Installation; Operation - Task Force Tips SHO-FLOW 1 Instructions For Safe Operation And Maintenance

4.0 INSTALLATION

SHO-FLOW should be installed with the FLOW arrows on the label pointing in the direction of water fl ow. Published accuracy is
assured when the fl ow meter is installed in conditions with minimal turbulence; between two lengths of hose with the same size
couplings as the fl ow meter. Avoid locations where the fl ow meter or adjacent hose are used as a step.
HOSE FROM TRUCK SE FROM TRUCK
NOTICE
NOTICE

5.0 OPERATION

A smartphone app is required to view the fl ow rate of the SHO-FLOW.
Please download the app from either the Google Play Store or the
Apple App Store before proceeding. Search SHO-FLOW in either store
1) Create a fl ow greater than or equal to the minimum rated fl ow rate
through the SHO-FLOW to turn on the device and start transmitting
the Bluetooth signal.
2) If the app is not already open, fi nd and press the SHO-FLOW app
icon from your list of apps, which will launch the app. (The TFT logo
is displayed while opening and the app will bring you to the main
Flow Display screen.)
a. (FOR ANDROID ONLY) If the app is not already on the home
screen you can choose to place it on the home screen if desired
by holding down on the icon until the phone gives you the ability
to drag it onto the screen.
3) Allow app to use location if prompted. (This is required for use)
4) If a Bluetooth connection has not already been set up refer to section
5.2.
5) Once a connection is established the fl ow rate will be displayed on
the Flow Display screen (Section 5.1)
©Copyright Task Force Tips LLC 2019
FLOW DIRECTION
ARROW
Turbulence can cause inaccurate readings. Installing the fl ow meter adjacent to turbulence
causing plumbing like elbows, partially gated valves, eductors, and fl at adapters is not
recommended. The best accuracy is assured when the fl ow meter is paired between two sections
of straight hose.
Reverse installation will result in incorrect readings and will damage the device over time. Always
ensure the FLOW arrows on the device point in the direction of fl ow.
HOSE TO NOZZLE HOSE TO NOZZLE
6
LIE-100 December 30, 2019 Rev04
