EMPERO EMP.DCY.120 Quick Start Manual

Tea maker with pot
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TEA MAKER WITH POT
Kasap Tip Dik Buzdolapları
CONTENTS
Page
2
Page
3
Page
3
Page
4
Page
4
Page
4
Page
5
6
Page
7
Page
8
Page
9
Page
15
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EMP.DCY.120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EMPERO EMP.DCY.120

Summary of Contents for EMPERO EMP.DCY.120

  • Page 1: Table Of Contents

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PART LIST- EXPLODING DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...

  • Page 2: Ageneral Information

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.

  • Page 3: A1 Product Description

    Kasap Tip Dik Buzdolapları PRODUCT DESCRIPTION *The Professional Tea Maker ,that provides high efficiency has been designed to be used in industrial kitchens. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.DCY.120 294x367x400 320x400x460 EMP.DCY.250 352x425x440 12,6 380x450x490 EMP.DCY.350 415x487x455...

  • Page 4: A3 Transportation

    TEA MAKER WITH POT TRANSPORTATION *This appliance can be moved by hand from area to area.Do not crash and drop the appliance Kasap Tip Dik Buzdolapları while transporting. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.

  • Page 5: Csafety Instructions

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. ...

  • Page 6: Doperation P Age

    TEA MAKER WITH POT OPERATION * Control Panel: Kasap Tip Dik Buzdolapları A : Indicator lamp B : Indicator lamp C : Thermostat D : 0-1 Switch * Operating: • Plug in the appliance and Switch to (l) position. • Before firs use fill the water tank completely with water and boil for 30 minutes.Then pour the water and rinse.

  • Page 7: Ecleaning & Maintenance

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Clean the surface of appliance with moist cloth after every use. • Always turn off the appliance and disconnect from the power supply before cleaning. •...

  • Page 8: Ftroubleshooting

    TEA MAKER WITH POT TROUBLESHOOTING Kasap Tip Dik Buzdolapları Check if the appliance is plugged in. THE APPLIANCE DOESN’T OPERATE Check the electrical connections and voltage. If the water level in the bowl is lower than tap level,add water. If the appliance’s thermostat button is THE APPLIANCE IS NOISY broken,the water in the bowl will always boil,check it.

  • Page 9: Gspare Part List- Exploding Drawing

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING...
  • Page 10 TEA MAKER WITH POT SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.DCY.120 PRODUCT NAME P.CODE BASE FARME Y.EMP.DCY.120.001 FEET Y.EMP.DCY.120.002 CONTACTOR Y.EMP.DCY.120.003 BOWL Y.EMP.DCY.120.004 RESISTANCE Y.EMP.DCY.120.005 Y.EMP.DCY.120.006 Y.EMP.DCY.120.007 INDICATOR THERMOSTAT Y.EMP.DCY.120.008 Y.EMP.DCY.120.009 PLATFORM Y.EMP.DCY.120.010 WARNING LAMP Y.EMP.DCY.120.011 THERMOSTAT Y.EMP.DCY.120.012...
  • Page 11 TEA MAKER WITH POT Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING...
  • Page 12 TEA MAKER WITH POT SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.DCY.250 PRODUCT NAME P.CODE BASE FARME Y.EMP.DCY.250.001 FEET Y.EMP.DCY.250.002 CONTACTOR Y.EMP.DCY.250.003 BOWL Y.EMP.DCY.250.004 RESISTANCE Y.EMP.DCY.250.005 Y.EMP.DCY.250.006 Y.EMP.DCY.250.007 INDICATOR THERMOSTAT Y.EMP.DCY.250.008 Y.EMP.DCY.250.009 PLATFORM Y.EMP.DCY.250.010 WARNING LAMP Y.EMP.DCY.250.011 THERMOSTAT Y.EMP.DCY.250.012 THERMOSTAT BUTTON Y.EMP.DCY.250.013...
  • Page 13 TEA MAKER WITH POT Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING...
  • Page 14 TEA MAKER WITH POT SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları PRODUCT CODE:EMP.DCY.350 PRODUCT NAME P.CODE BASE FARME Y.EMP.DCY.350.001 FEET Y.EMP.DCY.350.002 CONTACTOR Y.EMP.DCY.350.003 BOWL Y.EMP.DCY.350.004 RESISTANCE Y.EMP.DCY.350.005 Y.EMP.DCY.350.006 Y.EMP.DCY.350.007 INDICATOR THERMOSTAT Y.EMP.DCY.350.008 Y.EMP.DCY.350.009 PLATFORM Y.EMP.DCY.350.010 WARNING LAMP Y.EMP.DCY.350.011 THERMOSTAT Y.EMP.DCY.350.012 THERMOSTAT BUTTON Y.EMP.DCY.350.013...

  • Page 15: Helectric Circuit Schema

    TEA MAKER WITH POT Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA CODE EMP.DCY.120 EMP.DCY.250 EMP.DCY.350 THERMOSTAT 30-120ºC RESISTANCE 220V 2000 W THERMOSTAT SIGNAL LAMP THERMIC SIGNAL LAMP 0-1 SWITCH RESISTANCE CONTACTOR 220V LİMİT THERMOSTAT 100ºC...

This manual is also suitable for:

Emp.dcy.250Emp.dcy.350
