  • Page 1 ® PENTIUM P5I430TX TITANIUM IB+...
  • Page 2 Notice The information in this document is subject to change in order to improve reliability, design, or function without prior notice and does not represent a commitment on the part of this company. In no event will we be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or the possibility of such damages.
  • Page 3 EN 50082-1 Genetic immunity standard Part 1: Residual, commercial and light industry European Representative: QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S QDI SYSTEM HANDEL GMBH QDI COMPUTER ( NETHERLANDS) B. V. QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH QDI COMPUTER (ESPANA) S.A.
  • Page 4 Trade Name: QDI Computer ( U. S . A. ) Inc. Model Name: P5I430TX TITANIUM IB+ Responsible Party: QDI Computer ( U. S. A.) Inc. Address: 41456 Christy Street Fremont, CA 94538 Telephone: (510) 668-4933 Facsimile: (510) 668-4966 Equipment Classification:...

  • Page 5: Table Of Contents

    CONTENTS SpeedEasy Quick Setup(English)---------------------------------------- 1 SpeadEasy Schnell-Installation(Deutsch)------------------------------ 3 Fácil Y Veloz Rápida Instalación(Español)---------------------------- 5 Facilité de vitesse Initialisation(Francais)----------------------------- 7 Setup Della Scheda Speedeasy(Italiano) ------------------------------- 9 SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎÄ·±Ìå ) ---------------------------------- 11 SpeedEasy¿ìËÙ°²×°Ö¸ÄÏ(ÖÐÎļòÌå ) --------------------------------- 13 1. Introduction............1-1 1.1 Overview..............1-1 1.2 Key Features..............1-1 2.
  • Page 6 CONTENTS 2.15 PS2 Mouse ..............2-4 2.16 Sleep LED ..............2-4 2.17 I/O Port Description ..........2-5 2.18 Clear CMOS ..............2-5 2.19 Memory Configuration ..........2-5 3. AWARD BIOS Description........3-1 3.1 Entering BIOS Setup............3-1 3.2 Standard CMOS Setup ..........3-2 3.3 SpeedEasy CPU Setup..........3-4 3.4 BIOS Features Setup...........3-5 3.5 Chipset Features Setup ..........3-7 3.6 Power Management Setup...........3-9...

  • Page 7: Speedeasy Quick Setup(English)

    P5I430TX Titanium IB+ SpeedEasy Quick Setup Procedures : Correctly insert the CPU. Plug in other configurations and restore the system. Press <Del> key and power on the system to enter BIOS Setup. Enter “SpeedEasy CPU Setup” menu to set up CPU speed. Note: If CPU speed is not set, your system will run at the default setting (75MH for Pentium and AMD CPU, 100MH...
  • Page 8 SpeedEasy CPU Setup Menu Select the <SpeedEasy CPU Setup> item from the main menu and enter the sub-menu: ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right.
  • Page 9 P5I430TX Titanium IB+ Schneller Überblick über die Einstellungen: Vorgehensweise: 1. Setzen Sie die CPU richtig ein. 2. Stecken Sie weitere Komponenten ein und vervollständigen Sie das System. 3. Drücken < DEL > oder < ENTF > und schalten Sie das System ein, um in das BIOS-Setup zu gelangen.
  • Page 10 Wählen Sie das Menü < SpeedEasy CPU Setup > aus und gehen Sie in das folgende Untermenü: ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right.
  • Page 11 P5I430TX Titanium IB+ Setup Rápido Procedimiento: 1. Insertar la CPU correctamente. 2. Insertar otros dispositivos en el sistema. 3. Presionar la tecla <Del> y arrancar el sistema para entrar en BIOS setup. 4. Seleccionar el menu “SpeedEasy CPU setup” para seleccionar la velocidad de la CPU.
  • Page 12 Configuración de la CPU en el menu SpeedEasy Seleccione <SpeedEasy CPU setup> en el menu principal para entrar en el siguiente menu: ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right.
  • Page 13 P5I430TX Titanium IB+ Mise en marche rapide Démarche à suivre: 1) Insérer correctement le Processeur. 2) Assembler les autres éléments et mettez le système en place. 3) Appuyer sur la touche <Del> (Efface) et mettre le système en marche afin d’accéder à la configuration du BIOS. 4) Accédez au menu “SpeedEasy CPU Setup “...
  • Page 14 Menu de configuration de processeur de SpeedEasy Sélectionnez <SpeedEasy CPU Setup> du menu principal et accédez au sous- menu comme suit : ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right.
  • Page 15 P5I430TX Titanium IB+ Setup Rapido Procedure: Inserire la CPU correttamente. Inserire gli altri componenti e ricomporre il systema. Premere il tasto <Del> e accendere il sistema per entrare nel setup del Bios. Entrare nel menu “SpeedEasy CPU Setup” per impostare la velocita` della CPU.
  • Page 16 CPU manualmente, alla voce “CPU Speed” del menu “SpeedEasy CPU Setup”. Attenzione: QDI declina ogni responsabilita` per eventuali danni causati alla CPU da una impostazione della velocita` piu` alta di quanto indicato dal produttore della CPU stessa .
  • Page 17 P5I430TX Titanium IB+ ¿ìËÙÉèÖõIJ½Öè ¡¢ÕýÈ·°²×° ¡£ ¡¢°²×°ºÃϵͳ ×¼±¸¿ª»ú¡£ ¡¢°´Ï ¼ü±£³Ö²»¶¯£¬ È»áῪ»ú½øÈë ÉèÖóÌÐò¡£ <Del> BIOS ¡¢½øÈë “ ” Ŀ¼ÉèÖà Ëٶȡ£ SpeedEasy CPU Setup ×¢Ò⣺ Èç¹ûÓû§²»ÉèÖà Ëٶȣ¬ Ôòϵͳ»á ÓÃÔ-É趨ֵÔËÐÐ ±¼ÌÚºÍ »áÓà (Intel AMD K5 CPU 75HMz ÔËÐУ¬ »áÓà ÏÂÔËÐÐ ¡£ Cyrix 6x86 CPU 100MHz ¡¢±£´æ¼°Í˳ö...
  • Page 18 ÉèÖóÌÐòÖ÷Ŀ¼ÖÐÑ¡Ôñ Ò»Ï BIOS <SpeedEasy CPU Setup> ½ø ÈëÈçÏÂ×ÓĿ¼£º ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right. CPU over speed CPU Speed...
  • Page 19 P5I430TX Titanium IB+ ¿ìËÙÉèÖõIJ½Öè ¡¢ÕýÈ·°²×° ¡£ ¡¢°²×°ºÃϵͳ ×¼±¸¿ª»ú¡£ ¡¢°´Ï ¼ü±£³Ö²»¶¯£¬ È»ºó¿ª»ú½øÈë ÉèÖóÌÐò¡£ <Del> BIOS ¡¢½øÈë “ ” Ŀ¼ÉèÖà Ëٶȡ£ SpeedEasy CPU Setup ×¢Ò⣺ Èç¹ûÓû§²»ÉèÖà Ëٶȣ¬Ôòϵͳ»á ÓÃÔ-É趨ֵÔËÐÐ ±¼ÌÚºÍ »á Óà (Intel AMD K5 CPU 75HMz ÔËÐУ¬ »á Óà ÏÂÔËÐÐ ¡£ Cyrix 6x86 CPU 100MHz ¡¢±£´æ²¢Í˳ö...
  • Page 20 ÉèÖóÌÐòÖ÷Ŀ¼ÖÐÑ¡Ôñ Ò»Ï BIOS <SpeedEasy CPU Setup> ½ø ÈëÈçÏÂ×ÓĿ¼£º ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology CPU Model : Intel Pentium MMX Warning: Be sure your selection Speed Mode : SpeedEasy is right. CPU over speed CPU Speed...

  • Page 21: Introduction

    Chapter 1 Chapter 1 Introduction 1.1 Overview P5I430TX TITANIUM IB+ green mainboard provides a highly integrated solution for fully compatible, high performance PC/ATX platforms, supporting ® Intel Pentium , Cyrix 6x86, 6x86MX and AMD K5, K6 microprocessors. It features Write-Back Secondary Cache memory for 256KB/512KB in size. Flexible main memory size can be installed from 8MB up to 256MB DRAMs, so as to provide full play to the advantages of the Pentium , Cyrix 6x86, 6x86MX and AMD K5, K6 CPUs.
  • Page 22 Introduction - Supports from 8MB to 64MB 3.3V unbuffered SDRAM DIMM or 3.3V unbuffered EDO DIMM for DIMM slot. - Provides 256KB/512KB L2 Pipelined Burst Cache on Cache Memory board. - Provides 2 kinds of cache chips for users: 256KB/512KB cache on board. - Supports 2 PCI Bus Master (Bus Master works as On-board IDE DMA Mode 2 type) IDE ports.
  • Page 23 Chapter 1 (requires ATX through a modem (internal modem card or external modem), so that any user can access vital information power supply from their computer from anywhere in the word. - 3 x ISA Slots and 4 x PCI Slots. On-board I/O - Uses NS Plug &...
  • Page 24 Introduction -- This page is intentionally left blank --...

  • Page 25: Connector Configuration

    Chapter 2 Chapter 2 Connector Configuration This section lists all connector pin assignments and port description on the mainboard. The situations of the connectors and ports are illustrated in the following figures. Before inserting these connectors, please pay attention to the directions. 2.1 Power Connector (J3) PIN NUMBER FUNCTION...

  • Page 26: Keyboard Connector

    Connector Configuration If a standby Power supply or an ATX Power supply is used, the Power Switch supports the function as illustrated in the figures below. 1. When powering up your system, turn on the mechanical switch of the Standby Power supply first, then push once the button connected to Power Switch connector.

  • Page 27: Turbo Led Connector

    Chapter 2 IRRX IRTX 2.10 Turbo LED Connector (JP13) PIN NUMBER FUNCTION 2.11 Reset Switch (JP10) SETTING FUNCTION CLOSE ONCE RESET THE SYSTEM OPEN NORMAL 2.12 USB1/USB2 Connector (USB1/USB2) PIN NUMBER FUNCTION DATA - DATA + PWR-SW (JP20) P-LED (JP9) RESET (JP10) 2.13 FAN Connector (JP7) HD LED (JP12)

  • Page 28: Hardware Green

    Connector Configuration 2.14 Hardware SMI (JP8) PIN NUMBER FUNCTION Close HARDWARE GREEN (Close once) Open NORMAL 2.15 PS2 Mouse (JP1) PIN NUMBER FUNCTION DATA CLOCK 2.16 Sleep LED (JP21) PIN NUMBER FUNCTION Note: If you choose to use PS/2 Mouse, please contact your vendor for optional PS/2 Mouse cable.

  • Page 29: Clear Cmos

    Chapter 2 COM1/COM2/COM3/COM4 COM2/COM3/COM4/COM1 2.18 Clear CMOS ¸ *Normal CLEAR CMOS NORMAL Close once Open Clear CMOS “*”: Represents default jumper settings. 2.19 Memory Configuration The P5I430TX Titanium IB+ mainboard provides 4 SIMM slots and 2 DIMM slots for providing flexible memory size from 8MB up to 256MB main memory.
  • Page 30 Connector Configuration If using DIMM or SIMM only, you can install the DIMM and SIMM as shown in the following table. Total Memory SIMM1&2 SIMM3&4 DIMM1 DIMM2 4MB x 2 ---- ---- ---- ---- ---- ---- 16MB 8MB x 2 ---- ---- ----...
  • Page 31 Chapter 2 --This page is intentionally left blank -- Figure 2-1 Illustration of All Connectors on Board 2 - 7...
  • Page 32 Connector Configuration...

  • Page 33: Award Bios Description

    Chapter 3 Chapter 3 AWARD BIOS Description 3.1 Entering BIOS Setup Power on the computer, when the following message appears briefly at the bottom of the screen during the POST (Power On Self Test), press the <Del> key or simultaneously press the <Ctrl> + <Alt> + <Esc> keys. Press <Del>...
  • Page 34 AWARD BIOS Description Use the arrow keys to highlight the item, then use the < PgUp> or <PgDn> keys to select the value you want in each item. ROM PCI/ISA BIOS (2A59IQ1G) CMOS SETUP UTILITY AWARD SOFTWARE, INC. Date (mm:dd:yy) : Thu, Jul 17 1997 Time (hh:mm:ss) : 00:00:00...

  • Page 35: Speedeasy Cpu Setup

    Most use for this area is Shadow RAM. Total Memory Total memory of the system is the sum of the above memory. 3.3 SpeedEasy CPU Setup ROM PCI/ISA BIOS (2A59IQ1G) SPEEDEASY CPU SETUP QDI Innovative Technology 3 - 3...
  • Page 36 AWARD BIOS Description Warning: System may hang or CPU may be damaged if you wrongly set CPU Model : Intel Pentium MMX CPU voltage. It is strongly recommended not to change “Auto” to Speed Mode : SpeedEasy Warning : Be sure your selection “Manual”.

  • Page 37: Bios Features Setup

    Chapter 3 3.4 BIOS Features Setup ROM PCI/ISA BIOS (2A59IQ1G) BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Disabled Video BIOS Shadow : Enabled C8000 ~ CBFFF Shadow : Disabled CPU Internal Cache : Enabled CC000 ~ CFFFF Shadow : Disabled External Cache : Enabled D0000 ~ D3FFF Shadow : Disabled...
  • Page 38 AWARD BIOS Description C, CDROM,A • Swap Floppy Exchanges the assignment of A&B floppy Enabled drives. Drive The assignment of A&B floppy drives are Disabled normal. • Boot Up Floppy BIOS searches for floppy disk drive to determine Enabled if the drive is ready for diskette read/write Seek during booting.

  • Page 39: Chipset Features Setup

    Chapter 3 • C8000 Enabled Optional ROM will be copied to RAM by 16K CBFFF bytes per unit. Shadow ... DC000~DFFFF The shadow function is disabled. Shadow: Disabled • Delay For HDD 0 ~ 15 Sets the predelay time for hard disk to be ready for accessing the system.

  • Page 40: Power Management Setup

    AWARD BIOS Description configurations. Timing ... Fast MA to RAS# Delay • System BIOS Other than conventional memory, the Enabled system BIOS area is also cacheable. Cacheable Disabled The system BIOS area is not cacheable. • Video BIOS Besides conventional memory, video BIOS Enabled area is also cacheable.
  • Page 41 Chapter 3 Throttle Duty Cycle : 62.5% Thermal Duty Cycle : Disabled VGA Active Monitor : Disabled CPU Warning Temperature : Auto Soft-Off by PWR-BTTN : Instant-Off Resume by Ring : Disabled ↑↓→← : Select Item Resume by Alarm : Disabled ESC: Quit F1 : Help PU/PD/+/- : Modify...
  • Page 42 AWARD BIOS Description Suspend mode. If any item defined in “Wake Up Events In Suspend” is On and activated, the system will be waken up. • HDD Power HDD’s motor will not be off. Disabled 1 ∼15 Min Defines the continuous HDD idle time before the HDD Down enters power saving mode (motor off).

  • Page 43: Pnp/Pci Configuration Setup

    Chapter 3 “*”: These features require an ATX Power Supply, effect will not be taken until BIOS completes system configuration prior to starting the Operating System. 3.7 PNP/PCI Configuration Setup ROM PCI/ISA BIOS (2A59IQ1G) PNP/PCI CONFIGURATION SETUP AWARD SOFTWARE, INC PNP OS Installed : No PCI IDE IRQ Map To...

  • Page 44: Load Setup Defaults

    AWARD BIOS Description Disabled Disable forces updating ESCD function. • IRQ-3 ∼ IRQ-15 The specified IRQ-x will be assigned Legacy ISA to ISA only. assigned to PCI/ISA PnP The specified IRQ-x will be assigned to ISA or PCI. • DMA-0 ∼ DMA-7 The specified DMA-x will be assigned Legacy ISA to ISA only.
  • Page 45 Chapter 3 On-Chip Primary PCI IDE : Enabled On-Chip Secondary PCI IDE : Enabled USB Keyboard Support : Disabled Onboard FDC Controller : Enabled ↑↓→← : Select Item Onboard Serial Port 1 : Auto ESC: Quit Onboard Serial Port 2 : Auto F1 : Help PU/PD/+/- : Modify...

  • Page 46: Password Setting

    AWARD BIOS Description 3.10 Password Setting When selecting this function, the following message appears at the center of the screen to assist you in creating a password. ENTER PASSWORD Type the password, up to eight characters, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory.
  • Page 47 Chapter 3 Note: Some OSes (like SCO-UNIX) must use “NORMAL” for installation Figure 3-9 IDE HDD Auto Detection Menu 3.11.1 Setup Changes With auto-detection • BIOS setup will display all possible modes supported by the HDD including NORMAL, LBA and LARGE. •...

  • Page 48: Power-On Boot

    AWARD BIOS Description During HDD accessing, the IDE controller will transform the logical address described by sector, head and cylinder number into its own physical address inside the HDD. The maximum HDD size supported by LBA mode is 8.4 Gegabits. LARGE mode Some IDE HDDs contain more than 1024 cylinder without LBA support (in some cases, users do not want LBA).
  • Page 49 Chapter 3 3 - 17...
  • Page 51 Appendix Appendix A. Appendix A. Utility Diskette Utility Diskette Use this diskette to update your BIOS when necessary. For the updates and additional information regarding BIOS upgrades, please refer to "README" in the "Utility Diskette ". Warning: We strongly recommend you only upgrade BIOS when encountering problems.

  • Page 52: Appendix

    Appendix Appendix B. Appendix B. Introducing AMD-K5 CPU markings: Operating Voltage: B=3.45V~3.60V-->3.5V C=3.30V~3.465V--> 3.3V F=3.135V~3.465V-- > 3.3V G = x/y H=2.86V~3.00V/3.30V~3.465V -- > 2.9/3.3 J=2.57V~2.84V/3.30V~3.465V -- > 2.7/3.3 K=2.38V~2.63V/3.30V~3.465V -- > 2.5/3.3 Processor Name P-Rating 75,90,100,120, 133,150,166 AMD-K5 AMD-K5 PR133 PR133 AMD-K5-PR133ABQ 100MHz...

  • Page 53: Appendix C Introducing Amd-K6 Cpu Markings

    Appendix Appendix C. Appendix C. Introducing AMD-K6 CPU markings: Internal CPU Frequency 166MHz, 200MHz, 233MHz Processor Name AMD-K6 AMD-K6 AMD-K6-PR200 × × × × × × × × 2.9V m c 1996 AMD Center of Core Voltage: 2.9V, 3.2V (For dual voltage) A - 3...

  • Page 54: Appendix D Introducing Cyrix 6X86 Cpu Markings

    Appendix Appendix D. Appendix D. Introducing Cyrix 6x86 CPU markings: Name of the P-Rating processor 90+, 120+, 133+ 6x86, 6x86L 150+, 166+, 200+ CPU Core Frequency 100, 110, 120, 6x86-P133+GP 133, 150MH 110MHz 3.52V (028 ) Center of Core Voltage: 3.3V, 3.52V CPU Voltage: (For single voltage)
  • Page 55 Appendix Introducing Cyrix 6x86MX CPU markings: CPU P-Rating: PR200 Name of processor: 6x86 MX Cyrix ® P R O C E S S O R P R O C E S S O R 6x86 MX-PR200 66MH Bus 2.5X 2.9v CPU Core Frequency: FAN/HEATSINK REQUIRED 66MH...
  • Page 56 P/N: 430-01011-002...
  • Page 57 Appendix Manual TITANIUM IB+ Ver 2. 0 A - 3...
