO-DIMM. Please verify these items if necessary.) ECX-1100 series accessory box, which contains • Vecow Drivers & Utilities DVD Item Description Outlook...

  • Page 31: Front Panel I/O Functions

    2.2 Front Panel I/O Functions In Vecow ECX-1200/1200M/1100 series family, all I/O connectors are located on front panel and rear panel. Most of the general connections to computer device, such as USB, LAN Jack, Display, VGA, DVI-D, Display Port and any additional storage, are placed on the front panel.
  • Page 32 The pinouts of CFast port are listed as follows : Pin No. Description Pin No. Description SATA_TXP6 SATA_TXN6 CFAST_LED SATA_RXN6 PC10 SATA_RXP6 PC11 PC12 PC13 +3.3V PC14 +3.3V PC15 PC16 PC17 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 33 1920 x 1200 resolution. The DVI is automatically selected according to the display device connected. You will need a DVI-D cable when connecting to a display device. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 34 DVI-D LAN 1 / LAN 2 SIM 1 WLAN CFast ANT 3 ANT 4 Onboard Display Port support auxiliary channel dual mode, connection supports up to 4096x2304 resolution at 60 Hz. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 35 Mini PCIe Slot/SIM Slot/WLAN LED Mapping Table : Mini PCIe SIM 2 SIM 3 MPCIe 1 SIM 1 (CN19) SIM 1 MPCIe 2 SIM 2 (CN20) M.2 KEY B SIM 3 (CN21) Mini-PCIe2 M.2 Key B Mini-PCIe1 CN19 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 36 The pin-outs of LAN 1 and LAN 2 are listed as follows : Pin No. 10/100 Mbps 1000Mbps E_TX+ MDI0_P E_TX- MDI0_N E_RX+ MDI1_P ----- MDI2_P ----- MDI2_N E_RX- MDI1_N ----- MDI3_P ----- MDI3_N ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 37 ANT 3 ANT 4 There are 2 front-access 2.5" SSD/HDD trays in the front side of ECX- 1200/1200M/1100 series. Just trigger to open the SSD/HDD tray, up to 4TB is available. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...

  • Page 38: Rear Panel I/O & Functions

    You could turn on or off the system power by using this contact. This terminal block supports dual function of soft power-on/power-off (instant off or delay 4 second), and suspend mode. Pin No. Definition Pin No. Definition Ignition ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 39 INPUT 4 SIO_GPI74 INPUT 5 SIO_GPI75 INPUT 6 SIO_GPI76 DIO 1 INPUT 7 SIO_GPI77 DI_COM DIO_GND OUTPUT 0 SIO_GPO80 OUTPUT 1 SIO_GPO81 OUTPUT 2 SIO_GPO82 OUTPUT 3 SIO_GPO83 OUTPUT 4 SIO_GPO84 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 40 DIO2_GND DIO 2 OUTPUT 0 SIO_GPO22 OUTPUT 1 SIO_GPO26 OUTPUT 2 SIO_GPO64 OUTPUT 3 SIO_GPO65 OUTPUT 4 SIO_GPO41 OUTPUT 5 SIO_GPO40 OUTPUT 6 SIO_GPO52 OUTPUT 7 SIO_GPO27 DIO2_GND DIO2_VDC (6~48V Input) ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 41 GPIO Connectors pin assignments Mapping to SIO GPIO Mapping to SIO GPIO Pin No. Pin No. Function Function SIO_GPI37 SIO_GPO22 SIO_GPI56 SIO_GPO26 SIO_GPI57 SIO_GPO64 SIO_GPI15 SIO_GPO65 SIO_GPI16 SIO_GPO41 SIO_GPI35 SIO_GPO40 SIO_GPI46 SIO_GPO52 SIO_GPI11 SIO_GPO27 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 42 Port (5-wire) (9-wire) (3-wire) TXD- TXD- DATA- TXD+ TXD+ DATA+ RXD+ RXD+ ----------- RXD- RXD- ----------- 1 to 4 ----------- RTS- ----------- ----------- RTS+ ----------- ----------- CTS+ ----------- ----------- CTS- ----------- ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 43 COM Port MB Connector COM Port MB Connector COM 1 CN13 COM 2 CN14 COM 3 CN15 COM 4 CN16 Pin No. Signal Name CN13 to CN16 CN16 CN15 CN14 CN13 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 44 The pin-outs of LAN 3 and LAN 6 are listed as follows : Pin No. 10/100 Mbps 1000Mbps E_TX+ MDI0_P PoE+ E_TX- MDI0_N PoE+ E_RX+ MDI1_P PoE- ----- MDI2_P ---- ----- MDI2_N ---- E_RX- MDI1_N PoE- ----- MDI3_P ---- ------ MDI3_N ---- ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 45 2.3.6 Add Card ECX-1210M/1201M : ECX-1210/1201 : ECX-1110/1101 : There is the flexible expansion feature in the rear side of ECX-1110/1101/1210/1201/ 1210M/1201M. Optional for PCIe x16 FHHL add on card or PCI card. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 46 2.3.7 GTX 1050 graphic card ECX-1200 GTX1050 : ECX-1100 GTX1050 : ECX-1200/1100 with GTX1050 support GTX1050 graphic card only. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...

  • Page 47: Main Board Expansion Connectors

    2.4.1 Top View (Component Side) of ECX-1200/1200M/1100 Main Board With Connector Location CPU_FAN1 CN16 CN15 CN31 CN14 CN13 CN17 SODIMM_2 CN18 SATA2 SATA1 SODIMM_1 SATA4 SATA3 MPCIE2 M2_CN3 M2_CN2 M2_CN1 MPCIE1 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 48 2.4.2 Bottom View (Solder Side) of ECX-1200/1200M/1100 Main Board With Connector Location CN20 CN21 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 49 1100. It supports higher storage capacity with less cabling effort and smaller required space. The pin assignments of SATA1 and SATA2 are listed in the following table : SATA2 SATA1 Pin No. Definition Pin No. Definition ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 50 It also compliant with the requirements of SuperSpeed (SS), high speed (HS), full speed (FS) and low speed (LS). The pin assignments of CN14 are listed in the following table : Pin No. Description Pin No. Description USB_VCC USBD+ USBD- ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 51 SODIMM_2 SODIMM_1 Slot Description SODIMM_1 DDR4 Channel A SODIMM_2 DDR4 Channel B 2.4.8 CN1 : BIOS Socket If the BIOS needs to be changed, please contact the Vecow RMA service team. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 52 Pin No. Description Pin No. Description +VDC_IN +VDC_IN (6~36V, Max.9A) (6~36V, Max.9A) +VDC_IN Ground (6~36V, Max.9A) Ground Ground 2.4.10 Mini PCIe : MPCIe_1, MPCIe_2 Standard full length mini PCIe slot MPCIE2 MPCIE1 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 53 Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERp0 PERn0 +3.3Vaux PERST# Reserved reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 54 The system's real-time clock is powered by a lithium battery. It is Equipped with Panasonic BR2032 190mAh lithium battery. It is recommended that you not replace the lithium battery on your own. If the battery needs to be changed, please contact the Vecow RMA service team. BAT1 2.4.12 CPU_FAN1 : FAN Header Fan power connector supports for additional thermal requirements.
  • Page 55 The system's provide a LPC Port 80 Header for Debug Card. Pin No. Definition Pin No. Definition SERIRQ LFRAME# +3.3V LAD0 RESET# Ground LAD1 CLOCK LAD2 Ground 2.4.14 ECX-1200M CN17 : support M12 connector CN17 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 56 2.4.15 M2_CN1, M2_CN2, M2_CN3 : M.2 slot 2280 length and 2230 length M.2 slot The pin assignments of M2_CN1, M2_CN2, M2_CN3 in the following table : M2_CN3 M2_CN2 M2_CN1 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 57 REFCLKp REFCLKn PEWAKE# Ground CLKREQ# PETn0/SATA-A+ PERST# PETn0/SATA-A- Ground PERn0/SATA-B- PERn0/SATA-B+ Ground DEVSLP UIM-PWR Ground UIM-DATA UIM-CLK UIM-RESET Ground Mechanical Key Ground USB- LED_1# USB+ W_DISABLE1 FULL_CARD_PWR_OFF/ Ground Ground 3.3V 3.3V ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 58 Ground PERp0/SATA_B- PERn0/SATA_B+ Ground PETp1 DEVSLP PETn1 Ground PERp1 PERn1 Ground PETp2 PETn2 Ground PERp2 PERn2 3.3V Ground 3.3V PETp3 3.3V PETn3 3.3V Ground LED1# PERp3 PERn3 Ground 3.3V Ground 3.3V ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 59 Ground ALERT I2C_CLK Ground I2C_DATA PEWAKE0# CLKREQ0# Ground PERST0# REFCLKn0 REFCLKp0 Ground PERn0 PERp0 Ground PETn0 DEVSLP PETp0 Ground Mechanical Key Ground Ground Ground Ground USB- LED1# USB+ 3.3V Ground 3.3V ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...

  • Page 60: Main Board Jumper Settings

    You may configure your card to match the needs of your application by DIP switch. As below show the deep switch on and off. 1 : OFF 1 : ON 1 : ON 2 : OFF 2 : OFF 2 : ON ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 61 2 : 3 Non Wake Up support 1 : 2 Supported Wake Up (Default) SIM 2 SIM 3 DVI-D LAN 1 / LAN 2 SIM 1 WLAN CFast ANT 3 ANT 4 ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 62 3 - 4 +12V (0.5A max.) 5 - 6 RI (Default) COM3 to COM4 7 - 8 +5V (1A max.) 9 - 10 +12V (0.5A max.) 11 - 12 RI (Default) ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 63 2 : 3 PoE power on after system power on (Default) 2.5.5 JCMOS1 : CMOS JCMOS1 Jumper Setting Function JCMOS1 1 : 2 *Normal (Default) JCMOS1 2 : 3 Clear CMOS ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...

  • Page 64: Ignition Control

    2.6.1 Adjust Ignition Control Modes ECX-1200/1200M/1100 series provides 16 modes of different power on/off delay periods adjustable via SW2 switch. The default rotary switch is set to 0 in ATX/ AT power mode. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 65 5 seconds 30 minutes 5 seconds 1 hour 10 seconds 2 hours 10 seconds 4 hours 10 seconds 6 hours 10 seconds 8 hours 10 seconds 12 hours 10 seconds 24 hours ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...
  • Page 66 3. For proper ignition control, the power button setting should be "Power Down" mode. In Windows for example, you need to set "When I press the power button" to Shut down. ©Vecow ECX-1200/1100 User Manual GETTING TO KNOW YOUR ECX-1200/1100...

  • Page 67: Chapter 3 System Setup

    SYSTEM SETUP 3.1 How to Open Your ECX-1200/1100 Step 1 Remove six PHILLIPS#6-32 screws and two cover. Step 2 Take off the PCI/PCIe tray. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 68 Step 3 Remove two PHILLIPS#6-32 screws. Step 4 Turn over ECX-1200 to face the front side. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 69 Step 5 Remove one HEX#6-32 screw. Step 5 Remove one HEX#6-32 screw. Step 6 Take out SSD/HDD tray module. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 70: Installing Cpu

    Step 7 Finish. 3.2 Installing CPU 3.2.1 ECX-1200/1100 Step 1 Remove SATA DATA, SATA Power and COM cable. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 71 Step 2 Remove five HEX#6-32 and four HEX#4-40 screws. Step 3 Remove front panel and turn over to face the rear side. Step 4 Remove four HEX#6-32 screws. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 72 Step 5 Remove rear panel. Step 6 Remove twelve PHILLIPS M3 screws and take out main board from the heat sink. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 73 Step 7 Turn over the main board to make the CPU socket side up. Step 8 Unlock the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 74 Step 9 Open the CPU socket cover. Step 10 Watch out the direction of CPU and put CPU into the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 75 Step 11 Remove the mylar from CPU cover and lock the cover. Step 12 Cover and lock the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 76 3.2.2 ECX-1200M Step 1 Remove SATA DATA, SATA Power and COM cable. Step 2 Remove five HEX#6-32 and four HEX#4-40 screws. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 77 Step 3 Remove front panel and turn over to face the rear side. Step 4 Remove four HEX#6-32 screws. Step 5 Remove rear panel. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 78 Step 6 Remove two PHILLIPS M3 screws. Step 7 Remove ten PHILLIPS M3 screws and two stand off M3*16mm. Take out main board from the heat sink ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 79 Step 8 Turn over the main board to make the CPU socket side up. Step 9 Unlock the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 80 Step 10 Open the CPU socket cover. Step 11 Watch out the direction of CPU and put CPU into the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 81 Step 12 Remove the mylar from CPU cover and lock the cover. Step 13 Cover and lock the CPU socket. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 82: Installing Ddr4 So-Dimm Modules

    3.3 Installing DDR4 SO-DIMM Modules Step 1 DDR4 SO-DIMM socket. Step 2 Install DDR4 RAM module Step 3 Install DDR4 RAM module into SO-DIMM socket and into SO-DIMM socket and locked. locked. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 83: Installing Mini Pcie Card

    3.4 Installing Mini PCIe Card Step 1 Mini PCIe socket. Step 2 Install Mini PCIe card into Step 3 Fasten PHILLIPS M2.5 socket. screw. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 84: Installing Antenna Cable

    3.5 Installing Antenna Cable Step 1 Check Antenna cable and washer. Step 2 Fasten washer 1 and 2. Step 3 Finished. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 85: Installing Cfast Card

    Step 2 Remove CFast & SIM Card cover. Step 3 Before Inserting CFast & SIM Card, make sure the system power is not plugged. Step 4 Insert CFast card and push to lock. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 86: Installing Sim Card

    Step 2 Remove CFast & SIM Card cover. Step 3 Before Inserting CFast & SIM Card, make sure the system power is not plugged. Step 4 Insert SIM card and push to lock. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 87: Installing Pci/Pcie Card

    3.8 Installing PCI/PCIe Card Step 1 Remove PCI bracket and PHILLIPS#6-32 screw. Step 2 Match the PCI/PCIe card and the tray. Step 3 Fasten PHILLIPS#6-32 screw. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 88: Installing Ssd/Hdd

    3.9 Installing SSD/HDD Step 1 Unlock SSD/HDD tray. Step 2 Pull the trigger and open SSD/HDD tray. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 89 Step 3 Install 2.5" SSD/HDD into the tray and then push back to close the tray. Step 4 Lock the SSD/HDD tray with key. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 90: Installing

    3.10 Installing M.2 Step 1 M.2 socket. Step 2 Install M.2 into socket and fasten 1pcs PHILLIPS M3 screw. ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 91: Mounting Your Ecx-1200/1200M/1100 Series

    3.11 Mounting Your ECX-1200/1200M/1100 series 3.11.1 Wall mount Fasten six PHILLIPS#10-32 screws. 260.0 (10.24”) 3.11.2 VESA mount Fasten six PHILLIPS#10-32 screws. VESA 75 x 75/100 x 100 mm 100.0 (3.94”) 75.0 (2.95”) 260.0 (10.24”) ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...
  • Page 92 3.11.3 Din Rail Kit Fasten six PHILLIPS#10-32 screws. 260.0 (10.24”) 3.11.4 2U rack mount kit 241,0 (9,49”) 482.6 (19.00”) 217.0 (8.54”) ©Vecow ECX-1200/1100 User Manual SYSTEM SETUP...

  • Page 93: Bios Setup

    Figure 4-1 : Entering Setup Screen BIOS provides an interface for users to check and change system configuration. The BIOS setup program is accessed by pressing the <Del> key when POST display output is shown. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 94: Main

    Set the time. Use <Tab> to switch between time elements. 4.3 Advanced Figure 4-3 : BIOS Advanced Menu Select advanced tab to enter advanced BIOS setup options, such as CPU configuration, SATA configuration, and USB configuration. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 95 Technology). When disabled only one thread per core is enabled. Enable/disable CPU Advanced Encryption Standard instructions. Intel Trusted Execution Technology Enables utilization of additional hardware capabilities provided by Intel Trusted Execution Technology. Changes require a full power cycle to take effect. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 96 CPPCv2 interface to allow for hardware controlled P-states. Turbo Mode Turbo Mode. C states Enable or disable CPU C states. Enhanced C-states Enable/disable C1E. When enabled, CPU will switch to minimum speed when all cores enter C-State. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 97 When disabled AMT BIOS Features are no longer supported and user is no longer able to access MEBx Setup. AMT Configuration ® Configure Intel Active Management Technology Parameters. ME Unconfig on RTC Clear State Disabling this option will cause ME not to unconfigure on RTC clear. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 98 Enables or disables S3 video repost. 4.3.6 SMART Settings Figure 4-3-6 : SMART Settings SMART Self Test Run SMART self test on all HDDs during POST. 4.3.7 IT8786 Super IO Configuration Figure 4-3-7 : IT8786 Super IO Settings ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 99 Temperature Limit value of Fan Start (Degree C). (Range : 10~80) PWM Start Value (%) Default PWM Value of Fan. (Range : 15%~100%) Full Speed Temperature Temperature Limit value of Fan Full Speed (Degree C). (Range : 50~90) ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 100 Legacy Console Redirection Legacy Console Redirection Settings. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console redirection enable or disable. 4.3.10 Intel TXT Information Figure 4-3-10 : Intel TXT Information Display Intel TXT information. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 101 Globally Enables or Disables Hot-Plug support for the entire System. If system has Hot-Plug Capable Slots and this option set to Enabled, it provides a Setup screen for selecting PCI resource padding for Hot-Plug. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 102 IP6 Configuration Policy Set IP6 Configuration Policy. PXE boot wait time Wait time to press ESC key to abort the PXE boot. Media detect count Number of times presence of media will be checked. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 103 Controls the execution of UEFI and Legacy Storage OpROM. Video Allows more than two frequency ranges to be supported. Other PCI devices Determines OpROM execution policy for devices other than network, storage, or video. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 104 Maximum time the device will take before it properly reports itself to the Host Controller. 'Auto' uses default value, for a root port it is 100 ms, for a hub port the delay is taken from the hub descriptor. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 105: Chipset

    VT-d capability. Above 4GB MMIO BIOS assignment Enable/disable above 4GB MemoryMappedIO BIOS assignment. This is disabled automatically when aperture size is set to 2048MB. 4.4.1.1 Memory Configuration Figure 4-4-1-1 : Memory Information Displays memory information. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 106 2048MB aperture. To use this feature, please disable CSM Support. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. DVMT Total Gfx Mem Select DVMT5.0 Total Graphic Memory size used by the Internal Graphics Device. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 107 Specify what state to go to when power is re-applied after a power failure (G3 state). S0 State : Always turn-on the system when power source plugged-in. S5 State : Always turn-off the system when power source plugged-in. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 108 Enable/Disable the control of Active State Power Management on SA side of the DMI Link. Native PCIE Enable PCIE Express Native Support Enable/Disable. PCI Express device settings Bios options for PCI Express device setting. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 109 On an edge detect from 0 to 1, the PCH starts a COMRESET initialization sequence to the device. SATA Device Type Identifies that the SATA port is connected to solid state drive or hard disk drive. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 110: Security

    BIOS Lock Enable/disable the PCH BIOS Lock Enable (BLE bit) feature. 4.5 Security Figure 4-5 : BIOS Security Menu Administrator Password Set administrator password. User Password Set user password. Secure Boot Customizable Secure Boot Settings. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...
  • Page 111 User/Deployed, and CSM function is disabled. Secure Boot Mode Secure Boot mode selector Standard/Custom. In custom mode Secure Boot Variables can be configured without authentication Key Management Enables expert users to modify Secure boot policy variables without full authentication ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 112: Boot

    Boot Option Sets the system boot order. New Boot Option Policy Controls the placement of newly detected UEFI boot options. Hard Drive BBS Priorities Set the order of the Legacy devices in this group. ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 113: Save & Exit

    Restore Defaults Restore/Load Default values for all the setup options. Save as User Defaults Save the changes done so far as User Defaults. Restore User Defaults Restore the User Defaults to all the setup options ©Vecow ECX-1200/1100 User Manual BIOS SETUP...

  • Page 114: Appendix A : Isolated Dio Guide

    DIO 12 DI 5 DIO 5 DO 5 DIO 13 DI 6 DIO 6 DO 6 DIO 14 DI 7 DIO 7 DO 7 DIO 15 DI COM DIO_GND DIO_GND DIO_GND DIO_GND External VDC ©Vecow ECX-1200/1100 User Manual Appendix A...
  • Page 115 DIO Connector (NPN, Default) 6-48V DC DIO_VDC (Pin 20) DO (Pin 11-18) DIO_GND (Pin 10, 19) Source Mode Device DIO Connector (PNP) 6-48V DC DIO_VDC (Pin 20) DO (Pin 11-18) DIO_GND (Pin 10, 19) ©Vecow ECX-1200/1100 User Manual Appendix A...
  • Page 116 Sample folder include sample program, driver library, and API library. Source folder include sample program source code that compile on Visual Studio 2008. A.4 Sample Sample folder include x32 and x64 versions, as shown below : ©Vecow ECX-1200/1100 User Manual Appendix A...
  • Page 117 User setting, DO/DIO output state by hexadecimal bitmask - on/off. Use for Write button activate. DO/DIO writable text : User setting, DO/DIO writable of DIO configuration by hexadecimal bitmask - yes/no. Use for Read (DIO)/Write button activate. ©Vecow ECX-1200/1100 User Manual Appendix A...
  • Page 118 Set POE configuration to get POE state. Write button : Set POE configuration to set POE state. POE output text : User setting, POE output state by hexadecimal bitmask - on/off. Use for Write button activate. ©Vecow ECX-1200/1100 User Manual Appendix A...
  • Page 119 User setting, POE port writable of POE configuration. Use for Write button activate. POE port mode check button (port 4 ~ port 1) : User setting, POE port mode of POE configuration. Use for Write button activate. ©Vecow ECX-1200/1100 User Manual Appendix A...

  • Page 120: Appendix B : Software Functions

    Mask ([15:0]) : In/Out, pin setting by hexadecimal bitmask 1 : Output; 0 : Input Return : TRUE (1) : Success; FALSE (0) : Fail (Initial error, or call by pointer error, or hardware problem) ©Vecow ECX-1200/1100 User Manual Appendix B...
  • Page 121 Set isolated DIO output (DO) DO ([7:0]) : Output state, pin setting by hexadecimal bitmask 1 : High; 0 : Low Return : TRUE (1) : Success; FALSE (0) : Fail (Initial error, or hardware problem) ©Vecow ECX-1200/1100 User Manual Appendix B...
  • Page 122 FALSE (0) : Fail (Initial error, or hardware problem) BOOL GetPOEConfig (BYTE *Auto, BYTE *Mask) Get POE configuration (by variable) Auto ([3:0]) : Auto mode, pin setting by hexadecimal bitmask 1 : Auto; 0 : Manual ©Vecow ECX-1200/1100 User Manual Appendix B...
  • Page 123 POE ([3:0]) : POE state, pin setting by hexadecimal bitmask 1 : On; 0 : Off Return : TRUE (1) : Success; FALSE (0) : Fail (Initial error, or out of range error, or hardware problem) ©Vecow ECX-1200/1100 User Manual Appendix B...

  • Page 124: Appendix C : Raid Functions

    1. Please select SATA device to RAID mode on BIOS menu. Advanced → SATA Configuration → SATA Mode Selection → RAID (Skylake platform)/Intel RST Premium (Kaby Lake/Coffee Lake platform) 2. Please select Software Feature Mask Configuration on BIOS menu. ©Vecow ECX-1200/1100 User Manual Appendix C...
  • Page 125 3. Use RST Legacy OROM → Disabled → Save Changes and Reset. 4. Into BIOS menu again, select Intel(R) Rapid Storage Technology on BIOS menu. 5. Select Create RAID Volume on BIOS menu. ©Vecow ECX-1200/1100 User Manual Appendix C...
  • Page 126 You can get the software from driver CD. Also, you can find the latest information and software directly from Intel's website. http://www.intel.com/p/en_US/support/highlights/chpsts/imsm The RAID environment has been done if you completed the steps above. ©Vecow ECX-1200/1100 User Manual Appendix C...
  • Page 127 "RAID 1". C.7 Disk Management : Partition the Disk After RAID 1 volume is created, you can see the figure of SATA device allocation. You will find "Volume_0000" in SATA device at BIOS menu. ©Vecow ECX-1200/1100 User Manual Appendix C...
  • Page 128 Then add "Logical Device" for Windows access. C.8 If One SATA HDD on RAID Volume is Out-of-use After RAID 1 volume is created, you can see the figure of SATA device allocation. HDD CAUTION Sign ©Vecow ECX-1200/1100 User Manual Appendix C...
  • Page 129 A warning will pop-up to ask you if the disk is not a member of the original RAID volume. If you press "Rebuild", it will replace the broken SATA HDD to the last SATA HDD of RAID volume. ©Vecow ECX-1200/1100 User Manual Appendix C...

  • Page 130: Appendix D : Power Consumption

    Transcend SATA SSD420 128GB SATA 1 Seagate HDD 500GB LAN 1 (i219) 1.0Gbps LAN 2 (i210) 1.0Gbps Graphics output Power plan Balance (Windows10 Power plan) Power Source Chroma 62006P-100-25 Test Program-1 BurnInTest Test Program-2 FurMark ©Vecow ECX-1200/1100 User Manual Appendix D...
  • Page 131 Current Consumption Current Consumption Core™ 7.121A 42.73W 9.143A 54.86W i7-8700T Core™ 4.788A 43.10W 6.594A 59.35W i7-8700T Core™ 3.774A 45.29W 4.345A 52.13W i7-8700T Core™ 2.071A 49.71W 2.782A 66.77W i7-8700T Core™ 1.435A 51.65W 1.658A 59.67W i7-8700T ©Vecow ECX-1200/1100 User Manual Appendix D...
  • Page 132 Current Consumption Current Consumption Core™ 9.537A 57.22W 12.126A 72.76W i7-8700 Core™ 6.364A 57.28W 8.232A 74.08W i7-8700 Core™ 4.794A 57.53W 6.097A 73.16W i7-8700 Core™ 2.629A 63.10W 3.218A 77.23W i7-8700 Core™ 1.885A 67.86W 2.431A 87.53W i7-8700 ©Vecow ECX-1200/1100 User Manual Appendix D...
  • Page 133 ® 12.925A 77.55W 15.803A 94.82W E-2176G ® Xeon 8.721A 78.49W 9.501A 85.50W E-2176G ® Xeon 6.005A 72.05W 8.597A 103.16W E-2176G ® Xeon 3.346A 80.31W 4.111A 98.66W E-2176G ® Xeon 2.281A 82.11W 2.653A 95.50W E-2176G ©Vecow ECX-1200/1100 User Manual Appendix D...
  • Page 134 Power on and boot to Win10 (64-bit) Run 100% CPU Run 100% CPU Power usage with 2D usage with FurMark Input Current Consumption Current Consumption Core™ 3.113A 74.70W 9.035A 216.85W i7-8700 Core™ 2.197A 79.08W 5.879A 211.66W i7-8700 ©Vecow ECX-1200/1100 User Manual Appendix D...

  • Page 135: Appendix E : Supported Memory & Storage List

    Innodisk 8G DDR4 2666 W/T SODIMM M4S0-8GS1N5IK-H03 25ºC 25ºC Innodisk 8G DDR4 2666 W/T SODIMM M4S0-8GSSOCIK-H03 25ºC 25ºC Innodisk 4G DDR4 2666 W/T SODIMM M4S0-4GSSN5IK-H03 25ºC 25ºC Innodisk 4G DDR4 2666 W/T SODIMM M4S0-4GSSNCIK-H03 25ºC ©Vecow ECX-1200/1100 User Manual Appendix E...
  • Page 136 SLINK (MBG-JBM) 8G DDR4 2666 J48GSH1G8QHEC 25ºC 25ºC MEMXPRO 16G DDR4 2666-19 D4SAGHLQHFI 25ºC 25ºC MEMXPRO 16G DDR4 2666-19 D4SAGHLQHFC-AH 25ºC 25ºC MEMXPRO 8G DDR4 2666-19 D4S8GHLQHEC-AH 25ºC 25ºC MEMXPRO 8G DDR4 2666-19 D4S8GHLQHEI 25ºC ©Vecow ECX-1200/1100 User Manual Appendix E...
  • Page 137 SLINK (MBG-JBM) 8G DDR4 2666 J48GDH1G8QHJC 25ºC 25ºC MEMXPRO 16G DDR4 2466-19 D4DAGHLQHKC-AH 25ºC 25ºC MEMXPRO 16G DDR4 2466-19 D4DAGHLQHKI-AH 25ºC 25ºC MEMXPRO 8G DDR4 2666-19 D4D8GHLQHJI-AH 25ºC 25ºC MEMXPRO 8G DDR4 2666-19 D4D8GHLQHJC-AH 25ºC ©Vecow ECX-1200/1100 User Manual Appendix E...
  • Page 138 128GB ADATA ISSS332-256GM 256GB SATA HDD Seagate SDC001 500GB Transcend TS128GCFX600 128GB CFast Innodisk 3ME4 DECFA-A28M41BC1DC-H03 128GB M.2 Key M Toshiba KXG50ZNV512G 512GB ** If more help is needed, please contact Vecow Technical Support.** ©Vecow ECX-1200/1100 User Manual Appendix E...
  • Page 139 No part of this publication may be reproduced in any form or by any means, electric, photocopying, or recording, without prior authorization from the publisher. The rights of all the brand names, product names, and trademarks belong to their respective owners. © Vecow Co., Ltd. 2019. All rights reserved.

This manual is also suitable for:

Ecx-1200 seriesEcx-1100 seriesEcx-1210Ecx-1201Ecx-1201mEcx-1110 ... Show all

Table of Contents
