TEA MAKER Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page... -
Page 2: Ageneral Information
TEA MAKER Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
*The Professional Tea Maker ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) Ø 300x425 EMP.CY.80 340x340x480 Ø 355x480 EMP.CY.120 350x350x520 Ø 390x500 EMP.CY.250 420x420x540 Ø 510x620 EMP.CY.400... -
Page 4: A3 Transportation
TEA MAKER TRANSPORTATION *This appliance can be moved by hand from area to area.Do not crash and drop the appliance Kasap Tip Dik Buzdolapları while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
TEA MAKER Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ... -
Page 6: Doperation P Age
TEA MAKER OPERATION *Control Panel; Kasap Tip Dik Buzdolapları A : Indıcator Lamp B : Thermostat Button *Operating; Before firs use fill the water and tea tank completely with water and boil for 30 minutes.Then pour the water and rinse. ... -
Page 7: Ecleaning & Maintenance
TEA MAKER Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE CLEANING AND MAINTENANCE AFTER EVERY USE Clean the surface of appliance with moist cloth after every use. Always turn off the appliance and disconnect from the power supply before cleaning. ... -
Page 8: Ftroubleshooting
TEA MAKER TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. If the water level in the bowl is lower than tap level,add water. If the appliance’s thermostat button is THE APPLIANCE IS NOISY broken,the water in the bowl will always boil,check it. -
Page 9: Gspare Part List-Exploding Drawing
TEA MAKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.CY.80 PRODUCT NAME P.CODE M.MEK-TES-MSL-001 INDICATOR PIPE 19 CM M.PLS-ERS-005 LONG ELBOW 12/1 M.MEK-TES-SRI-004 PLUG SOCKET WARNING LAMP- YELLOW M.ELK-LMB-SNY-003 CAYYAP THERMOSTAT 30-120 C M.ELK-MEK-TRM1-007 CHASSIS RESISTANT 220V 1750W L165 YUV FLASH M.ELK-RZS-BRU-CAY-001... -
Page 10: Product Name
TEA MAKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE: EMP.CY.120 PRODUCT NAME P.CODE COVER (WIRE PEAK) M.MTS-ERS-CAY-021 COVER (24X8) YMH-ERS.CY-FLZ-0004 FILTER (12X17) M.MTS-ERS-CAY-010 DEM CONTAINER (14X21) M.MTS-ERS-CAY-009 FILTER SHEET DIAMETER:95 YSC-ERS.CAY-LZ-0010 RESISTANT 220V 1750W L165 YUV FLASH M.ELK-RZS-BRU-CAY-001 3*1.5 TTR PLUG GRAY CABLE 2MT M.ELK-PWR-PBK-004... - Page 11 TEA MAKER Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE : EMP.CY.250 PRODUCT NAME P.CODE M.MEK-TES-MSL-001 NUT 16 OF 12/1 M.MEK-TES-SRI-005 INDICATOR PIPE 27 CM M.PLS-ERS-007 YELLOW NIPPLE 12/1 M.MEK-TES-SRI-003 LONG ELBOW 12/1 M.MEK-TES-SRI-004 WARNING LIGHT WITH SOCKET- YELLOW M.ELK-LMB-SNY-003 THERMOSTAT 30-120 C M.ELK-MEK-TRM1-007...
- Page 12 TEA MAKER SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE : EMP.CY.400 PRODUCT NAME P.CODE M.MEK-TES-MSL-001 INDICATOR PIPE 32 CM M.PLS-ERS-008 YELLOW NIPPLE 12/1 M.MEK-TES-SRI-003 NUT 16 OF 12/1 M.MEK-TES-SRI-005 LONG ELBOW 12/1 M.MEK-TES-SRI-004 LONG YELLOW NIPPLE YTL-ERS.CY-KS-0002 CHASSIS WARNING LIGHT WITH SOCKET- YELLOW M.ELK-LMB-SNY-003...
-
Page 13: Helectric Circuit Schema
TEA MAKER Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA PRODUCT CODE EMP.CY.80 1,75 EMP.CY.120 1,75 EMP.CY.250 Terminal Thermostat (30-120ºC) Resistance 1750 W (220V) Thermostat Signal Lamp... -
Page 14: Product Code
TEA MAKER ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları PRODUCT CODE EMP.CY.400 Resistance 2500 W Resistance 2500 W Thermostat Signal Terminal Thermostat (30- (220V) (220V) Lamp 120ºC)
