Overview
The WinneX 3 green mainboard utilizes the Intel first generation integrated graphics chipset
®
— Intel 810 Chipset, providing a fully compatible, high performance and cost-effective PC/
microATX platform. The new integrated technologies, together with the software configurable
AC' 97 audio and modem system give customers an advanced, multimedia solution at an
extremely low price. It provides 66/100 MHz system bus support for all Intel
® TM
Pentium II, and Celeron Slot1 processors. 100MHz SDRAMs are supported up to 512MB.
It also provides advanced features such as Wake-on-LAN, Wake-on-Modem and Keyboard
Password Power-on functions. Suspend to RAM, the optimal implementation of the Ad-
vanced Configuration and Power Interface (ACPI) specification, makes the PC' s power
consumption drop to the lowest possible level and enable quick wakeup. ManageEasy, our
system management application is also supplied to enable remote monitoring and configura-
tion of the system.
Flexibility in Designing Cost-effective System
®
The Intel 810 Chipset is a high-integration chipset which consists of a Graphics and
Memory Controller Hub (GMCH) Host Bridge and an I/O Controller Hub (ICH) Bridge. There
are two versions of the GMCH (GMCH0/GMCH) and two versions of ICH (ICH0/ICH). The
®
Intel 810 Chipset System provides added flexibility in designing cost-effective solutions
by using different combinations of the GMCH and ICH.
The following describes the three kinds of Intel
features. Please identify which kind of mainboard you purchased.
®
1. Intel 810 DC-100: GMCH (Intel
Added features:
• Includes 4MB, 32-bit 100MHz SDRAM Display Cache.
• Supports Ultra ATA/66.
®
2. Intel 810: GMCH0 (Intel
Added features:
• Supports Ultra ATA/66.
®
Intel 810L: GMCH0 (Intel
3.
This is the basic system combination.
All information contained in this manual applies to all three kinds of system, unless
otherwise specified.
®
810 chipset combination and their added
®
82810-DC100) + ICH (Intel
® ®
82810) + ICH (Intel 82801AA)
® ®
82810) + ICH0 (Intel 82801AB)
