3.0 GENERAL INFORMATION

The SHO-FLOW is a water-powered fi re ground fl ow meter that measures the fl ow rate in a hose line and transmits fl ow data using a
Bluetooth wireless connection. Data is received by a paired device and displayed using a smart phone app. The SHO-FLOW does
not have a display. Flow meter power is generated whenever fl ow causes its turbine to rotate. Data is automatically transmitted
whenever fl ow is present, and stops when fl ow stops. An arrow indicates the direction of fl ow.
The SHO-FLOW is intended for intermittent use with clean fi re water or solutions of water and foam concentrate. It is not intended for
use with pure foam concentrate, compressed air foam, hydrocarbons, or other types of liquid. Turbine bearings are subject to wear.
The SHO-FLOW is not intended for continuous outdoor storage, use with heated fl uids, in permanently piped installations, 24/7 wet
conditions, or in extended service conditions (non-fi re ground).
Hose from Truck Hose from Truck

3.1 PART IDENTIFICATION AND TERMS

OPERATING FLOW RANGE
50-300 GPM
(200-1200 LPM)
50 GPM (200 LPM)
Required to Connect
DO NOT EXCEED
350 GPM (1300 LPM)
MAXIMUM
OPERATING PRESSURE
300 PSI (20 BAR)
INLET THREADS
DIRECTION OF FLOW
©Copyright Task Force Tips LLC 2019
User Supplied SmartPhone
with SHO-FLOW App
Figure 3.0
50-300 GPM
(200-1200 LPM)
Figure 3.1
4
Hose to Nozzle Hose to Nozzle
QUICKSTART:
tft.com/SHO-FLOW
®
tft.com/EXXXXXX
DEVICE NAME
UNIQUE DEVICE NAME/SERIAL NUMBER
OUTLET THREADS
MADE IN USA
TFT.COM
PATENT PENDING
PATENT: 9,295,863
LIE-100 December 30, 2019 Rev04
