    DOUGH ROLLER CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWINGS Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    DOUGH ROLLER GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    DOUGH ROLLER PRODUCT DESCRIPTION *Professional Dough Roller ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.HA.01 530x550x650 550x500x800 EMP.HA.02 430x550x650 560x520x770 EMP.HA.01.Y 530x550x650 600x550x770 EMP.HA.02.Y 430x550x650 560x600x770 EMP.HA.03...

  • Page 4: A3 Transportation

    DOUGH ROLLER TRANSPORTATION *This appliance can be moved by hand from area to area.Do not crash and drop the appliance while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    DOUGH ROLLER SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials.  *Do not operate the appliance when the machine is empty. *Do not load so less or more than appliance’s capacity.

  • Page 6: Doperation

    DOUGH ROLLER OPERATION *Control Panel; A : START Button B : STOP Button C : Urgent Stop Button *Operating; • Before operating,clean the rollers and body with a wet cloth and dry. • For adjusting the thickness of dough,pull the latches near the roller slowly to unsettle the pin.In this way when you turn the latch up;...

  • Page 7: Ecleaning &Maintenance

    DOUGH ROLLER CLEANING &MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Always turn off the appliance and disconnect from the power supply before cleaning. • Clean outer surface of appliance and rollers with wet cloth and dry after every use. •...

  • Page 8: Ftroubleshooting

    DOUGH ROLLER TROUBLESHOOTING Check if the appliance is plugged in. Check the electrical connections and voltage. THE APPLIANCE DOESN’T OPERATE Check the urgent stop button. Check the start button if it works or not. Check that if there is problem with contactor.

  • Page 9: Gspare Part List- Exploding Drawings

    DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS EMP.HA.01Y-HA.02Y...
  • Page 10 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE:EMP.HA.01.Y PRODUCT NAME P.CODE TOP GEARBOX EQUIVALENT Y.EMP.HA.01.Y.001 TOP FRONT ROLLER SHAFT Y.EMP.HA.01.Y.002 BALL BEARING (6200) Y.EMP.HA.01.Y.003 BOTTOM BACK ROLLER SHAFT Y.EMP.HA.01.Y.004 BOTTOM FRONT ROLLER SHAFT Y.EMP.HA.01.Y.005 BOTTOM FRONT ROLLER Y.EMP.HA.01.Y.006 BOTTOM FRONT CLEANING BLADE Y.EMP.HA.01.Y.007...
  • Page 11 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE:EMP.HA.02.Y PRODUCT NAME P.CODE TOP GEARBOX EQUIVALENT Y.EMP.HA.02.Y.001 TOP FRONT ROLLER SHAFT Y.EMP.HA.02.Y.002 BALL BEARING (6200) Y.EMP.HA.02.Y.003 BOTTOM BACK ROLLER SHAFT Y.EMP.HA.02.Y.004 BOTTOM FRONT ROLLER SHAFT Y.EMP.HA.02.Y.005 BOTTOM FRONT ROLLER Y.EMP.HA.02.Y.006 BOTTOM FRONT CLEANING BLADE Y.EMP.HA.02.Y.007 BOTTOM BACK CLEANING BLADE Y.EMP.HA.02.Y.008...
  • Page 12 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS EMP.HA.01-HA.02...
  • Page 13 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE:EMP.HA.01 PRODUCT NAME P.CODE TOP GEAR BOX EQUIVALENT Y.EMP.HA.01.001 TOP FRONT ROLLER SHAFT Y.EMP.HA.01.002 BALL BEARING (6200) Y.EMP.HA.01.003 BOTTOM BACK ROLLER SHAFT Y.EMP.HA.01.004 BOTTOM FRONT ROLLER SHAFT Y.EMP.HA.01.005 BOTTOM FRONT ROLLER Y.EMP.HA.01.006 BOTTOM FRONT CLEANING BLADE Y.EMP.HA.01.007...
  • Page 14 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE:EMP.HA.02 PRODUCT NAME P.CODE TOP GEAR BOX EQUIVALENT Y.EMP.HA.02.001 TOP FRONT ROLLER SHAFT Y.EMP.HA.02.002 BALL BEARING (6200) Y.EMP.HA.02.003 BOTTOM BACK ROLLER SHAFT Y.EMP.HA.02.004 BOTTOM FRONT ROLLER SHAFT Y.EMP.HA.02.005 BOTTOM FRONT ROLLER Y.EMP.HA.02.006 BOTTOM FRONT CLEANING BLADE Y.EMP.HA.02.007 BOTTOM BACK CLEANING BLADE...
  • Page 15 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS EMP.HA.03...
  • Page 16 DOUGH ROLLER SPARE PART LIST- EXPLODING DRAWINGS PRODUCT CODE:EMP.HA.03 PRODUCT NAME P.CODE BASE FRAME Y.EMP.HA.03.001 WHELL Y.EMP.HA.03.002 SLIDING SHEET METAL (CHECK IN) Y.EMP.HA.03.003 SLIDING SHEET METAL (MEDIUM) Y.EMP.HA.03.004 SLIDING SHEET METAL (EXIT) Y.EMP.HA.03.005 BUTTON (START-STOP) Y.EMP.HA.03.006 URGENT STOP Y.EMP.HA.03.007 PLASTIC PIN (LONG) Y.EMP.HA.03.008 PLASTIC PIN (SHORT) Y.EMP.HA.03.009...

  • Page 17: Helectric Circuit Schema

    DOUGH ROLLER ELECTRIC CIRCUIT SCHEMA Motor Urgent Stop...
