Page 1: Table Of Contents
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page INJECTOR CHANGE AND GAS SETTING Page GAS CONNECTION IMAGES Page... -
Page 2: Ageneral Information
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty. -
Page 3: A1 Product Description
PRODUCT DESCRIPTION *The Professional Pizza Ovens (Gas) ,that provides high efficiency has been designed to be used in industrial kitchen. Packaging Product Code Dimensions (mm) Weight (kg) Dimensions (mm) EMP.50G-1340 1710x1075x575 1770x1155x755 EMP.60G-1530 1965x1185x575 TECHNICAL INFORMATION EMP.50G-1340 EMP.60G-1530 PRODUCT CODE... -
Page 4: A3 Transportation
GAS CONVEYOR PIZZA OVENS TRANSPORTATION Kasap Tip Dik Buzdolapları *This appliance can not be moved by hand from area to area.It must be moved on pallet with forklift truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol. -
Page 5: Csafety Instructions
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS *Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials. *Do not operate the appliance when the machine is empty. -
Page 6: Doperation
GAS CONVEYOR PIZZA OVENS OPERATION Kasap Tip Dik Buzdolapları * Control Panel: OFF MODE SCREEN AMBIENT TEMPERATURE PANEL ON / OFF... - Page 7 GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları *Use of MAIN MENU MANUEL COOKING If you want to cook manually, click here. RECEIPT If you want to cook a recipe or create a recipe, click here. ON / OFF BUTTONU Click here to turn the device on or off.
- Page 8 GAS CONVEYOR PIZZA OVENS COOKING SCREEN Kasap Tip Dik Buzdolapları ON / OFF BUTTONU If this button is clicked, cooking ends, the oven turns off and returns to the main menu. TEMPERATURE The instantaneous temperature of the furnace, the set value and the status of the heaters are displayed here.
- Page 9 GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları RECEIPT COOKING SCREEN RECEIPT NAME If this button is clicked, cooking ends, the oven turns off and returns to the main menu. RECEIPT IMAGE Recipe photo can be edited by clicking here.
-
Page 10: Cleaning And Maintenance
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları CLEANING & MAINTENANCE ➢ CLEANING AND MAINTENANCE AFTER EVERY USE • Be sure that gas and electric connections are off before cleaning. • Clean the inside of the oven with soft cloth by using oil solvent spray,before the appliance gets cooled exactly. -
Page 11: Ftroubleshooting
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları TROUBLESHOOTING Check if the gas connection of the device has been made. If the hoses with gas inlet leak gas due to tears, holes, DEVICE DOES NOT WORK etc., the device will not work.. Check the electrical connection. -
Page 12: Ginjector Change And Gas Setting
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları INJECTOR CHANGE AND GAS SETTING PIZZA OVENS (GAS ) BURNER-INJECTOR CHANGE CHART EMP.50G-1340 EMP.60G-1530 NG / LPG mm mm 30 mbar 50 mbar 37 mbar 50 mbar Change of the burner injector The oven must be dispatched from the factory as it works with NG.The injectors of the... -
Page 13: Hgas Connection Images
GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları GAS CONNECTION IMAGES Image 1... -
Page 14: Ispare Part List-Exploding Drawing
GAS CONVEYOR PIZZA OVENS SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.50G-1340... - Page 15 GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.50G-1340 PRODUCT NAME P.CODE 8A 230 V AC RELAY JP.M.ELK-KNT-ROL-001 J TYPE THERMOCULP 15 CM M.ELK-EDM-JKT-018 IGNITION PLUG M.GAZ-CKM-BUJI-001 PG-11 CABLE FITTING M.ELK-RKR-PLS-003 350 °C LIMITOR M.ELK-MEK-LMT-014...
- Page 16 GAS CONVEYOR PIZZA OVENS SPARE PART LIST-EXPLODING DRAWING Kasap Tip Dik Buzdolapları EMP.60G-1530...
- Page 17 GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları SPARE PART LIST-EXPLODING DRAWING PRODUCT CODE: EMP.60G-1530 PRODUCT NAME P.CODE IGNITION PLUG M.GAZ-CKM-BUJI-001 3/4- 3/4 30 CM GAS FLEX M.GAZ-TES-SPR-026 CONEXION SHEET YSC-KNX.GPZ-LZ-0112 BURNER PIPE 32*2 130MM YBR-KNX.GPZ-KS-0008 GASKET M.CNT-PLS-KLN-001 FLANGE SHEET YSC-KNX.GPZ-LZ-0110 GASKET M.CNT-PLS-KLN-003...
-
Page 18: Jelectric Circuit Schema
GAS CONVEYOR PIZZA OVENS ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları Digital indicator Limit Termostat terminal Ignition Card Prosestat Step Motor Driver Snail Fan Step Motor Gas Valve Power Supply Contactor Fuse 4 A Circulation Engine Glass Fuse Cooling fan... - Page 19 GAS CONVEYOR PIZZA OVENS Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA...
- Page 20 GAS CONVEYOR PIZZA OVENS ELECTRIC CIRCUIT SCHEMA Kasap Tip Dik Buzdolapları...
