ROTATING ELECTRIC PİZZA OVEN
Kasap Tip Dik Buzdolapları
CONTENTS
A
GENERAL INFORMATION
A1
PRODUCT DESCRIPTION
A2
TECHNICAL INFORMATION
A3
TRANSPORTATION
A4
UNPACKING
B
INSTALLATION
C
SAFETY INSTRUCTIONS
D
OPERATION
E
CLEANING & MAINTENANCE
F
TROUBLESHOOTING
G
SPARE PARTS LIST- EXPLODED DRAWING
H
ELECTRIC CIRCUIT SCHEMA
Page
2
Page
3
Page
3
Page
4
Page
4
4
Page
5
Page
6
Page
8
Page
9
Page
10
Page
13
Page
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the EMP.SPO.01 and is the answer not in the manual?

Questions and answers

Related Manuals for EMPERO EMP.SPO.01

Summary of Contents for EMPERO EMP.SPO.01

  • Page 1 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları CONTENTS GENERAL INFORMATION Page PRODUCT DESCRIPTION Page TECHNICAL INFORMATION Page TRANSPORTATION Page UNPACKING Page INSTALLATION Page SAFETY INSTRUCTIONS Page OPERATION Page CLEANING & MAINTENANCE Page TROUBLESHOOTING Page SPARE PARTS LIST- EXPLODED DRAWING Page ELECTRIC CIRCUIT SCHEMA Page...
  • Page 2 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları GENERAL INFORMATION Before installing the appliance, read operation and maintenance instructions carefully.Wrong installation and part changing may damage the product or may cause injury on people.These are not in our company’s responsibility to damage the appliance intentionally,negligence,detriments because of disobeying instructions and regulations,wrong connections.Unauthorized intervention to appliance invalidates the warranty.
  • Page 3 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları DESCRIPTION *This appliance-professional pizza oven electrical - provides high efficiency, designed to be used in industrial kitchens . PACKED WEİGHT(kg) CODE DIMENSIONS(mm) DIMENSIONS EMP.SPO.01 1200x1384x1980 1310x1550x2220 TECHNICAL INFORMATION ELECTRIC CABLE POWER FUSE CODE CAPACITY (mm²)
  • Page 4 ROTATING ELECTRIC PİZZA OVEN TRANSPORTATION *This appliance can’t be moved from area to area by hands, it must be on a pallet with forklift Kasap Tip Dik Buzdolapları truck. UNPACKING *Please unpack the package according to the security codes and ordinances of current country and get rid from the pack.Parts which contacts with food are produced by stainless steel.All plastic parts are marked by material’s symbol.
  • Page 5 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları SAFETY INSTRUCTIONS * Do not use the appliance in insufficient lighted place. *Do not touch the moving attachments while the appliance operates. *Do not install the appliance in the presence of flammable or explosive materials.The ...
  • Page 6 ROTATING ELECTRIC PİZZA OVEN OPERATION Kasap Tip Dik Buzdolapları *CONTROL PANEL : A: ON-OFF B: LAMP C: TOP DIGITAL THERMOMETER D: TOP DIGITAL SIGNAL LAMP E: SUB DIGITAL THERMOMETER F: SUB DIGITAL SIGNAL LAMP G: TANBUR SPEED ADJUSTMENT H: TOP DIGITAL HEAT ADJUSTMENT I: SUB DIGITAL HEAT ADJUSTMENT...
  • Page 7  When you finish, press OFF button to switch it off. PİZZA CODE 1.ALTERNATIVE BUTTOM DEGREE : 300ºC UPPER DEGREE : 280ºC COOKİNG TİME: 7-8 minute EMP.SPO.01 2.ALTERNATIVE BUTTOM DEGREE: 350ºC UPPER DEGREE : 320ºC COOKİNG TİME : 5-6 minute...
  • Page 8 ROTATING ELECTRIC PİZZA OVEN CLEANING & MAINTENANCE Kasap Tip Dik Buzdolapları  AFTER EACH USE YOU HAVE TO :  Turn off the appliance and disconnect it from the electric before cleaning.  Clean the inside of the oven with soft cloth by using oil solvent spray,before the appliance gets cooled exactly.
  • Page 9 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları TROUBLESHOOTING Check if the appliance is plugged in. Check the electrical connections and THE APPLIANCE DOESN’T OPERATE voltage. Check if the fuse is on or off. Check the resistances. Check the heat settings. THE APPLIANCE DOESN’T COOK WELL Do not overload the oven.
  • Page 10 ROTATING ELECTRIC PİZZA OVEN SPARE PART LIST- EXPLODED DRAWING Kasap Tip Dik Buzdolapları...
  • Page 11 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları SPARE PART LIST- EXPLODED DRAWING PRODUCT CODE:EMP.SPO.01 PRODUCT NAME P.CODE CHIMNEY EXITS SHEET-3 YSC-KNX.SPOE-PN-0005 CHIMNEY EXITS SHEET-6 YSC-KNX.SPOE-LZ-0044 J TYPE THERMOCOUPLE 10 CM M.ELK-EDM-JKT-016 J TYPE TERMOHANDLE 15 CM M.ELK-EDM-JKT-017 TICKET M.AKS-ETK-LKS-089 D700-SC FR-D720S-025SC-EC - DRIVER JP.M.ELK-SRC-001...
  • Page 12 ROTATING ELECTRIC PİZZA OVEN M8 HANDLE JP.M.AKS-KLP-BKL-002 COVER ARA-KNX.SPOE-0002 Kasap Tip Dik Buzdolapları 565MM*160MM*4 MM GLASS M.CAM-TMP-034 GLASS WICK HCN-ELY-KZ-001 ENCODER JP.M.ELK-EDM-DGT-010 0-1 SWITCH JP.M.ELK-SLT-PKO-004 HINGE M.AKS-MNT-PLC-001 PG-16 CABLE FITTING JP.M.ELK-RKR-PLS-001 PG-11 CABLE FITTING M.ELK-RKR-PLS-003 PLUG M.PLS-OZL-004 0,18 KW900 MTR S41/60 TRF.15 D/DK ESM-40 REDUCER M.ELK-MTR-RMB-002 17*60*1 V-TAMBOUR M.MUH-KSN-003...
  • Page 13 ROTATING ELECTRIC PİZZA OVEN Kasap Tip Dik Buzdolapları ELECTRIC CIRCUIT SCHEMA...
