Declaration of conformity
QUANTUM DESIGNS(HK) LTD.
5/F Somerset House, TaiKoo Place 979 Kings Road,
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EM C Directive)
þ
EN 55022
Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
þ
EN 50081-1
Generic emission standard Part 1:
Residential, commerci a l and light industry
þ
EN 50082-1
Generic immunity standard Part 1:
Residential, commerci a l and light industry
European Representative:
QDI COMPUTER ( UK ) LTD
QDI SYSTEM HANDEL GMBH
QDI COMPUTER (FRANCE) SARL
QDI COMPUTER (ESP ANA) S.A.
Signature :
Anders Cheung
Printed Name :
Quarry Bay, Hong Kong
declares that the product
Mainboard
KinetiZ 7A
is in conformity with
QDI COMPUTER ( SCANDINAVIA ) A/S
QDI COMPUTER ( NETHERLANDS) B. V.
QDI COMPUTER HANDELS GMBH
QDI COMPUTER (SWEDEN) AB
Place / Date :
Position/ Title :
HONG KONG/2000
President
Advertisement
Table of Contents
Related Manuals for QDI KinetiZ 7A
Summary of Contents for QDI KinetiZ 7A
- Page 1 EN 50082-1 Generic immunity standard Part 1: Residential, commerci a l and light industry European Representative: QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S QDI SYSTEM HANDEL GMBH QDI COMPUTER ( NETHERLANDS) B. V. QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH QDI COMPUTER (ESP ANA) S.A.
- Page 2 Declaration of conformity Trade Name: QDI Computer ( U. S . A. ) Inc. M odel Name: KinetiZ 7A Responsible Party: QDI Computer ( U. S. A.) Inc. Address: 41456 Christy Street Fremont, CA 94538 Telephone: (510) 668-4933 Facsimile: (510) 668-4966...
-
Page 3: Table Of Contents
C O N T E N T S Facilité de vitesse Initialisation(Francais) ..........1 1. Introduction ............. Over view ....................3 Key Features ..................3 Introduction to New Features ..............5 2. Installation Instructions ..........External Connectors ................. 7 PS/2 Keyboard & PS/2 Mouse Connector ..........7 USB1 &... - Page 4 PnP/PCI Configurations Setup ..............30 PC Health Status ..................31 Frequency/Voltage Control ............... 32 Set Supervisor/User Password ..............33 Boot with BIOS defaults ................33 Appendix A QDI Driver CD 2000 ..........35 Appendix B ..........Boot Logo RecoveryEasy ............... 39 Introduction ....................39 Operation Process ..................
-
Page 5: Facilité De Vitesse Initialisation(Francais)
KinetiZ 7A Installation de la carte mè re KinetiZ 7A Assurez-vous que votre ensemble est complet: carte mère, c âbles IDE et FLOPPY, notice d’util i sati o n et CD-ROM d’installati o n. Vérifiez que l’alimentation est débranchée et reliez-vous à la terre par une courroie à... - Page 6 Il faut presser les touches Ctrl + Bksp et F12 pour entrer dans les interfaces «Recovery» et «Partition» durant l e démarrage du Bios. ATTENTION : lisez attenti v ement le manuel du RecoveryEasy traduit sur le CD-ROM QDI avant d’installer cette fonction.
-
Page 7: Introduction
Chapter 1 Introduction Introduction Overview The KinetiZ 7A green mainboard utilizes the VIA Apollo KX-133 chipset, providing a cost- effective PC/ATX platform with perfect capabi l ity and high performance to support AMD Slot ® ® A Athlon proces sors. The VIA... - Page 8 Supports ACPI (Advanced Configurati o n and Power Interface) and ODPM (OS Directed Power Management). Supports three green modes: Doze, Standby and Suspend. Supports ACPI power status: S0, S1, S3(STR), S5(Soft-off). Expansion slots 1 ISA slot, 5 PCI slots, 1 AGP and 1 AMR. Manual for KinetiZ 7A...
-
Page 9: Introduction To New Features
The operating system must be capable of DMA transfers. Win95 (OSR2), Win98 and WindowsNT are capable. An Ultra ATA/66 capable, 40-pin, 80-conductor cable is required. Ultra ATA/66 compatible IDE device such as a hard driv e or CD-ROM drive. Manual for KinetiZ 7A... - Page 10 The s ame ways used to power up the system can be used to wake up the system from Suspend-to-RAM s tatus. For example, pushing the power button, through the Wake-on- LAN, Wake-on-Modem function or RTC Alarm. Manual for KinetiZ 7A...
-
Page 11: Installation Instructions
Two USB ports are available for connecting USB devices. USB3, USB4 Two USB ports are not available on the back panel. Therefore, we provide a 10-pin ribbon cable with bracket to connect Built-i n on-board USB header. ( manufacturing option) Manual for KinetiZ 7A... -
Page 12: Parallel Port Connector And Serial Port Connector
Note: * If you change “soft-off by PWR-BTTN” from default “ Instant-off” to “ Delay 4 Secs” in the “ POWER MANAGEMENT SETUP” section of the BIOS, the pow er button should be pressed for m ore than 4 seconds before the system pow ers dow n. Manual for KinetiZ 7A... -
Page 13: Hard Disk Led Connector (Hd Led)
LED is off. When the system is in suspend to RAM status, the LED is on. Hardware Green Connector (SLEEP) Push once the switch connected to this header, the system enters suspend mode. Manual for KinetiZ 7A... -
Page 14: Fan Connector (Cpufan, Chsfan)
LAN adapter, set “Wake Up On LAN/Ring” as Enabl e d in the “POWER MANAGEMENT SETUP” section of the BIOS. Save & exit, then boot the operating sys tem once to make sure this function takes effect. Manual for KinetiZ 7A... -
Page 15: Wake-Up On Internal Modem (Wom)
It als o allows the sharing of mono_in (s uch as a phone) and mono_out (such as a speaker) between the onboard audio and the voice modem card. Manual for KinetiZ 7A... -
Page 16: Audio/Modem Riser Interface Connector(Amr)
Riser, or no audio with modem on the Riser. KinetiZ 7A mainboar d provides you with audio onboard solution, onboard audio can be enabled/disabled. Either AMR (Audio/Modem Riser) card or MR (Modem Riser) card can be used on this system. -
Page 17: Expansion Slots & I/O Ports Description
Warning: If you set J13 with pin2&pin3 closed and set “ACPI Suspend Type” to S3 in “Power Management Setup” secti o n of the BIOS, the blank screen w ill come out, in this case, just clear CMOS and boot up the system once again. Manual for KinetiZ 7A... -
Page 18: Bios-Protecteasy Jumper(Jav)
Clear CMOS (JCC) If you want to clear CMOS, unplug the AC power supply first, close JCC (pin1 & pin2) once, set JCC back to the normal status with pin2 & pin3 connected, then power on the system. Manual for KinetiZ 7A... -
Page 19: Overclocking Jumper Setting (Jfsb)
Enable/Disable on-board audio(JSD) If you want to use the on-board audio, set JSD with pin2 & pin3 closed (default). Otherwise, s et JSD with pin1 & pin2 closed for disabling this function. Enable on-board audio: Disable on-board audio: Manual for KinetiZ 7A... - Page 20 Installation Instruction -- This page is intentionally left blank -- Manual for KinetiZ 7A...
-
Page 21: Bios Description
1. Create a bootable system floppy diskette by typing F ormat A:/s from the DOS prompt under DOS6.xx or Windows 9x environment. 2. Click “Browse CD” option under QDI Driver CD 2000, copy Awdflash.exe (version>7.36) from the directory \Utility onto your new bootable disk ette. -
Page 22: Award Bios Description
The basic CMOS settings included in “Standard CMOS Features” are Date, Time, Hard Disk Drive Types, Floppy Disk Drive Types, and VGA etc. Use the arrow keys to highlight the item, then use the <PgUp> or <PgDn> keys to select the value desired in each item. Manual for KinetiZ 7A... - Page 23 Enter the information directly from the keyboard and press < Enter>: CYLS number of cylinders HEAD number of heads PRE COMP write pre-c ompensation LANDZ landing zone SECTOR number of sectors MODE HDD access mode Manual for KinetiZ 7A...
- Page 24 To support LBA or LARGE mode of HDDs, there must be some softwares involved which are located in Award HDD Service Routine(INT13h).It may fail to access a HDD with LBA (LARGE) mode selected if you are running under an Operating System whi c h replaces the whole INT 13h. Manual for KinetiZ 7A...
- Page 25 The POST of the BIOS will determine the amount of base (or conventional) memory installed in the system. Extended Memory The BIOS determines how much extended memory is presented during the POST. Total Memory Total memory of the system equals the sum of the above memory. Manual for KinetiZ 7A...
