Chapter 1
Chapter 1
Introduction
Introduction
Overview
The WinneX 5 green mainboard utilizes Intel' s first generation integrated graphics
chipset — Intel® 810 Whitney Chipset, providing a fully compatible, high performance and
cost-effective PC/ATX platform. The new integrated technologies, together with soft-
ware configurable AC' 97 audio and modem system give customers an advanced,
multimedia solution at an extremely low price. It provides 66MHz and 100 MHz system
bus support for all the Intel® Celeron PPGA 370 Processors. 100MHz SDRAMs are
supported up to 512MB. It also provides advanced features such as Wake-Up On LAN,
Wake-Up On Internal/External Modem and Keyboard Password Power-on functions.
Suspend to RAM, the optimal implementation of the Advanced Configuration and Power
Interface (ACPI) specification, makes the PC' s power consumption drop to the lowest
possible level and enable quick wakeup. ManageEasy, our system management applica-
tion is also supplied to enable remote monitoring and configuration of the system.
Flexibility in Designing Cost-effective System
The Intel® 810 Chipset is a high-integration chipset which consists of a Graphics and
Memory Controller Hub (GMCH) Host Bridge and an I/O Controller Hub (ICH) Bridge.
There are two versions of GMCH (GMCH0/GMCH). The Intel® 810 Chipset System
provides added flexibility in designing cost-effective solutions by using different combi-
nations of GMCH and ICH.
The following describes the two kinds of Intel® 810 chipset combination and their
added features. Please identify which kind of mainboard you purchased.
1.
Intel® 810 DC-100: GMCH (Intel® 82810-DC100) + ICH (Intel® 82801AA)
Added features:
• Includes 4MB, 32-bit 100MHz Display Cache.
• Supports Ultra ATA/66.
2.
Intel® 810: GMCH0 (Intel® 82810) + ICH (Intel® 82801AA)
Added features:
• Supports Ultra ATA/66.
All information contained in this manual applies to both kinds of system, unless otherwise
specified.
Manual for WinneX 5
Chapter 1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WinneX 5 and is the answer not in the manual?

Questions and answers

Summary of Contents for QDI WinneX 5

  • Page 1 Introduction Introduction Overview The WinneX 5 green mainboard utilizes Intel’ s first generation integrated graphics chipset — Intel® 810 Whitney Chipset, providing a fully compatible, high performance and cost-effective PC/ATX platform. The new integrated technologies, together with soft- ware configurable AC’ 97 audio and modem system give customers an advanced, multimedia solution at an extremely low price.
  • Page 2: Key Features

    1.2M/1.44M/2.88M format. Two high speed 16550 compatible UART (COM1/COM2/COM3/COM4 selective) with 16-byte send/receive FIFOs. USB host interface supporting 2 USB ports. One joystick port. Infrared interface. All I/O ports can be enabled/disabled in the BIOS setup. Manual for WinneX 5...
  • Page 3 Provides onboard 3.3V regulator to support ATX power supply without 3.3V output. System status resumes after AC power failure. Supports QDI’ s innovation such as SpeedEasy, InstallEasy, SecurityEasy and RecoveryEasy. Protects the system BIOS from being attacked by severe virus such as CIH.
  • Page 4: Introduction To New Features

    To implement this function, the following requirments are essential: Power supply requirements: The current of 5VSB line of the power supply should be more than 0.75A. Manual for WinneX 5...
  • Page 5 This cable adds 40 additional ground lines between each of the original 40 ground and signal lines. The additional 40 lines help shield the signal from EMI, reduce crosstalk and improve signal integrity. Manual for WinneX 5...
  • Page 6 3. The operating system must be capable of DMA transfers. W in95 (OSR2) and W in98 are capable. 4. A capable Ultra ATA/66 , 40-pin, 80-conductor cable is required. 5. Ultra ATA/66 compatible IDE device such as a hard drive or CD-ROM drive. Manual for WinneX 5...
  • Page 7: Installation Instructions

    You can enable/disable them and choose the IRQ or I/O address in “ Integrated Peripherals” from AWARD BIOS SETUP. Parallel Port UART1 Manual for WinneX 5...
  • Page 8: Midi/Joystick Connector

    When powering off the system, you needn’ t turn off the mechanical switch, just Push once the power switch. ATX Power Supply Connector 5VSB PS-OK PSON -12V 3.3V 3.3V 3.3V POWER Manual for WinneX 5...
  • Page 9: Reset Switch (Reset)

    RAM status), the LED will flash. The connector has an orientation. Hardware Green Connector (SLEEP) If the operating system or the BIOS does not enable ACPI, push once the switch con- nected to this header, the system enters APM suspend mode. Manual for WinneX 5...
  • Page 10: Infrared Header (Irda)

    The fan speed of these three fans can be detected and viewed in “ PC Health” section of the BIOS. These three fans will be automatically turned off after the system enters suspend mode. +12V FAN GND SENSE POWFAN CPUFAN FAN GND +12V SENSE SENSE FAN GND +12V CHSFAN Manual for WinneX 5...
  • Page 11 Signal for waking up (active low) Digital Audio Connector (CDLIN1) CDLIN1 is a Sony standard CD audio connector, it can be connected to a CD-ROM drive through a CD audio cable. CDLIN1 CD Right Channel CD Left Channel Manual for WinneX 5...
  • Page 12 If the connector has been closed once, the system will record the status and indicate the chassis has been opened. You can receive this information from QDI ManageEasy software. Indicate signal...
  • Page 13: Jumper Settings

    Riser, audio on the mainboard and modem on the Riser, or no audio with modem on the Riser. WinneX 5 mainboard provides you with audio onboard solution, onboard audio can be enabled/disabled. Either AMR (Audio/Modem Riser) card or MR (Modem Riser) card can be used on this system.
  • Page 14 Enable keyboard password power-on function (JKB) The mainboard provides the advanced keyboard password power-on function. Before using this function, set JKB with pin1 & pin2 closed. Otherwise, set JKB with pin2 & pin3 closed for disabling. Disable: Enable: Manual for WinneX 5...
  • Page 15 Refer to the chart below for the location of these jumpers, and the table for information on how to set them. JFS1 JFS0 CPU FSB 66MHz 100MHz 133MHz AUTO JFS0 OPEN OPEN JFS1 OPEN ‘ 1-2’ represents pin1 & pin2 closed. ‘ 2-3’ represents pin2 & pin3 closed. Manual for WinneX 5...
  • Page 16 “ Un- known Flash Type” will be displayed on the screen, and DMI information update will fail while updating DMI. Refer to page 4 for the two choices to implement FW H Protection function. Manual for WinneX 5...
  • Page 17: Installation Of All Drivers

    2 Installation of All Drivers A QDI Mainboard Utility CD-ROM is supplied with each mainboard. All drivers can be installed from this CD-ROM. Before installing all the drivers, check system requirements such as system memory (at least 32MB for Windows 95/98 system or 64MB for Win- dows 2000 system) and disk space.
  • Page 18 QDI ManageEasy also helps you to use remote access and control computers in your local area network. With QDI ManageEasy, you can improve your management level.
  • Page 19: Bios Description

    A:\>AW DFLASH /? Note: AWDFLASH.EXE (version>7.07) utility must be used to upgrade the WinneX 5 mainboard BIOS instead of QDI flash utility. QDI flash utility — - FLASH.EXE (V1.3) does not support the flash memory on WinneX 5 mainboard.
  • Page 20: Load Optimized Defaults

    The basic CMOS settings included in “ Standard CMOS Features” are Date, Time, Hard Disk Drive Types, Floppy Disk Drive Types, and VGA etc. Use the arrow keys to highlight the item, then use the <PgUp> or <PgDn> keys to select the value desired in each item. Manual for WinneX 5...
