4.0 INSTALLATION
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) For RC monitor.
4.1 STRUCTURAL REQUIREMENTS
The structure that the EF1 RC Monitor is mounted to must
withstand the internal pressure of the monitor as well as shear
and bending forces due to nozzle reaction. Nozzle reaction can be
as high as 150 lbs (70 kg) (200 gpm at 200 psi).
For flanged connections the use of flat flanges without raised
faces is recommended. Use a ring gasket as defined in ASME
16.21 or ISO 7483. Tighten flange bolts in an alternating sequence
as shown in figure 4.1. Tighten sequentially each bolt or stud
three times with 30%, then 60%, and finally 100% of the specified
torque. Tighten to 76-80 ft-lb (100-110 Newton-Meters).
FLANGE TYPE
1.5 ANSI 150
2.0 ANSI 150
4.2 TRAVEL RANGES
The EF1 RC Monitor is available with various inlet fittings. These Inlet Adapters must be oriented upon installation so the EF1 RC will
point in the desired direction. Figure 3.4A shows examples of Inlet Adaptors. Travel ranges relative to the Straight Ahead Reference
Mark are shown in Figure 4.2. Figure 4.2.1 gives the location of the travel stops.
HORIZONTAL
TRAVEL
©Copyright Task Force Tips, Inc. 2017
OUTSIDE
THICKNESS
DIAMETER
in
mm
in
mm
5
127
0.63
16
6
152.4 0.75
19
135° LEFT
135° RIGHT
Fig 4.2 Travel Ranges Relative to
Straight Ahead Reference Mark
9
1
3
4
2
Fig 4.1
Flange Bolt Tightening Sequence
BOLT
# OF
SIZE OF
HOLE
BOLTS
BOLTS
CIRCLE
in
mm
in
3.88 98.4
4
1/2
4.75 120.7
4
5/8
90°
45°
ELEVATION
TRAVEL
Tighten Sequentially
Each Bolt
Three Times
TORQUE ON
BOLTS
mm
ft-lb
N-m
13
20-40
27-54
16
40-70
54-95
LIY-210 December 4, 2017 Rev00
